COLORWORKS MX RIMS AND REPLACEMENT SPOKES (CONT)
1
Must use OEM spokes and nipples for this model.
2
Hubs must be drilled.
3
Can use either Excel spokes and nipples or OEM spokes and nipples for this model.
4
May use OEM or Excel spokes.
5
Nipples are steel.
6
98-02 models must use OEM spokes and nipples; 03-05 models can use Excel or OEM spokes.
FITS MODEL
SIZE
BLACK
BLUE
GOLD
SILVER SPOKE SET PART #
ATK
All models 89-98
18 x 2,15 RKFEK410
1
-
RKFEG410
1
RKFES410
1
-
19 x 2,15 RKGEK410
1
-
RKGEG410
1
RKGES410
1
-
HONDA
XR50R 00-03
10 x 1,60 0210-0052
2
-
0210-0054
2
0210-0053
2
0211-0026
2
CRF50F 04-09, 11-12
10 x 1,60 0210-0052
2
-
0210-0054
2
0210-0053
2
0211-0026
2
CR80R 86-91
14 x 1,60 RKBCK405
3
-
-
RKBCS405
3
-
CR80R 92-02
14 x 1,60 RKBCK405
3
-
-
RKBCS405
3
XS0-11147
CR85R 03-07
14 x 1,60 RKBCK405
3
-
-
RKBCS405
3
XS0-11147
CR80R 96-02/85R BW 03-07
16 x 1,85 RKDDK405
3
-
-
RKDDS405
3
XS0-11167
CR125R/250R 89-01, CR500R 95-01
18 x 1,85 0210-0017 -
0210-0016 0210-0018 XS8-11187
18 x 2,15 RKFEK411 -
RKFEG411 RKFES411 XS8-11187
19 x 1,85 RKGDK411 -
RKGDG411 RKGDS411 XS8-11197
19 x 2,15 RKGEK411 -
RKGEG411 RKGES411 XS8-11197
19 x MT2,50 -
-
-
RKGFS412 -
CR125R/250R/F450R/X 02-04/CRF250X 04-05
18 x 1,85 0210-0017 -
0210-0016 0210-0018 0211-0003
18 x 2,15 RKFEK411 -
RKFEG411 RKFES411 0211-0003
19 x 1,85 RKGDK411 -
RKGDG411 RKGDS411 0211-0001
19 x 2,15 RKGEK411 -
RKGEG411 RKGES411 0211-0001
CR125R/CR250R 05-07, CRF250R 05-13, CRF450R 05-13, CRF250X 06-09, 12-13, CRF450X 05-09, 12-13 18 x 1,85 0210-0017 -
0210-0016 0210-0018 0211-0024
18 x 2,15 RKFEK411 -
RKFEG411 RKFES411 0211-0024
19 x 1,85 RKGDK411 -
RKGDG411 RKGDS411 0211-0025
19 x 2,15 RKGEK411 -
RKGEG411 RKGES411 0211-0025
CRF150F 03-09, 12-13
16 x 1,60 0210-0044
4
-
-
0210-0045
4
0211-0013
CRF150R 07-09, 12-13
14 x 1,60 RKBCK404 -
-
RKBCS404 0211-0037
CRF150RB (BW) 07-09, 12-13
16 x 1,85 RKDDK404 -
-
RKDDS404 0211-0038
CRF230F 03-09, 12-13
18 x 1,85 0210-0046 -
-
0210-0047 0211-0014
CR250R/CRF450R 02-04
18 x MT2,50 -
-
-
0210-0010 -
19 x MT2,50 -
-
-
RKGFS412 0211-0005
CR250R/500R 89-01
18 x MT2,50 -
-
-
0210-0010 -
XR250R 97-04
18 x 2,15 -
-
-
RKFES400 XS9-11187
XR400R 96-04
18 x 2,15 -
-
-
RKFES400 XS9-11187
18 x MT2,50 -
-
-
-
0211-0006
XR600R 93-06
18 x 2,15 -
-
-
RKFES400 XS9-11187
18 x MT2,50 -
-
-
-
0211-0006
XR650R 00-07/650L 93-09, 12-13
18 x 2,15 RKFEK400 -
-
RKFES400 XS9-11187
18 x MT2,50 -
-
-
-
0211-0006
KAWASAKI
KX60 85-03
12 x 1,60 -
-
-
0210-0002
3
XS0-21127
5
KX65 00-09, 11-13
12 x 1,60 -
-
-
0210-0013
3
XS0-22127
KX80 98-00/KX85 01-13, 11/KLX140 08-09, 11-13
14 x 1,60 RKBCK400
3
-
-
RKBCS400
3
XS9-21147
KX100 98-09, 11-13
16 x 1,85 RKDDK400
3
-
-
RKDDS400
3
XS9-21167
KLX110 02-13
12 x 1,60 0210-0042 -
-
0210-0043 0211-0015
KX125/250 89-02/KX500 89-05
18 x 1,85 -
RKFDD406 -
RKFDS406 0211-0008
18 x 2,15 RKFEK410 -
RKFEG410 RKFES410 0211-0008
19 x 1,85 RKGDK406
3
RKGDD406
3
RKGDG406
3
RKGDS406
3
XS8-21197
19 x 2,15 RKGEK410
3
-
RKGEG410
3
RKGES410
3
XS8-21197
KX125 03-05/KX250 03-07/KX250F 04-13/KX450 06-13/KLX450R 08-09
18 x 1,85 -
RKFDD406 -
RKFDS406 0211-0009
19 x 1,85 RKGDK406
3
RKGDD406
3
RKGDG406
3
RKGDS406
3
0211-0010
18 x 2,15 RKFEK410 -
RKFEG410 RKFES410 0211-0009
19 x 2,15 RKGEK410
3
-
RKGEG410
3
RKGES410
3
0211-0010
KDX200 89-06/KDX220R 97-05
18 x 2,15 RKFEK410 -
RKFEG410 RKFES410 XS9-21187
KDX250R 91-94
18 x 1,85 -
RKFDD406 -
RKFDS406 0211-0008
18 x 2,15 RKFEK410 -
RKFEG410 RKFES410 0211-0008
18 x MT2,50 -
-
-
0210-0014 XS8-23187
19 x 1,85 RKGDK406
3
RKGDD406
3
RKGDG406
3
RKGDS406
3
XS8-21197
19 x 2,15 RKGEK410
3
-
RKGEG410
3
RKGES410
3
XS8-21197
19 x MT2,50 -
-
-
-
XS8-22197
KX250 89-02/KX500 89-04
18 x MT2,50 -
-
-
0210-0014 XS8-23187
19 x MT2,50 -
-
-
-
XS8-22197
KLX250R 94-96/KLX300R 97-07
18 x 2,15 RKFEK410 -
RKFEG410 RKFES410 XS8-22187
18 x MT2,50 -
-
-
0210-0014 -
KLX400R 03-04
18 x 2,15 RKFEK410
3
-
RKFEG410
3
RKFES410
3
XS8-31187
KLX400SR 03-04
18 x 2,15 RKFEK410
3
-
RKFEG410
3
RKFES410
3
XS8-32187
KLX650R 93-96
18 x 2,15 RKFEK410 -
RKFEG410 RKFES410 XS8-22187
18 x MT2,50 -
-
-
0210-0014 -
KTM
125/200/250/300/400/450/520/525 03-07 (all)
18 x 2,15 RKFEK422
6
RKFED422
1
RKFEG422
6
RKFES422
6
0211-0019
18 x MT2,50 RKFFK422
6
-
-
RKFFS422
6
-
19 x 1,85 0210-0004
6
-
0210-0003
6
0210-0005
6
0211-0020
19 x 2,15 RKGEK422
6
RKGED422
1
RKGEG422
6
RKGES422
6
0211-0020
REAR RIMS AND SPOKE SETS
