IMPORTANT NOTE:
SEE PAGE 729 FOR IMPORTANT INFORMATION REGARDING CERTAIN WARRANTY AND EMISSION CONTROL REGULATORY
COMPLIANCE INFORMATION.
PART #
1020-1606
FITS MODEL
DESCRIPTION
PART #
KTM
250/350 SX‑F/XC‑F 11‑12
White
2106‑0144
Orange
2106‑0145
Blue
2106‑0146
HUSABERG
FE 390/450/570 09‑11
White
2106‑0144
Orange
2106‑0145
Blue
2106‑0146
EFI SWITCHES
•Change the way the electronic fuel injection behaves
•3-position design to quickly move between stock, mild
and wild based on what the environment demands
•Plug into stock connectors
•Kill switch integrated
TRIGA iBOOST2
•Developed by TRIGA Engineering, a company from the Netherlands that uses state-of-
the-art 3D software and top-level technical knowledge to engineer, develop and produce
high performance fuel injection systems
•Now available at Pro Circuit, TRIGA’s iBoost2 is an off-the-shelf, easy-to-install throttle
body enhancement kit that will give you more power and better throttle response
•Kits include TRIGA’s Throttle Body Insert (TRIGA-TBI) and TRIGA Butterfly Valves (TRIGA-TBV)
•TRIGA-TBI improves the volumetric efficiency of the engine by applied Pressure Wave
Tuning (PWT)
•Up and down running pressure wave in the intake system is tuned to ensure the positive peak of the pressure
wave is there when the intake valve opens
•Using the TRIGA tubular insert will slightly reduce the overall flow area, which will allow enhanced speed over the valve while timing the pressure waves
for low and mid-range power improvements
•On the track, using the TRIGA butterfly valve will increase top-end power – the TRIGA tubular insert will utilize some of this extra power and distribute it
over the entire rpm range
•The flow-engineered butterfly valves and shaft are CNC-precision-machined from steel, which allows for less material use and optimal shape to eliminate
high-end flow loss by lowering flow restriction
•Throttle control via the butterfly valve is known for its low-flow loss up to 75% of TPS; the high range flow is more restricted because the valve is still
horizontally present
•The TRIGA butterfly valve reduces the restriction in the throttle body, which decreases the overall pressure drop over the throttle body at full throttle
•This results in higher velocity for improved fuel droplet breakup. This also improves the fuel-air mixture while allowing more air mass flow to enter the
combustion chamber – more air, more fuel, more power
•On the track, using the TRIGA butterfly valve will increase top-end power; the TRIGA tubular insert will utilize some of this extra power and distribute it
over the entire rpm range
•Kits offer two installation configurations
•Option 1 can significantly increase horsepower in low, mid and top range
•Option 2 can significantly increase horsepower in top range
•Easy-to-use and install
•Significant increase in torque and power throughout the power band
•Throttle body insert improves the volumetric efficiency of the engine
•Butterfly valve and shaft eliminates high-end flow loss by lowering flow restriction
•Can be installed and uninstalled without damaging the OEM throttle body
•Allows for significantly better throttle response
•No service necessary after installation
•Can be installed in a stock bike without changing the fuel mapping or tuning
•TRIGA TPS Tool (sold separately) is needed to recalibrate the TPS sensor after installing the
TRIGA valve and shaft; correct TPS sensor calibration is essential to the performance of the IBoost2
PART #
3804-0037
TRIGA TPS TOOL
FITS MODEL
PART #
HONDA
CRF250R/450R 13
1020‑2010
KAWASAKI
KX250F 13
1020‑2009
KX450F 13
1020‑2008
FITS MODEL
PART #
KTM
250 SX‑F 13
1020‑2014
350/450 SX‑F 13
1020‑2015
SUZUKI
RM‑Z250 09‑13
1020‑2011
RM‑Z450 08‑13
1020‑2012
FITS MODEL
PART #
YAMAHA
YZ250F 14
1020‑2254
YZ450F 10‑13
1020‑2013
YZ450F 14
1020‑2253
POWER COMMANDER III USB
FOR HONDA XL 700V 08
•USB (Universal Serial Bus) port provides an instant and automatic connection to the Power
Commander Control Center software; simply power up the unit and connect the PC III USB
to the computer with the supplied cable
•Provides precise information for fine-tuning a fuel-injected motorcycle when
changing an air filter, installing a new exhaust system or doing additional engine
performance modifications
•Each unit includes a built-in microprocessor and a specific map designed to improve
engine performance over stock; Dynojet continuously maps new calibrations for each bike
for downloading at their web site (
•If you do not have a computer, you can change the settings with three touch buttons on
the faceplate
•OEM-style wiring connectors with improved harness protection are supplied; no wiring
modifications required
•Includes easy-to-follow instructions
•Direct injector control technology manages the fuel curve on models that do not have the
sensors to monitor fuel adjustment
•Features an expansion port for future add-on modules from Dynojet
•Software is compatible with Windows 2000/XP/Vista and Windows 7
•USB special cable and 9V battery power adapter are included
•Made in the U.S.A.
NOTE: Not legal for sale or use on pollution controlled vehicles.
