KILL SWITCH HOW TO ORDER
NOTICE TO CUSTOMERS: There are two types of stop switches: (1) Normally Open (NO) or (2) Normally Closed (NC).
Switches in this catalog are typically of the Normally Open (NO) type. They work by GROUNDING the primary ignition lead when activated.
Note that they will not work on electrical systems requiring a Normally Closed (NC) switch, which works by OPENING the circuit when activated.
NC switches are typically used on battery type ignitions, which may have an ignition key as an identifier. NC switches are generally found on
newer machines. If in doubt, check your machine’s wiring schematic.
PART #
PS-15
UNIVERSAL KILL SWITCH
•Works only when pushed; stops working when
you let off
•Mounts on handlebars
PART #
S-20
UNIVERSAL TOGGLE SWITCH
•Three-way toggle switch; middle is off
•Great switch for turn signals, etc.
PART #
S10
DOO DAD SWITCH
•Single-throw, double-pole toggle switch turns
accessories on and off with ease
•Can be wired to turn one thing on and another off
•Clamps on 22 mm (
7
/
8
”) bars and is rated for 6A at 6V, 12V and 14V
PART #
0616-0021
KILL SWITCH
TETHER LINE
•Kills engine when rider
falls off
•Attaches easily
•Normally closed
DESCRIPTION
PART #
NORMALLY OPEN SWITCH
Kill switch for 22,2 mm handlebars (
7
/
8
”)
2106‑0053
Kill switch for 28,6 mm handlebars (1
1
/
8
”)
2106‑0054
NORMALLY CLOSED SWITCH FOR BATTERY‑TYPE IGNITION
Kill switch for 22,2 mm handlebars (
7
/
8
”)
DS‑305502
Kill switch for 28,6 mm handlebars (1
1
/
8
”)
2106‑0042
REPLACEMENT TETHERS
Optional tether cord w/ wristband
2106‑0030
Repl. tether cord w/ clip
DS‑305504
TETHER KILL
SWITCHES
•Handlebar-mount tether
kill switch protects your expensive
motor from over-revving
•Complete with a clipped tether cord that
extends to 127 cm (50”)
•Optional tether cord is easy to attach and offers
a hook-and-loop adjustable wristband that will fit over gloves
•Two-piece handlebar mount clamps around handlebars; available for
22,2 mm (
7
/
8
”) or 28,6 mm (1
1
/
8
”) handlebars
•Available for normally closed battery-type ignition models and normally
open electrical system models
•Made from billet aluminum with water-resistant, stainless steel
internal components
•Made in the U.S.A.
2106‑0030
2106‑0042
DS‑305504
DESCRIPTION
PART #
NORMALLY OPEN SWITCH
Red
GK1011
Blue
GK1012
Black
GK1013
NORMALLY CLOSED SWITCH FOR
BATTERY‑TYPE IGNITION
Red
2106‑0004
DESCRIPTION
PART #
NORMALLY CLOSED SWITCH FOR
BATTERY‑TYPE IGNITION (CONT)
Blue
2106‑0005
Black
2106‑0006
REPLACEMENT LANYARDS
Black
GK1023
GUNNAR KILL
SWITCHES
•Tether kill switch is
easy to install; plugs into most electrical systems
•Narrow design; installs on slightly curved portion
of the bars
•Weatherproofed housing; matching lanyard included
•Normally Open switch is the open type; works by grounding the primary
ignition lead when activated
•Normally Closed switch works the opposite of Normally Open and is
designed for use on newer, more complex electrical systems
•Replacement lanyards available separately and fit both switches
DESCRIPTION
PART #
HANDLEBAR‑MOUNTED TETHER KILL SWITCHES (FIT 22,2 MM HANDLEBARS (
7
/
8
”))
For non‑battery models, closes circuit when pulled
2106‑0147
For electric‑start models, opens circuit when pulled
2106‑0148
HANDLEBAR CLAMP‑MOUNTED TETHER KILL SWITCHES
For non‑battery models, closes circuit when pulled
M96955
For electric‑start models, opens circuit when pulled
2106‑0002
UNIVERSAL
TETHER KILL
SWITCHES
•Kills motor if rider falls off
•Required in many forms
of competition
COLOR
PART #
Black/black
PD100
COLOR
PART #
Red/black
PD102
COLOR
PART #
Blue/black
PD103
PART #
PD150BLK
LANYARD KILL SWITCH
•Handlebar mount
•The #1 quality lanyard kill switch used
by professionals
•Works with both NO/NC systems if instructions are followed
•Replacement lanyard made to fit Pro Design kill switches; available
in black only
KILL SWITCHES
REPLACEMENT LANYARD (BLACK ONLY)
GK1012
2106‑0004
2106‑0006
GK1023
PD100
PD102
PD103
2106‑0148
M96955
