ALUMINUM SKID PLATES
•Protects vital engine parts and cases from rocks and debris
•Clear anodized for corrosion protection and good looks
•Skid plates made from 4,8 mm (
3
/
16
”) 5052 H-32 aluminum (some plates
use 4,1 mm (0,160”))
•Smooth underside won’t snag when crossing logs
•Oil drain hole on all required models
•Heat-treated chromoly steel clamps keep plates mounted securely
•All mounting hardware included
•Replacement clamps available
•Made in the U.S.A.
REPLACEMENT HARDWARE
•Replacement clamps sold each
•Quantity of replacement clamps is one unless there is a ( ) with a quantity in front
of the part number
•Bolt kits are sold in sets of four bolts and four washers
FITS MODEL
SKID PLATE PART # REPL. CLAMPS
2
BMW
F650/800GS 08-13
0505-0966
1
-
R1200GS 08-13
0506-0628
-
GAS GAS
MX/XC/EC200/250/300 98-11
M750
(3) M209
HONDA
CRF/XR50/70 00-12
0505-0047
-
CR80/85/85E 00-08
M100
(3) M208
CR125R 02-07
M105
(4) 0506-0152
CRF150F/230 03-05
0505-0048
(3) M208
CRF150F 06-14
0506-0261
(2) M208
CRF150R/E 07-14
0506-0288
(2) M208 / (2) M209
CRF230F 06-14
0505-0048
(3) M208
CRF230L 08-12
0505-1044
(3) M208 / (1) M209
CR250R 97-99
M451X
(3) M827
CR250R 00-01
M452X
(4) M827
CR250R 02-07
M453X
(3) 0506-0152 / (1) 0506-0153
CRF250R 04-09
0505-0064
(1) 0506-0152, (3) 0506-0153
CRF250X 04-14
0505-0064
(1) 0506-0152, (3) 0506-0153
CRF250R 10-14
0505-1045
(4) 0506-0763
CRF250L 13-14
0506-0767
-
XR250R 86-94
M405X
(2) M207
XR250R 96-04
M412X
(1) M207 / (3) M208
XR400R 96-04
M411X
(1) M207 / (3) M209
CRF450R 02-04
M454X
(4) M827
FITS MODEL
SKID PLATE PART # REPL. CLAMPS
2
HONDA (CONT)
CRF450R 05-08
0506-0149
(3) 0506-0152
CRF450R 09-14
0505-0896
(4) 0506-0763
CRF450X 05-14
0506-0183
(1) 0506-0152
CR500 90-01
M433
(3) M209
XR600R 89-00
M431
(3) M208
XR650L 92-14
M431
(3) M208
XR650R 00-07
M434X
-
HUSABERG
TE 250/300 11-13
0506-0641
(4) M208
HUSQVARNA
250/300/360 CR/WR 98-13
M207X
(3) M208
250/310/450/510 TC/TE/TXC 08-09 0505-1101
(2) M208
250R/310R TC/TXC 11-13
0505-1326
-
310/450/510 TC/TE/TXC 2010
0505-1101
(2) M208
Terra/Strada TR650 13
0505-1290
(2) M803
KAWASAKI
KX65 97-14
0506-0262
-
KX80/85/100 96-14
M220
-
KLX125/L 03-06
-
(3) M208
KX125 03-05
M242
(3) M208
KLX140 All years
0505-1098
(2) M207
KDX200 89-94
M214
(4) M208
KDX200/220 95-06
M217
(3) M208
KX250 88-89
M222
(4) M208
APPLICATION CHART
0505‑0966
0506‑0265
M750
1
Full skid plate; anodized black.
2
Some skid plates require more than one size clamp.
