All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
EXHAUST
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
39
IMPORTANT NOTE:
SEE PAGE 5 FOR IMPORTANT INFORMATION REGARDING CERTAIN WARRANTY AND EMISSION CONTROL REGULATORY
COMPLIANCE INFORMATION.
LENGTH OF SILENCER SHELL
19 CM (7,5”)
23 CM (9”)
25,5 CM (10”)
29 CM (11,5”)
33 CM (13”)
40,5 CM (16”)
2‑STROKE
BILL’S PIPES
250 Race Silencer
‑
MFRR2‑0009E
MFRR2‑0010
MFRR2‑0115
‑
‑
DOMA
Race Silencers
MFRR2‑0075E
MFRR2‑0009E
MFRR2‑0010
MFRR2‑0115
‑
‑
FMF
Power Core 2/Titanium 2
MFRD1‑0075
MFRD1‑0875
‑
MFRD1‑1175
MFRD1‑0135
MFRD1‑0016
Turbine Core 2/Q 2‑Stroke
1
MFRD1‑0075
MFRD1‑0875
‑
MFRD1‑1175
MFRD1‑0135
‑
PRO CIRCUIT
R304 Std. / R304 Race
MFRR2‑0075E
MFRR2‑0009E
MFRR2‑0010
MFRR2‑0115
‑
‑
296 Silencer
1
MFRD1‑0075
MFRD1‑0875
‑
MFRD1‑1175
MFRD1‑0135
‑
4‑STROKE
YOSHIMURA
RS‑4
‑
‑
1860‑0537
‑
‑
‑
1
When choosing a repack kit for a spark arrester silencer, subtract 14 cm (5,5”) from the length of the muffler body for the actual packable length and order based on that length.
Example: An FMF Turbine Core 2 with a 35,5 cm (14”) L body will have an 21,5 cm (8,5”) packable length. Order the next longest length. Use this rule for Pro Circuit also.
FITS MODEL
PART #
HONDA 2‑STROKE
CR80R/85 Expert 96‑07
MFRD1‑0875
CR125R 93‑07
MFRD1‑1025
CR250R 92‑07
MFRD1‑1175
HONDA 4‑STROKE
CRF250R 07‑09
1860‑0172
CRF450R 02‑03
1860‑0091
1
CRF450R 04‑08
1860‑0033
CRF450R 09‑10
1860‑0534
KAWASAKI 2‑STROKE
KX65 02‑11
1860‑0090
KX80/85/100 91‑11
MFRD1‑1025
KX125 02‑05
MFRD1‑1025
KX125 96‑01
MFRD1‑1175
KX250 96‑02
MFRD1‑1175
KX250 03‑07
MFRD1‑1025
KAWASAKI 4‑STROKE
KX250F 04‑08
1860‑0050
KX450F 06‑10
1860‑0091
1
KTM 2‑STROKE
50/60/65 ADV, SX 02‑12
1860‑0097
85/105 SX, XC 03‑12
MFRR2‑011F
1
125 SX 00‑05
MFRR2‑011F
1
125 SX 06
1860‑0123
150 XC 10
1860‑0123
FITS MODEL
PART #
KTM 2‑STROKE (CONT)
125/200/250/300/380 EXC, MXC 98‑05
MFRD1‑0016
200/250/300 XC‑W 06‑10
1860‑0124
200/250/300 XC‑W 11‑12
1860‑0536
250 SX 04‑06
1860‑0123
250 SX 07‑10
1860‑0533
200 XC 06‑07
1860‑0123
200 XC 08‑09
1860‑0533
250/300 XC 06
1860‑0123
250/300 XC 07‑09
1860‑0533
250/300 XC 10
1860‑0124
250/300 XC 11‑12
1860‑0536
KTM 4‑STROKE
250 EXC‑G 03‑04
MFRE1‑0115
1
250 XCF‑W 06‑07
1860‑0055
250 XCF‑W 08‑10
MFRE1‑0115
1
250 SX‑F 05‑06
1860‑0055
250 SX‑F 07, 09, 11‑12
1860‑0092
250 SX‑F 08, 10
1860‑0535
250 XC‑F 08‑09
1860‑0055
400/450/520/525/530 EXC, EXC‑GR, MXC,
MXC‑G 01‑08
MFRE1‑0115
1
400/450/520/525/530 XCR‑W, XC‑W,
SMR 01‑08
MFRE1‑0115
1
400/450/525 SX, SX‑F, XC, XC‑G 01‑07, 11‑12 1860‑0055
FITS MODEL
PART #
KTM 4‑STROKE (CONT)
450/505 XC‑F 08‑09
1860‑0055
450 SX‑F 08‑10
1860‑0535
400/450/530 XC‑W.EXC.SMR 09‑12
MFRE1‑0115
1
505 SX‑F 08
1860‑0535
SUZUKI 2‑STROKE
RM80/85 89‑10, 12
MFRD1‑0075
RM125 96‑07
MFRD1‑1025
RM250 96‑08
MFRD1‑1175
SUZUKI 4‑STROKE
RM‑Z 250 04‑06
1860‑0050
RM‑Z 450 05‑07
1860‑0091
1
YAMAHA 2‑STROKE
YZ80/85 93‑12
MFRD1‑1175
YZ125 96‑12
MFRD1‑1175
YZ250 96‑12
MFRD1‑0135
YAMAHA 4‑STROKE
YZ250F 01‑05
MFRE1‑1013
YZ250F 06‑08
1860‑0033
YZ250F 09
1860‑0538
YZ400/426 98‑02
1860‑0095
YZ450F 03‑05
1860‑0096
YZ450F 06‑07
1860‑0091
1
YZ450F 08‑09
1860‑0173
1
1
Packing comes flat, not pre‑rolled.
DESCRIPTION
FOR MUFFLERS WITH SHELL LENGTHS UP TO 38 CM (15”)
FOR MUFFLERS WITH SHELL LENGTHS FROM 38 CM‑51 CM (15”‑20”)
Competition Pillow
1860‑0573
1860‑0574
Universal Spec 31 Pillow
1860‑0471
1860‑0472
CUT-TO-LENGTH PILLOWS FOR AFTERMARKET 4-STROKE EXHAUSTS
•Pillows are designed to pack all mufflers with core diameters between 44,5 mm-57,2 mm (1,75”-2,25”) and shell circumferences between 30,5 cm (12”) and
34,5 cm (13,5”)
•Measure the distance around the outside of the muffler’s shell to determine its circumference
COMPETITION REPACK CARTRIDGES
•Offer consistent packing density
•Cut installation time in half
•25% lighter than stock packing
•Last 5-10 times longer than glass mat packing
•Outer casing made from carbon-coated fiber, which remains intact for removal of used part
•If noted in chart, these parts were designed flat due to the OEM attaching wool to the core
or a fixture on the core that prevents the pre-rolled cartridge from being slid onto the core
•Made in the U.S.A.
NOTE: Part numbers given above are for unmodified aftermarket exhausts. If the muffler has been
modified from the original length and falls between lengths available on the chart, order the next longest cartridge available for your muffler.
FOR AFTERMARKET SILENCERS
FIBERGLASS
MUFFLER PACKING
•Repack blown-out silencer
for more power and a
quieter ride
•Long-filament fiberglass made
especially for muffler packing
•Measures 26,5 cm x 40,5 cm (10,5” x 16”), more than
enough to repack virtually any 2-stroke silencer
•Resists breakdown up
to 649°C (1200°F)
•Made in the U.S.A.
PART #
M701
UNIVERSAL STAINLESS REPACK KIT
•Louder exhaust does not mean more horsepower
•Blown-out packing causes exhaust turbulence and increased
backpressure, which reduces horsepower
•Re-pack your silencer with this pro-quality, three layer
packing system and restore the power you’ve blown out
•Also great for getting in compliance with new sound laws
•Kit contains 6,4 mm (
1
/
4
”) thick 152 cm x 51 cm (60” x 20”) glass
mat, 18 cm x 51 cm (7” x 20”) stainless wool; 20,5 cm x 51 cm
(8” x 20”) stainless mesh, twelve 4,8 mm (
3
/
16
”) rivets,
and full instructions
•Made in the U.S.A.
PART #
1860-0037
