All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
HANDLEBARS & CONTROLS
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
216
UNIVERSAL
TWIST-GRIP
THROTTLE CABLE
•Universal 112 cm (44”)
throttle cable for
twist-type throttles
BULK CABLE WIRE
•30,5 m (100’) bulk galvanized
cable wire for custom
cable fabrication
•Sold to dealer in 30,5 m roll (100’); sold to consumer per 30,5 cm (12”)
HIGH-
TEMPERATURE
SLEEVING KITS
•Protects against abrasion and
resists oil, gasoline and most
chemicals
•Heat range of -40° to 94+°C
(-40° to 200+°F)
•UV light resistant
•Easy to cut with scissors and is easy to clean with soap and water
•Kits include 305 cm (10’) of 6,4 mm (
1
/
4
”) sleeving, 305 cm (10’) of
9,5 mm (
3
/
8
”) sleeving, 152 cm (5’) of 12,5 mm (
1
/
2
”) sleeving and heat-shrink
termination tubing
•Available in black, red or blue
BULK CABLE
HOUSING
•Bulk cable housing for
custom cable fabrication
•30,5 m L (100’) with 4,8 mm
outside diameter (
3
/
16
”)
•Sold to dealer in 30,5 m roll
(100’); sold to consumer per
30,5 cm (12”)
DESCRIPTION
PART #
(A) Black
2120‑0080
(B) Red
2120‑0081
DESCRIPTION
PART #
(C) Blue
2120‑0082
SIZE
PART #
4,8 mm W x 30,5 m L (
3
/
16
” x 100’)
901
DESCRIPTION
PART #
1,2 mm W x 30,5 m L (
3
/
64
” x 100’)
900
DESCRIPTION
PART #
1,6 mm W x 30,5 m L (
1
/
16
” x 100’)
900A
PART #
110049
PART #
1178-65
UNIVERSAL
BRAKE CABLE
•Universal 152,5 cm (60”)
cable with black
outer housing
•9,5 mm (
3
/
8
”) barrel end
at lever
PART #
17
UNIVERSAL
THROTTLE CABLE
•Universal 122 cm (48”) cable
with black outer housing
•Ball end fits many throttles
PART #
935
CABLE
ADJUSTER
•Fits 4,8 mm (
3
/
16
”) cable housing
•Sold each
DESCRIPTION
PART #
9,5 mm dia. (
3
/
8
”)
DS‑223460
DESCRIPTION
PART #
12,7 mm dia. (
1
/
2
”)
DS‑223461
DESCRIPTION
PART #
19,1 mm dia. (
3
/
4
”)
DS‑223462
CLEAR
SHRINK TUBING
•Used to cover cables, wiring, etc.
•Prevents scratching of paint and chrome
•Available in 305 cm (10’) rolls in three sizes
DS‑223462
A
B
C
DESCRIPTION
PART #
Cable sleeve kit
DS‑223002
3
/
8
” x 10’ roll
DS‑223007
DESCRIPTION
PART #
1
/
2
” x 10’ roll
DS‑223008
5
/
8
” x 10’ roll
DS‑223009
BRAIDED CABLE SLEEVE KIT
•Clear vinyl shrink-tube covers clear stainless steel-type cables to eliminate
scratching painted or chrome surfaces
•Vinyl tube slides over cable, then is heated with heat gun to shrink tightly
over cable
•Kit contains four 40,5 cm-long tubes (16”) – enough to cover two throttle cables, clutch cable and
speedometer cable
•Also available in 3 m rolls (10’): 10 mm (
3
/
8
”) for throttle cables,
13 mm (
1
/
2
”) for speedometer cables and 16 mm (
5
/
8
”)
for clutch cables
