IMPORTANT NOTE:
SEE PAGE 729 FOR IMPORTANT INFORMATION REGARDING CERTAIN WARRANTY AND EMISSION CONTROL REGULATORY
COMPLIANCE INFORMATION.
FITS MODEL
PART #
HONDA
CRF250R 10‑11
1010‑0957
CRF250R 12‑14
1010‑1126
CRF450R 09‑10
1010‑1019
CRF450R 11‑12
1010‑1020
FITS MODEL
PART #
KAWASAKI
KX250F 09‑10
1010‑0960
KX250F 11
1010‑0961
KTM
250 SX‑F 11‑12
1010‑1127
FITS MODEL
PART #
KTM (CONT)
250 SX‑F 13‑14
1010‑1128
350 SX‑F 11‑14
1010‑1128
SUZUKI
RM‑Z250 10‑11
1010‑0958
FITS MODEL
PART #
SUZUKI (CONT)
RM‑Z450 08‑12
1010‑1117
RM‑Z450 13
1010‑1390
YAMAHA
YZ250F 10‑13
1010‑0959
AIR4ORCE TUNABLE INTAKE SYSTEM
•Change power characteristics to match rider preference and track
conditions using interchangeable velocity stacks
•Depending on the selected velocity stack, the rider will experience
increased bottom and mid-range power (longer stack) or
mid- to top-range power (shorter stack)
•Improved throttle response with either stack installed
•Velocity stacks function as resonating pipes; the length of the pipe alters the dynamic tuning range by adjusting
the frequency of pressure pulses within the tract
•System includes AIR4ORCE tunable intake system, two velocity stacks, detailed instructions and hose clamps and gaskets (for models that require them)
1010-0957
1010-1127
“THE ORIGINAL” POWER BOWL
•Better than fuel injection; the Power Bowl eliminates
unpredictable carburetor hesitation
•Bolt-on product requires no modification
•Delivers instant throttle response, improved acceleration, easier starting and better
holeshots while eliminating hesitation and bogging
•The Power Bowl’s zero-tolerance jet chamber redirects fuel during hard impacts and
creates maximum fuel exposure during the most extreme conditions, which eliminates the
possibility of the jets being exposed to air pockets and therefore eliminates misfiring
•The anti-cavitation accelerator pump is designed with two separate fuel ports; port one is
located at the highest point in the chamber to allow trapped air to escape through the leak
jet orifice, while port two is positioned low in the fuel sump to ensure that only fuel enters
the Venturi
•Externally adjustable leak jet allows fine tuning with a simple hand adjustment
•Ball check valve is located at the bottom of the pump cover for more consistent fuel supply;
stock steel ball has been replaced with nylon for better response time during hard impacts
•Kit includes Power Bowl with easy tune leak jet, accelerator pump cover, O-rings, linkage
spring, diaphragm spring, R&D sticker and instructions
•Works with all 4-stroke MX bikes
FITS MODEL
PART #
For Keihin FCR carbs
1050‑0154
FITS MODEL
PART #
Keihin carb with check valve equipped models
1050‑0155
QUICKSHOT 2 ACCELERATOR PUMP COVERS
•QuickShot’s patent pending design eliminates hesitation and bog on bikes and ATVs and provides
instant response to throttle movements
•Additional benefits are reduced hot engine stalling and improved low end performance
•Bolt-on product for all Keihin FCR carbs that requires no modifications; use PART #1050-0155 on Honda
CRF250F 07-09, CRF250X 07-12, CRF450 07-12
DESCRIPTION
PART #
For all Keihin FCR‑Equipped MX, Off Road
and ATV models
1050‑0225
For KTM 250 SX‑F 07‑09
1050‑0258
QUICKSHOT 3
FOR ALL KEIHIN
FCR-EQUIPPED
MX, OFF-ROAD
AND ATV MODELS
•Tunable leak jet
maximizes volume
of fuel and duration
of squirt for all conditions
•Investment cast and finished to precise tolerances
•25% more fuel capacity
•High-volume vertical check valve located in the QS3
for precise, consistent fuel metering
•Stops hesitation and bog
•Instant throttle response
•Improved low-end performance
•Fits ALL Keihin FCR carbs
•Simple bolt-on installation
DESCRIPTION
PART #
For all Keihin FCR‑equipped MX, off‑road and ATV models
1050‑0228
For KTM 250 SX‑F/XC‑F 05‑10, KTM 450 SX‑F 07‑10, KTM 450 XC‑F 08‑09
1050‑0235
QUICKSTART
FOR ALL KEIHIN
FCR-EQUIPPED MX, OFF-ROAD
AND ATV MODELS
•The most effective way to add performance
to a Keihin FCR carburetor
•Integrated Hot Start Assist eliminates
problem 4-stroke hot start procedure
•Tunable leak jet maximizes volume of
fuel and duration of fuel spray for
all conditions
•25% more fuel capacity
•High-volume vertical check valve located in
the QS3 for precise, consistent fuel metering
•Patented design stops bogging and improves
throttle response
•Improved low-end performance
•Investment cast and finished to precise tolerances
•Fits ALL Keihin FCR carbs
•Simple bolt-on installation
PART #
1050-0199
