pribor za Kontaktorje, velikost 0–12 – nadaljevanje
Opis
napetost tuljave
Šifra
pribor za velikost 0–12
povezovalni vmesnik zamotorska zaščitna stikala BES2, velikost 2
in kontaktor velikost 2
za AC
LSZ2D004
povezovalni vmesnik zamotorska zaščitna stikala BES2, velikost 2
in kontaktor velikost 2
za DC
LSZ2D005
povezovalni vmesnik zamotorska zaščitna stikala BES3, velikost 3
in kontaktor velikost 3
za DC
LSZ3D003
povezovalni vmesnik zamotorska zaščitna stikala BES3, velikost 3
in kontaktor velikost 3
za AC
LSZ3D004
povezovalni vmesnik, 4-polni za velikost 2 do S2
LSZ2W002
povezovalni vmesnik, 4-polni za velikost 3 do S3
LSZ3W002
povezovalni vmesnik, 3-polni za velikost 2/3/6 do 2/3/6
LSZ2W003
mehanski zapah za velikost 0-2,
ostane v položaju „VKLOP“pr izpadu krmilne napetosti
24VAC/DC
LSZ00113
prekritje priključkov za velikost 2*
LSZ2D002
prekritje priključkov za velikost 3*
LSZ3D002
prekritje priključkov za velikost 6*
LSZ6D001
prekritje priključkov - kratka verzija za velikost 6*
LSZ6D002
prekritje priključkov za velikost 10*
LSZED001
prekritje priključkov - kratka verzija za velikost 10*
LSZED002
* naročite 2 kosa za en kontaktor, naročite 1 kos samo za eno stran kontaktorja (priključki zgoraj/spodaj)
