251
motorska zaščitna stikala do 100 A
1) pomožni kontakt, montiran s strani, 2-polni
2) signalni kontakt (S0 ... S3), montiran s strani
3) sprožnik
4) pomožni kontakt, montiran s čelne strani
5) vtični kabeljski čevelj za vijačno pritrditev
6) z glavnim pomožnim kontaktom za podnapetostni sprožnik
7) predloga vrtanja
8) standardnamontažna letev TH 35 po EN 60715
9) zamontažo po EN 60715 na TH 35 standardnomontažno letev, 15mm globine, ali TH 75 standardnomontažno letev
10) imbus vijak 4mm
11) možnost zaklepa v nevtralni poziciji 3,5 ... 4,5mm premer obešanke
5/21
Siemens LV1T · 2008
5
General data
■
Dimensional drawings
3RV1motor starter protectors, sizeS00
3RV1motor starter protectors, sizeS0
3RV1motor starter protectors, sizeS2
3RV1motor starter protectors, sizeS3
1) Sidemounted auxiliary switch, 2-pole
2) Signaling switch (S0 ... S3) sidemounted
3) Auxiliary tripunit
4)
auxiliary switch
5) Push-in lugs for screwmounting
6)With leading auxiliary switch only for undervoltage release
7) Drillingpattern
8) Standardmounting rail TH35 according toEN60715
9) Formounting according toEN60715 on TH35 standardmounting rail,
15mmdeep, or TH75 standardmounting rail
10) Allen screw 4mm
11) Lockable in neutral positionwith 3.5 ... 4.5mm shacklediameter
3RV1011, 3RV16
3RV1021, 3RV1321, 3RV14 21
3RV1031, 3RV13 31, 3RV1431
20
55
18 9
18
45
85
109
121
127
5
8
132
144
140
89
125
1) 2)
3)
4)
8)
11)
5
30
130
7)
3RV104, 3RV134
Front mounted
w
mere
motorska zaščitna stikala, velikost 00
BESD
motorska zaščitna stikala, velikost 2
Bes2
motorska zaščitna stikala, velikost 3
Bes3
motorska zaščitna stikala, velikost 0
BES0
