72
73
L
levi zapah_left bolt
52
L1
18
L2
2
2
desni zapah_right bolt
22 48
40
10
L
52
L1
L2
2
2
18
22 48
40
spodnja letev za krilna vrata_
wing door bottom slat
spodnja letev za krilna vrata_
wing door bottom slat
A-180
A-181
8
10
12
8
10
12
max 110
max 250
max 110
max 250
80
kg
max
80
kg
max
KODA_CODE
L
L1
L2
A180/TG/800/L
800 658 606
levo_left
A180/TG/800/R
800 658 606 desno_right
a180/tg/900/l
900 758 706
levo_left
a180/tg/900/r
900 758 706 desno_right
a180/tg/1000/l
1000 858 806
levo_left
a180/tg/1000/r 1000 858 806 desno_right
a180/tg/1200/l
1200 1058 1006
levo_left
a180/tg/1200/r 1200 1058 1006 desno_right
a180/ti/800/l
800 658 606
levo_left
a180/ti/800/r
800 658 606 desno_right
a180/ti/900/l
900 758 706
levo_left
a180/ti/900/r
900 758 706 desno_right
a180/ti/1000/l
1000 858 806
levo_left
a180m/ti/1000/r 1000 858 806 desno_right
a180/ti/1200/l
1200 1058 1006
levo_left
a180/ti/1200/r
1200 1058 1006 desno_right
TG
= Geze pravokotni tečaj (standard)_
Geze rectangular hinge (standard)
TI
= italijanski kvadratni tečaj (po naročilu)_
italian square hinge (on demand)
KODA_CODE
L
L1
L2
a181/tg/800
800 658 606
a181/tg/900
900 758 706
a181/tg/1000
1000 858 806
a181/tg/1200
1200 1058 1006
a181/ti/800
800 658 606
a181/ti/900
900 758 706
a181/ti/1000
1000 858 806
a181/ti/1200
1200 1058 1006
TG
= Geze pravokotni tečaj (standard)_
Geze rectangular hinge (standard)
TI
= italijanski kvadratni tečaj (po naročilu)_
italian square hinge (on demand)
artikel se vgradi brez izrezov na steklu •
puša P10 ni priložena •
the article can be mounted without glass machining •
inlet piece P10 not included •
• artikel se vgradi brez izrezov na steklu
• the article can be mounted without glass machining
s tečajem in zapahom_
with hinge and bolt
s tečajem in izrezom za cilinder_
with hinge and cylinder cutting
