EXPEDITION HARD CASE TRUNKS
•Universal mounting kit attaches to your existing luggage rack
•Quick disconnect mounting system allows trunk to be removed in seconds
•All hardware included – everything you need for complete installation to your rack
•Solid weatherproof construction keeps your cargo dry, even when riding in the rain
•PART #3516-0068 overall outside dimensions: 38 cm L x 38 cm W x 25,5 cm H (15” x 15” x 10”);
27,9 liter (1700 cubic inch) capacity; holds one full-face helmet
•PART #3516-0118 overall outside dimensions: 43 cm L x 58,5 cm W x 33 cm H (17” x 23” x 13”);
47,5 liter (2900 cubic inch) capacity; holds two full-face helmets and other needed gear
DESCRIPTION
PART #
HC1700
3516‑0063
HC2900
3516‑0064
DESCRIPTION
PART #
Mounting plate and hardware kit for PART # 3516‑0063
3516‑0171
Mounting plate and hardware kit for PART # 3516‑0064
3516‑0172
NOTE: USE YOUR OWN JUDGMENT WHEN LOADING YOUR MOTORCYCLE. LIMITS MAY DEPEND ON RIDER EXPERIENCE, SPEED, TERRAIN TO BE COVERED AND WEATHER CONDITIONS.
3516‑0171
3516‑0063
HC1700 AND HC2900 HARD CASE TRUNKS
•Solid and weatherproof with matte black polypropylene construction
•Streamlined shape looks great and cuts through the wind
•Universal mounting kit attaches to existing luggage rack; quick-disconnect allows trunk to be removed from bike in seconds
•Integrated lock with two keys
•Integrated molded grip for easy transport off-bike
•All hardware included
•Protective tape sold separately
•HC1700 overall outside dimensions: 38 cm L x 38 cm W x 25,5 cm H (15” x 15” x 10”); 27,9 liter capacity (1700 cubic inch); holds one full-face helmet and
other needed gear
•HC2900 overall outside dimensions: 43 cm L x 58,5 cm W x 33 cm H (17” x 23” x 13”); 47,5 liter capacity (2900 cubic inch); holds two full-face helmets and
other needed gear
3516‑0064
3516‑0068
3516‑0118
DESCRIPTION
PART #
Small
3516‑0068
DESCRIPTION
PART #
Large
3516‑0118
Quick disconnect
mounting system
