676
FITS MODEL
TYPE
HEAD DIAMETER
OD X ID X HEIGHT
PART #
HONDA
CRF250R/X 04-14
Intake
34 mm
1,339” x 1,024” x 0,375”
0926-1625
CRF250R 04-09/X 04-14
Exhaust
29 mm
1,142” x 0,827” x 0,375”
0926-1621
CRF250R 10-14
Exhaust
28 mm
1,102” x 0,787” x 0,375”
0926-1620
CRF450R 02-14
Intake
38,5 mm
1,516” x 1,142” x 0,434”
0926-1627
CRF450R 02-08
Exhaust
35 mm
1,378” x 1,024” x 0,434”
0926-1626
CRF450R 09-12
Exhaust
34 mm
1,339” x 1,024” x 0,375”
0926-1625
KAWASAKI
KX250F 04-13
Intake
32 mm
1,260” x 0,945” x 0,374”
0926-1623
Exhaust
28 mm
1,102” x 0,787” x 0,374”
0926-1620
KLX450R 08-13
Exhaust
34 mm
1,339” x 1,024” x 0,375”
0926-1625
KX450F 06-13
Intake
39 mm
1,535” x 1,024” x 0,434”
0926-1628
Exhaust
35 mm
1,378” x 1,024” x 0,434”
0926-1626
SUZUKI
RM-Z250 04-13
Intake
32 mm
1,260” x 0,945” x 0,374”
0926-1623
Exhaust
28 mm
1,102” x 0,787” x 0,374”
0926-1620
DRZ-400 00-13
Exhaust
32 mm
1,260” x 0,945” x 0,374”
0926-1623
RM-Z450 08-13
Exhaust
33 mm
1,299” x 0,984” x 0,375”
0926-1624
YAMAHA
WR/YZ250F 01-13
Intake
25 mm
0,984” x 0,669” x 0,355”
0926-1619
1
Exhaust
28 mm
1,102” x 0,787” x 0,374”
0926-1620
1
YZ450F 03-09, WR450F 03-13
Intake
29 mm
1,142” x 0,827”x 0,375”
0926-1621
2
Exhaust
31 mm
1,220” x 0,906”x 0,375”
0926-1622
2
YZ450F 10-13
Intake
39 mm
1,535” x 1,181”x 0,434”
0926-1628
3
Exhaust
33 mm
1,299” x 0,984”x 0,375”
0926-1624
3
1
All years of the Yamaha YZ/WR250F are 5-valve engines using three intake seats and two exhaust seats.
2
The YZ450F 03-09 and WR450F 03-13 are 5-valve engines using three intake seats and two exhaust seats.
3
The YZ450F 10-13 bikes are 4-valve engines using two intake and two exhaust seats.
VALVE SEATS
FOR TITANIUM VALVES
•Copper-based material designed specifically for use with titanium valves in high performance applications
•Gives the seat excellent thermal characteristics as well as resistance to corrosion and wear
•These seats are the result of a two year KPMI R&D effort during which we recorded and verified results with
4 and 5 valve singles, multi cylinder street bikes, as well as British and European 4-strokes
•In each test the wear, thermal conductivity and machinability surpassed the standards we set for success
•These seats are used by succsessful builders around the world in all forms of racing
•Sold each
•Made in the U.S.A.
NOTE: All applications listed use two intake and two exhaust seats unless otherwise noted.
FITS MODEL
INTAKE
VALVE SEAL
EXHAUST
VALVE SEAL
HONDA
XR50 00-03
0926-0385 0926-0385
XR100R 85-03
0926-0386 0926-0386
XR200 83-02
0926-0386 0926-0386
CRF250R/X 04-09
0926-0381 0926-0382
XR/XL250 RFVC 83-95
0926-0386 0926-0386
XR250L 91-96
0926-0386 0926-0386
XR250 RFVC 96-00
0926-0386 0926-0386
CRF450 02-08
0926-0386 0926-0385
XR500/R 79-84
0926-0387 0926-0387
XL600R 83-00
0926-0387 0926-0387
XR600 85-00
0926-0387 0926-0387
XR650L 93-08
0926-0387 0926-0387
XR650R 00-07
0926-0387 0926-0387
FITS MODEL
INTAKE
VALVE SEAL
EXHAUST
VALVE SEAL
KAWASAKI
KLX250 94-07
0926-0384 0926-0384
KX250F 07-12
0926-0383 0926-0383
KLX300 94-07
0926-0384 0926-0384
KLX400 01-06
0926-0385 0926-0385
KLX650 93-96
0926-0388 0926-0388
KTM
450/540 00-07
0926-1666 0926-1666
SUZUKI
DR250 90-96
0926-0385 0926-0385
RMZ250 04-09
0926-0384 0926-0384
DR350S/SE 90-99
0926-0385 0926-0385
DRZ400 01-12
0926-0385 0926-0385
FITS MODEL
INTAKE
VALVE SEAL
EXHAUST
VALVE SEAL
YAMAHA
TTR250 99-06
0926-0385 0926-0385
YZ250F 02-12
0926-0390 0926-0389
XT250/350 84-00
0926-0386 0926-0386
WR/YZ400/426 98-02
0926-0391 0926-0392
YZ450F 03-09, WR450F 03-12 0926-0393 0926-0394
1
TT550 82-95
0926-0388 0926-0388
XT500 82-95
0926-0388 0926-0388
TT600 82-95
0926-0388 0926-0388
XT600 82-95
0926-0388 0926-0388
XTZ660/YTZ660 01-08
0926-2383 0926-2383
1
Pack of two.
PART #
STEM DIAMETER GUIDE DIAMETER OVERALL LENGTH SEAL O.D.
0926-0381
1
5,0 mm
-
-
-
0926-0382
1
5,0 mm
-
-
-
0926-0383
4,0 mm
0,285”
0,310”
0,375”
0926-0384
4,5 mm
0,325”
0,310”
0,375”
0926-0385
5,0 mm
0,340”
0,335”
0,395”
0926-0386
5,5 mm
0,285”
0,325”
0,425”
0926-0387
6,5 mm
0,475”
0,385”
0,560”
0926-0388
7,0 mm
0,475”
0,430”
0,565”
0926-0389
1
4,5 mm
-
-
-
0926-0390
2
4,0 mm
-
-
-
PART #
STEM DIAMETER GUIDE DIAMETER OVERALL LENGTH SEAL O.D.
0926-0391
2
4,5 mm
-
-
-
0926-0392
1
5,0 mm
-
-
-
0926-0393
2
4,5 mm
-
-
-
0926-0394
5,0 mm
-
-
-
0926-1666
5,0 mm
0,435”
0,315”
0,520”
0926-2383
6,0 mm
0,385”
0,360”
0,475”
1
Contains two seals.
2
Contains three seals.
VALVE SEALS
•All valve seals are made of 100% solid Viton for long life
•Meet or exceed OEM specifications
•When using Kibblewhite spring kits, Kibblewhite valve seals must be used because of spring clearances
•Sold individually; unless noted
•If specific application is not listed, use size chart to determine correct valve seal PART #
•Made in the U.S.A.
VALVE SEAL SPECIFICATIONS
