The PDX Amplifiers give you more of everything you want in an amp. They are more powerful,
more efficient, more compact and more convenient than any other amps you can buy.
Amplifier Performance at the Highest Level
Common Features:
• Selectable Variable Filters HP & LP • Mono amps provide Variable LP, Selectable Subsonic Filters and compatibility with Remote Control Bass Knob (RUX-KNOB) • Stacking Capability • Thermal and Low Voltage
Protection • Ultra Wide Frequency Response Range • Quick Connectors for Speakers and Power Supply • Mono 1 Ω Drive • RMS Output @ 2-4 Ω
PDX-M12
PDX-M6
PDX-F6
PDX-F4
PDX-V9
Output Channels
Mono
Mono
4 Channels
4 Channels
5 Channels
Max Power Output
2500W
1200W
1200W
900W
1600W
RMS Power Output [@14.4V 1%THD]
1 x 1200W (2/4
Ω
)
1 x 600W (2/4
Ω
)
4 x 150W (2/4Ω)
2 x 300W (4Ω)
4 x 100W (2/4Ω)
2 x 200W (4Ω)
4 x 100W + 1 x 500W (2/4Ω)
2 x 200W + 1 x 500W (4Ω)
Amplification Circuit
Class-D
Class-D
Class-D
Class-D
Class-D
Quick and Convenient Connection and Adjustment
Because the PDX amps handle massive amounts
of power, they have large plug-in terminals that
accept any type of cable and allow quick connection.
Convenient front panel controls let you make fine
sound adjustments at any time.
Remote Control Bass Knob (RUX-KNOB)
Simply add the RUX-KNOB (sold separately) and get full
control from the dash for instant bass adjustment. You
also get the ability to control multiple amps from just
one controller with simple telephone cord adapters. For
mono amps and PDX-V9.
Better Class-D Performance
Previously, Class-D amplifiers have not been able
to achieve both low distortion and high frequency
response, but the PDX series amps provide both!
Non-Stop Sound Output
If the amp gets too hot, the Thermal
Protection circuit decreases power until
it cools down, maintaining continuous
operation. It also decreases the output if
battery voltage gets too low. When two or
more amps are stacked, heat transfer plates
between them ensure efficient cooling.
Get More Power and Save Space
The PDX amplifiers feature a smart, unique
stacking design and a new, slimmer chassis,
allowing them to be stacked vertically on top
of one another, saving space in your car.
High Power With Amazing Efficiency
All of the PDX amps take advantage of Switch-
Mode Digital Amplification technology for
exceptional efficiency at all power levels. You
can drive them at high power for as long as you want, they’ll never overheat.
Inside these compact, stackable amps, advanced technology provides extreme power and supremely efficient performance.
The new 5-channel PDX-V9 completes the impressive PDX series lineup.
