FLUID PRO KNEE BRACE SET
•CE-certified CE 1621-1 K Type B
•Lightweight, strong and is constructed from
a high-performance glass fiber compound to offer
optimized structural integrity and frame strength
•Features a lightweight ‘exoskeleton’, reduced material
construction design
•Highly ventilated channeled padding and mesh zones for
optimized ventilation and airflow
•25 percent lighter than current B2 brace versions
•Extreme temperature resilience: performs at temperatures as low
as -4°F (-20°C)
•Designed to provide a highly customizable, personalized and stable
fit: SAS (size adapter system): provides adjustable and versatile
brace fitment in size ranges S-M-L and XL-XXL
•Innovative spacer system: brace supplied with leg-size adjustment
spacers (1 mm, 2 mm and 3 mm) on either side of hinge, plus two
pairs of flexible, anatomically optimized ‘ergo-fit’ spacers (6 mm
and 9 mm) for improved directional articulation performance
•Knee pivot system: new double-pivoting hinge system
incorporating tool-free, fast, easily exchangeable extension stops
(0, 5, 10, 15, 20 degrees) to prevent hyperextension injuries
•Incorporates a bio-organic engineering design for superb
anatomical performance: innovative patella/knee cup protection
system is an ergonomically sculptured, ventilated knee cup system
constructed from semi-rigid TPU backed by shock absorbing PU
memory foam
•Correct position of knee cup is secured accurately in place with top
and bottom elastic straps, allowing multi-directional freedom
of movement
•Additional protection in strongly angled positions afforded by
upper and lower patella cuffs
•Innovative, dual X-strap system promotes secure fitment of brace in all riding positions and includes combined
buckle and hook-and-loop closures for rapid and easy mounting
FLUID TECH CARBON KNEE BRACE
•CE-certified CE 1621-1 K Type B
•Lightweight and strong, the brace is constructed from an advanced
high-performance carbon polymer compound
•Optimized structural integrity and frame strength: the Fluid Tech features
a lightweight ‘exoskeleton’ reduced material construction design
•Highly ventilated: channeled padding and mesh zones for optimized
ventilation and airflow
•Crucial weight-saving: the Fluid Tech is 40 per cent lighter than current B2
brace versions
•Extreme temperature resilience: Fluid Tech performs at temperatures as
low as -4°F (-20°C)
•The Fluid Tech is designed to provide a highly customizable, personalized
and stable fit: SAS (size adapter system) provides adjustable and versatile
brace fitment in size ranges S-M-L and XL-XXL
•Innovative spacer system: brace is supplied with leg-size adjustment
spacers (1 mm, 2 mm and 3 mm) on either side of hinge, plus two pairs
of flexible, anatomically optimized ‘ergo-fit’ spacers (6 mm and 9 mm) for
improved directional articulation performance
•Knee pivot system: New double-pivoting hinge system incorporating tool-
free, fast, easily exchangeable extension stops (0, 5, 10, 15 or 20 degrees) to
prevent hyperextension injuries
•Incorporates a bio-organic engineering design for superb
anatomical performance
•Innovative patella/knee cup protection system is an ergonomically
sculptured and ventilated knee cup system constructed from semi-rigid TPU
backed by shock-absorbing PU memory foam
•Correct position of knee cup is secured accurately in place with top and
bottom elastic straps, allowing multi-directional freedom of movement
•Additional protection in strongly-angled positions afforded by upper and lower patella cuffs
•Innovative, dual X-strap system promotes secure fitment of brace in all riding positions and includes combined buckle and hook-and-loop
closures for rapid and easy mounting
DESCRIPTION
COLOR
PART #
Buckles
Red
2704-0325
Dual strap kit
Black
2704-0326
DESCRIPTION
COLOR
PART #
Extension stops
Red
2704-0327
Lateral spacer pads
Black
2704-0328
DESCRIPTION
COLOR
PART #
Adjustment spacers Black
2704-0329
Hinge cover stickers Black Metallic Brush
2704-0330
SIZE
PART #
S/L
2704-0323
SIZE
PART #
XL/XXL
2704-0324
FLUID PRO KNEE BRACE SPARE PARTS
SIZE
RIGHT
LEFT
S/L
2704-0319
2704-0321
SIZE
RIGHT
LEFT
XL/XXL
2704-0320
2704-0322
DESCRIPTION
COLOR
PART #
Buckles
Red
2704‑0325
Dual strap kit
Black
2704‑0326
DESCRIPTION
COLOR
PART #
Extension stops
Red
2704‑0327
Lateral spacer pads
Black
2704‑0328
DESCRIPTION
COLOR
PART #
Adjustment spacers Black
2704‑0329
Hinge cover stickers Black Metallic Brush
2704‑0330
FLUID TECH CARBON KNEE BRACE SPARE PARTS
