BRAKE PADS AND SHOES WITH ABE continued on next page.
ORGANIC/KEVLAR
®
BRAKE PADS
•Made with DuPont
®
Kevlar
®
•Provide excellent stopping power without noise and rotor galling
•Fingertip control and strong, predictable brake response
“R” SINTERED METAL LONG-LIFE BRAKE PADS
•The perfect pads for leisure use
•Offer maximum durability and excellent braking performance
•Constructed of U.S.-made sintered bronze for longest lifetime
•Best for riding in water, mud, dust or sand
DOUBLE-H™ SINTERED METAL BRAKE PADS
•Feature the HH friction rating – the highest in the industry
•Provide maximum brake effect and last twice as long as organic pads
“EP” EXTREME PRO™ BRAKE PADS
•The latest in sintered metal brake pad fusion technology
•Has the highest friction rating possible – 0,6 – for strong, fade-free
stopping power
•Pad blend includes molybdenum metal and tungsten additives to enhance
friction performance for the life of the pad
•No lead, iron or steel additives; no more rotor outline etching or
rotor stiction
•Super-fast bed-in, full friction after 10 to 15 race stop uses
•Great heat cycle ability; pads cool after the race and perform just as strong
the next race day
“TT” SPORT CARBON BRAKE PADS
•Carbon graphite pads blended with Kevlar
®
for leisure/sport use
•Low price point
•Lowest heat generation
•Best for fast, dry riding; not for mud, water or sand
“MXS” RACE SINTERED BRAKE PADS
•High-performance pads perfect for racers
•Diamond-ground surface finish speeds up bed-in
•Constructed of U.S.-made sintered bronze for longest lifetime
“EP” EXTREME PRO™ BRAKE PADS
•The latest in sintered metal brake pad fusion technology
•Has the highest friction rating possible – 0,6 – for strong, fade-free
stopping power
•Pad blend includes molybdenum metal and tungsten additives to enhance
friction performance for the life of the pad
•No lead, iron or steel additives; no more rotor outline etching or
rotor stiction
•Super-fast bed-in, full friction after 10 to 15 race stop uses
•Great heat cycle ability; pads cool after the race and perform just as strong
the next race day
V-SEMI SINTERED METAL BRAKE PADS
•Semi-sintered construction containing 30% copper by weight within an
organic matrix
•This design combines the long life of a sintered pad with the great feel and
lack of rotor damage common with sintered pads
•Can be used to replace Kevlar
®
or sintered metal compound pads
STANDARD BRAKE SHOES
•Made using high-pressure die-cast aluminum platforms with bonded
brake linings
•All shoes are radius-ground and edge trimmed
•Feature lead-out chamfers at lining ends and original-style brake
shoe springs
“G” GROOVED BRAKE SHOES
•All the features of EBC standard brake shoes, plus multiple-angle
liner grooves designed to channel away dirt, dust, water and debris from
the braking surface area to improve performance and extend drum and
shoe life
NOTE: See cross reference charts on pages 404-406 and use EBC type numbers next to
the OE replacement pads.
NOTE: See footnotes in charts for TÜV/ABE part numbers.
See chart
for details
FITS MODEL
FRONT BRAKE
PAD/SHOE
PART #
FRONT EBC
PAD/SHOE
TYPE
REAR BRAKE
PAD/SHOE
PART #
REAR EBC
PAD/SHOE
TYPE
ACCOSSATO
50/80 Cross/Enduro 83-
1723-0310
6
841
1723-0310
6
841
C50 Cross/Enduro/Compet. 84-
1723-0310
6
841
1723-0310
6
841
CE50/80/KR 80 87-
FA47
047
1722-0163 116
EnduroCodice 50 89-
FA47
047
1722-0163 116
AGRALE
Elefantre30
FA47
047
-
-
AJP
7
PR3 125 Enduro 08-11
1720-0011
10
194
1722-0153 303
PR3 125 Enduro 12-14
1720-0011
10
194
-
-
FITS MODEL
FRONT BRAKE
PAD/SHOE
PART #
FRONT EBC
PAD/SHOE
TYPE
REAR BRAKE
PAD/SHOE
PART #
REAR EBC
PAD/SHOE
TYPE
AJP
7
(CONT)
PR3 125 Enduro Pro 08-11
1720-0011
10
194
1722-0153 303
PR3 125 Enduro Pro 12-14
1720-0011
10
194
-
-
PR3 125 Supermoto 08-11
1720-0011
10
194
1722-0153 303
PR3 125 Supermoto 12-14
1720-0011
10
194
-
-
PR3 125 Supermoto Pro 10-11
1720-0011
10
194
1722-0153 303
PR3 125 Trial 11-14
1720-0011
10
194
-
-
PR4 125 Enduro 04-09
1722-0609
167
1722-0153 303
BRAKE PADS AND SHOES WITH ABE
APPLICATION CHART
6
Non OE grooved shoe.
7
If Front pad listing is incorrect please check drawings for EBC#167 (2 pin fixing, no hook)
and EBC#465 (single pin fixing).
10
TÜV/ABE.
