P-12 LIFT STANDS
•Rubber top with embossed logo and raised bumpy non-slip surface
•Most adjustable lift stand available
•Adjusts to 11 height positions from 24 cm to 37 cm high (9
1
/
2
” to 14
1
/
2
”)
•Designed for dirt bikes from 50-650cc
•Easily lifts bikes by stepping on foot lever
•Even youth riders can put their own bike on this stand
•Foot-activated release trigger with nylon slider block
•Made of high-quality aircraft aluminum
•Large heavy-duty top lifts both wheels off the ground
•Large recessed rivets won’t break off
•Super-strong lower legs constructed from box aluminum tubing
•Legs are arched with flat ends for stability on uneven ground
•Leg stance is 40,5 cm (16”) wide for maximum stability
•Available in silver anodized or six hard-coat factory colors: black, red, blue, green, orange or yellow
826
COLOR
PART #
Silver
4110‑0014
Black
4110‑0015
COLOR
PART #
Red
4110‑0016
Blue
4110‑0017
COLOR
PART #
Green
4110‑0018
Orange
4110‑0063
COLOR
PART #
Yellow
4110‑0064
LAY-OVER STAND
•Safer and more secure method for holding
a bike in a leaning position; resting bikes
on MX stands can tear grips and damage
expensive upper fork tubes
•Keeps bike off the ground,
eliminating the chance of damaging
valuable components
•Choose from seven grip height adjustments
from 33 cm (13”) to 48,5 cm (19”) tall –
works with most mini-bikes to full-size
off-road bikes
•Notched grip cradle design compatible
with Bark Busters
•Aluminum and stainless steel construction –
rust-resistant and great for power-washing those hard
to reach areas
•Easier access to front and rear rebound suspension adjusters
•Quick clutch maintenance without draining transmission oil -
saves time between races
•Easier way to install or remove
engine skid plates
•Lightweight and folds compact;
easy to transport
DESCRIPTION
PART #
Lay‑over stand
4101‑0350
PRO MX
SCISSOR LIFT
•Professional-quality hydraulic scissor lift for dirt
bikes from 50cc-650cc
•Heavy-duty steel frame construction will last forever
•No bending over – two foot pedals incorporated to lift
and lower stand
•No loose parts – attached secure footpeg springs
tighten automatically to pegs when stand rises to help
stabilize bike
•Raises between 35,5 cm to 84 cm (14” to 33”), lifts
motorcycle to a comfortable work height
•Large 35,5 cm x 40,5 cm (14” x 16”) oil- and
gas-resistant top
•Access hole in top measuring 76 mm x 18 cm (3” x 7”)
•Adjustable Safety Pin sets at multiple heights
allowing for extra security
•Black and silver powder-coated finish
•181 kg (400 lb) max lift capacity
DESCRIPTION
PART #
MX Scissor Lift
4110‑0022
MX SHOCK
LIFT STAND
•Integrated shock absorber lowers
bike at a safe, controlled speed to
help prevent sudden drops
•Works great for almost all dirt bikes
and mini-bikes
•Fully adjustable from 24 cm to 34,5
cm tall (9
1
/
2
” to 13
1
/
2
”)
•Wide lever design allows bike to
be raised or lowered easily using
only one foot
•Stand top raises 76 mm (3”) when foot pedal is
pushed down and lever is locked in the up position
•Quick-release safety latch incorporated to lock stand in up position
•Non-slip, oil and gas resistant rubber top
•Four end caps raise the bottom frame off the ground for more
stability on uneven terrain
•Maximum weight capacity of 159 kg (350 lb)
•Available in black
DESCRIPTION
PART #
MX shock lift stand
4110‑0060
