199
DESCRIPTION
PART #
RESERVOIRS WITH STRAIGHT NOZZLE
Transparent plastic
1731‑0309
Black aluminum
1731‑0311
Aluminum
1731‑0310
DESCRIPTION
PART #
RESERVOIRS WITH 90° NOZZLE
Transparent plastic
1731‑0312
Black aluminum
1731‑0314
Aluminum
1731‑0313
BRAKE FLUID RESERVOIRS
•Mini-style brake fluid reservoirs
•Manufactured from plastic or aluminum
•Available in three finishes
FITS MODEL
SYSTEM PART #
MASTER TYPE
LINE LENGTH
PISTON
ASSEMBLY
SLAVE PART #
HONDA
CR 250 R 90‑03
0617‑0145
167 Black
1045 mm
9,5 mm
52
0612‑0048
1
CR 250 R 04‑06
0612‑0308
167 Black
1045 mm
9,5 mm
41
0612‑0047
CRF 250 R 04‑09
0612‑0306
167 Black
1045 mm
9,5 mm
57
0612‑0046
HYDRAULIC CLUTCH SYSTEM
•No more pressure-point fading
•Completely self-adjusting; less maintenance
•Reduces lever pull up to 20%
•Forged lever blade with reach-adjust is ready to mount
•Filled with biodegradable mineral oil
HYMEC 167 BLACK HYDRAULIC CLUTCH APPLICATION CHART
HYDRAULIC CLUTCH SYSTEM continued on next page.
167 Style
163 Style
M0720499
M0999020
M0432301‑02
M0720568
M0720552
1
All spare slave cylinders will be issued with standard cap and bracket; this model uses a slave cylinder with a different cap.
1731‑0309
1731‑0310
1731‑0314
