MOOSE RACING BY
ARC FLEX BRAKE LEVERS
•Forged, anodized, and hinged brake levers with CNC-machined master
cylinder interfaces
•Adjustable reach allows customization to rider’s hand size
•ARC hinge design allows lever to flex out of the way in most impact situations
•Pushrod or ball bearing contact styles for positive brake modulation
•Available in black, blue and red with laser-etched Moose Racing by ARC logos
MOOSE RACING BY ARC DC8
CLUTCH ASSEMBLIES
•Say goodbye to lever play and vibration,
thanks to the ARC external lever pivot design
•Oversized cast perch, forged flex lever,
spiked rubber cable adjuster, and a nylon handlebar
sleeve make up this precision control
•ARC flex lever blade with reach adjust is hinged to move
out of the way in most impact situations
•Fits all 01-14 off-road bikes with cable operated clutch
•Includes a slipper clamp for the brake master cylinder
•Available in black, blue or red with laser-etched Moose Racing by ARC logos
•Replacement levers fit Moose Racing by ARC DC8 clutch assembly only
•DC8 refresh kit PART #0615-0098 includes two rubber guards, lever pivot bolt, stainless
steel wire and pivot bushings
•Made in the U.S.A.
DESCRIPTION
PART #
MOOSE RACING BY ARC DC8 CLUTCH ASSEMBLY
Black lever
0612‑0250
Blue lever
0612‑0251
Red lever
0612‑0252
DESCRIPTION
PART #
MOOSE RACING BY ARC DC8 REPLACEMENT LEVERS
Black
0613‑0271
Blue
0613‑0272
Red
0613‑0273
REFRESH KIT
PART #
0615-0098
DESCRIPTION
PART #
Easy‑Pull clutch system
M555‑00
Repl. cable
M555‑10‑01
EASY PULL
CLUTCH SYSTEM
•Constructed of high-strength polished
cast aluminum
•Inner linkage has three settings which increase
the leverage ratio and ease the clutch pull
•Fits most bikes, dependent on cable end and
cable housing
•Easy Pull’s cable end measures 9,6 mm tall and
7,9 mm in diameter
•Easy Pull’s cable housing measures 8 mm
in diameter
•Verify full clutch disengagement before riding
•For off-road use only
•Replacement cable PART #M555-10-01 comes
with two different length cables for all 2- and
4-stroke models
ULTIMATE CLUTCH FITMENT
ULTIMATE
CLUTCH
SYSTEM
ULTIMATE
PERCH
ULTIMATE
HOT START
LEVER
ULTIMATE
LEVER
STANDARD
ULTIMATE
LEVER
SHORTY
2-stroke applications
0612-0006
0615-0019
-
0613-0035
0613-0036
CRF/YZF
0612-0005
1
-
0615-0001
0613-0035
0613-0036
RM-Z/KXF
0612-0042
1
-
-
0613-0035
0613-0036
1
Perch includes hot start lever.
ULTIMATE CLUTCH
LEVER SYSTEM
•Two cable locating positions (shown on
bottom of lever) allow for adjustable leverage
and an easy pull
•Needle bearings provide a smooth,
consistent feel
•Removable rubber guard keeps mechanisms
clean and operational
•Nylon insert allows perch to rotate
during impact
•Pivoting cable adjuster makes cable tension
adjustments easy
•Adjustable reach for personalized lever angle
•Constructed of polished cast aluminum alloy
•Replacement perch inserts available
separately, PART #0615-0180 (3-pk.)
NOTE: When ordering a replacement 4-stroke
perch (perch only) order 2-stroke perch and
appropriate hot start lever.
0612‑0005
Back view
w/o cover
FITS MODEL
BLACK
BLUE
RED
HONDA
CR125R/250R 05-07
0614-0222
0614-0223
0614-0224
CRF250/450R 05-06
0614-0222
0614-0223
0614-0224
CRF250/450R 07-14
0614-0225
0614-0226
0614-0227
CRF250/450X 05-07
0614-0222
0614-0223
0614-0224
KAWASAKI
KX125/250 00-09
0614-0216
0614-0217
0614-0218
KX250F/450F 04-12
0614-0216
0614-0217
0614-0218
KX250F/450F 13-14
0614-0219
0614-0220
0614-0221
SUZUKI
RM125/250 04-09
0614-0216
0614-0217
0614-0218
FITS MODEL
BLACK
BLUE
RED
SUZUKI (CONT)
RMZ250/450 04-14
0614-0216
0614-0217
0614-0218
YAMAHA
YZ85 05-12
0614-0216
0614-0217
0614-0218
YZ125/250 01-07
0614-0216
0614-0217
0614-0218
YZ125/250 08-14
0614-0219
0614-0220
0614-0221
YZ250F 05-06
0614-0216
0614-0217
0614-0218
YZ250F 07-14
0614-0219
0614-0220
0614-0221
YZ450F 05-07
0614-0216
0614-0217
0614-0218
YZ450F 08-14
0614-0219
0614-0220
0614-0221
0614‑0216
0614‑0217
0614‑0218
0612‑0250
0612‑0251
0612‑0252
M555‑00
