All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
CHAINS
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
349
See our sprocket and chain configurator at
for a complete list of fitments.
DESCRIPTION
COLOR
PART #
420 HDR REPLACEMENT MASTER LINKS
Clip connecting link
Gold and steel
1225‑0231
Clip connecting link
Steel
1225‑0232
DESCRIPTION
COLOR
PART #
428 HDR REPLACEMENT MASTER LINKS
Clip connecting link
Gold and steel
1225‑0233
Clip connecting link
Steel
1225‑0234
TYPE
ROLLER
DIAMETER
PIN
LENGTH
INNER PLATE
THICKNESS
OUTER PLATE
THICKNESS
WEIGHT PER
100 LINKS
AVG. TENSILE
STRENGTH
PIN
RIVETING
HEAVY DUTY DRIVE CHAIN
420HDR 7,77 mm 15,05 mm 1,6 mm 1,6 mm 0,74 kg
1900 kg
2
428HDR 8,50 mm 18,30 mm 2,0 mm 2,0 mm 0,97 kg
2500 kg
2
RACE SERIES ‑ SUPER COMPETITION CHAIN
520HDR 10,16 mm 17,80 mm 2,0 mm 2,0 mm 1,46 kg
3680 kg
4
RACE SERIES ‑ ULTIMATE COMPETITION CHAIN
520HDS 10,22 mm 18,60 mm 2,2 mm 2,2 mm 1,56 kg
4020 kg
4
TYPE
ROLLER
DIAMETER
PIN
LENGTH
INNER PLATE
THICKNESS
OUTER PLATE
THICKNESS
WEIGHT PER
100 LINKS
AVG. TENSILE
STRENGTH
PIN
RIVETING
EXPERT SERIES ‑ HEAVY DUTY X‑RING DRIVE CHAIN
520X1R 10,22 mm 20,30 mm 2,0 mm 2,0 mm 1,55 kg
3700 kg
4
525X1R 10,22 mm 22,60 mm 2,2 mm 2,2 mm 1,89 kg
4050 kg
4
530X1R 10,22 mm 24,90 mm 2,4 mm 2,4 mm 2,08 kg
4200 kg
4
EXPERT SERIES ‑ SUPER HEAVY DUTY X‑RING DRIVE CHAIN
525Z1R 10,32 mm 23,70 mm 2,4 mm 2,6 mm 2,06 kg
4850 kg
4
530Z1R 10,32 mm 25,30 mm 2,4 mm 2,6 mm 2,15 kg
4850 kg
4
NUMBER OF LINKS
PART #
520 HDR STEEL
94
1220‑0174
96
1220‑0175
98
1220‑0176
100
1220‑0177
102
1220‑0178
104
1220‑0179
106
1220‑0181
NUMBER OF LINKS
PART #
520 HDR STEEL (CONT)
108
1220‑0182
110
1220‑0183
112
1220‑0184
114
1220‑0185
116
1220‑0186
118
1220‑0187
120
1220‑0188
NUMBER OF LINKS
PART #
520 HDR STEEL (CONT)
124
1220‑0189
520 HDR GOLD AND BLACK
94
1220‑0190
96
1220‑0191
98
1220‑0192
100
1220‑0193
102
1220‑0194
NUMBER OF LINKS
PART #
520 HDR GOLD AND BLACK (CONT)
104
1220‑0195
106
1220‑0196
108
1220‑0197
110
1220‑0198
112
1220‑0199
114
1220‑0200
116
1220‑0201
NUMBER OF LINKS
PART #
520 HDR GOLD AND BLACK (CONT)
118
1220‑0202
120
1220‑0203
124
1220‑0204
NUMBER OF LINKS
PART #
420 HDR STEEL
98
1220‑0112
100
1220‑0113
104
1220‑0114
108
1220‑0115
110
1220‑0116
112
1220‑0117
114
1220‑0118
116
1220‑0119
120
1220‑0120
122
1220‑0121
124
1220‑0122
126
1220‑0123
128
1220‑0124
130
1220‑0125
NUMBER OF LINKS
PART #
420 HDR STEEL (CONT)
132
1220‑0126
134
1220‑0127
140
1220‑0128
420 HDR GOLD AND BLACK
100
1220‑0129
104
1220‑0130
108
1220‑0131
114
1220‑0132
116
1220‑0133
120
1220‑0134
122
1220‑0135
124
1220‑0136
126
1220‑0137
130
1220‑0138
NUMBER OF LINKS
PART #
420 HDR GOLD AND BLACK (CONT)
134
1220‑0139
140
1220‑0140
428 HDR STEEL
100
1220‑0141
104
1220‑0142
108
1220‑0143
110
1220‑0144
112
1220‑0145
114
1220‑0146
116
1220‑0147
118
1220‑0148
120
1220‑0149
122
1220‑0150
124
1220‑0151
NUMBER OF LINKS
PART #
428 HDR STEEL (CONT)
126
1220‑0152
128
1220‑0153
130
1220‑0154
132
1220‑0155
134
1220‑0156
136
1220‑0157
140
1220‑0158
142
1220‑0159
146
1220‑0160
428 HDR GOLD AND BLACK
100
1220‑0161
104
1220‑0162
108
1220‑0163
110
1220‑0164
NUMBER OF LINKS
PART #
428 HDR GOLD AND BLACK (CONT)
112
1220‑0165
120
1220‑0166
122
1220‑0167
130
1220‑0168
132
1220‑0169
134
1220‑0170
136
1220‑0171
140
1220‑0172
142
1220‑0173
NUMBER OF LINKS
PART #
520 HDS STEEL
102
1220‑0205
104
1220‑0206
108
1220‑0208
110
1220‑0209
112
1220‑0210
NUMBER OF LINKS
PART #
520 HDS STEEL (CONT)
114
1220‑0211
116
1220‑0212
118
1220‑0213
120
1220‑0214
124
1220‑0215
NUMBER OF LINKS
PART #
520 HDS GOLD AND BLACK
102
1220‑0216
104
1220‑0217
106
1220‑0218
108
1220‑0219
110
1220‑0220
NUMBER OF LINKS
PART #
520 HDS GOLD AND BLACK (CONT)
112
1220‑0221
114
1220‑0222
116
1220‑0223
118
1220‑0224
NUMBER OF LINKS
PART #
520 HDS GOLD AND BLACK (CONT)
120
1220‑0225
124
1220‑0226
NUMBER OF LINKS
PART #
525 Z1R STEEL
122
1223‑0477
NUMBER OF LINKS
PART #
530 Z1R STEEL
102
1223‑0524
NUMBER OF LINKS
PART #
530 Z1R STEEL (CONT)
104
1223‑0525
NO. OF LINKS
MASTER LINK INCLUDED
PART #
520 X1R GOLD AND BLACK
74
Clip and rivet
1223‑0597
84
Clip and rivet
1223‑0599
86
Clip and rivet
1223‑0600
NO. OF LINKS
MASTER LINK INCLUDED
PART #
525 X1R STEEL
94
Rivet
1223‑0443
525 X1R GOLD AND BLACK
100
Rivet
1223‑0456
JT DRIVE CHAINS
•JT Chains produces a full range of superior quality motorcycle chains using leading-edge technology and only the highest grade of special steel alloys
•Specifications of the JT advanced power transfer chains meet or exceed the requirements of all modern motorcycles, street, MX, enduro, off road and ATV
•A full range of chain types, from 50cc mopeds to 200+ bhp superbikes, in steel or gold finish
•Leading edge technology in materials and production ensures top class performance, strength, and durability
•Specially engineered to favorably compare with all types and brands of motorcycle chain on the market
•Minimum weight at maximum strength
•HDR, HDS, X1R available in steel or gold and black finish
•Z1R available in steel or gold and gold finish
•For applications please use chain configurator at
RACE SERIES - HDR SUPER COMPETITION CHAIN
HDR HEAVY DUTY CHAIN
DRIVE CHAIN SPECIFICATIONS
EXPERT SERIES - Z1R SUPER HEAVY DUTY X-RING DRIVE CHAIN
EXPERT SERIES - X1R HEAVY DUTY X-RING DRIVE CHAIN
RACE SERIES - HDS ULTIMATE COMPETITION CHAINS
