All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
ELECTRICAL & GAUGES
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
552
DESCRIPTION SOCKET EU SOCKET PART #
1156/BA15S
Clear
1156
BA15S
2060‑0150
Red
1156
BA15S
2060‑0072
Amber
1156
BA15S
2060‑0074
1157/BAY15D
Clear
1157
BAY15D
2060‑0068
Red
1157
BAY15D
2060‑0070
DESCRIPTION SOCKET EU SOCKET PART #
1157/BAY15D (CONT)
Red
1157
BAY15D
2060‑0351
1
Amber
1157
BAY15D
2060‑0153
3156/W2,1X9,5D
Clear
3156
W2,5x16D
2060‑0350
Red
3156
W2,5x16D 2060‑0073
Amber
3156
W2,5x16D 2060‑0075
DESCRIPTION SOCKET EU SOCKET PART #
3157/W2,5X16DQ
Clear
3157
W2,5x16DQ 2060‑0069
Red
3157
W2,5x16DQ 2060‑0071
Amber
3157
W2,5x16DQ 2060‑0154
1
This bulb is 7,9 mm (
5
/
16
”) longer than standard 1157/
BAY15D bulbs, with 20 LEDs for maximum brightness.
QUARTZ LIGHTS
•12V quartz halogen lights
manufactured by Candlepower
come complete with H-4 P43T 60/55W bulbs
•Twice the illumination of standard sealed beams
•Available in 14,5 cm and 18 cm styles
(5
3
/
4
” and 7”)
HALOGEN BULBS
•Quartz halogen bulbs
replace standard-type bulbs
with SA (H4 P43T) or BA (H4 P45T) base
•Available in standard-power 60/55W and
higher-powered versions
•Heavy-duty types available for extra vibration resistance
•All are 12V
ROTATING AND
PULSATING RED
LED BRAKE/
TAILLIGHT
•It rotates, it pulsates, it’s red
•Replaces standard 1157/BAY15D bulb
•Clear LEDs turn brilliant red when illuminated
•As taillight, LEDs simulate rotating bulb
•When actuated as brake light, LEDs pulse more than twice per second
•For use only with battery system
NOTE: For off-road or show use only.
PART #
2120-0429
H4 BULB WIRING
CONNECTOR
•For changing headlight to H4
bulb, replacement and custom
application
DESCRIPTION
PART #
H4 P43T BASE
35/35W
48220
60/55W
01009
60/55W heavy-duty
6260HD
100/55W
01019
100/55W heavy-duty
6263
100/80W
01021
100/80W heavy-duty
6265
DESCRIPTION
PART #
H4 P45T BASE
60/55W
6255H
60/55W heavy-duty
6361
100/55W heavy-duty
6255HP
100/80W heavy-duty
6365
BAY15D BASE
50/15W
H1157-BP
TYPE
PART #
14,5 cm (5
3
/
4”
) round lamp DS‑280009
TYPE
PART #
18 cm (7”) round lamp
DS‑280007
DESCRIPTION PART #
55W
Standard
H755
DESCRIPTION PART #
100W
Standard
H7100
DESCRIPTION PART #
100W (CONT)
Super white
H7100SW
HEADLAMP BULBS
H7 BASE
•Available in standard-power 55W and higher-powered
100W versions
•12V, 55W lamps meet SAE specifications for street use;
100W lamps are a special, higher-wattage version of
the H755 (100W versus 55) and are for off-road use
•Superwhite lamps use a proprietary superwhite coating
to produce a whiter, brighter light
•Sold each
LED TAILLIGHT BULBS
•Revolutionary 360° design of LEDs around the base of the bulb
•Only LED taillight that will function in any mounting position and on any application
•Made of the highest-quality LEDs to emit the most light possible
•LEDs draw extremely little electricity, are vibration resistant and last up to 10.000 hours of use
•1156 and 1157 have round metal bases and the 3156 and 3157 have flat plastic bases
•Sold each
REF. # STYLE # SOCKET
EU
SOCKET VOLTS
WATTS OR
CANDLEPOWER
BLISTER PACK
QUANTITY PART #
A‑62
A
BA9s
6V 3W
2
A62‑BP
A‑72
A
BA9s
12V 3,4W
2
A72‑BP
GE53
A
53
BA9s
12V 1C
2
53‑BP
A‑1272 B
A‑1272
12V 2W
2
A1272‑BP
1156‑BP C
1156 BA15s
12,8V ‑
2
2060‑0235
GE93
C
93
BA15s
12,8V L5C
2
93‑BP
A‑4513 C
BA15s
6V 21C
2
A4513‑BP
A‑4527 C
BA15s
12V 32C
2
A4527‑BP
A‑4813 D
BAY15d 6V 17/5,3W 2
A4813‑BP
GE1034 D
1034 BAY15D 14V 32/3C
2
1034‑BP
‑
D
BAY15d 12V 21/5W
2
7528‑BP
GE1157 D
BAY15D 12,8V 32/3C
2
1157‑BP
A‑4829 D
BAY15D 12V 32/3C
2
A4829‑BP
GE1016 D
1016 BAY15D 14V 21/6C
2
1016‑BP
1
A‑5649 E
P15d30 6V 35/35W 1
A5659‑BP
GE67
F
67
BA15s
13,5V 4C
2
67‑BP
GE89
F
89
BA15s
13V 6C
2
89‑BP
GE97
F
97
BA15s
13,5V 4C
2
97‑BP
GE57
G
57
BA9s
12V 2C
2
57‑BP
GE1895 G
1895 BA9s
14V 2C
2
1895‑BP
GE68
H
68
BA15d 13,5V 4C
2
68‑BP
1156A‑BP I
1156 BA15S 12,8V ‑
2
2060‑0236
2
GE194 J
194 W2.1x4,9d 14V 2C
2
194‑BP
GE1004 K
1004 BA15d 12,8V 15C
2
1004‑BP
REF. # STYLE # SOCKET
EU
SOCKET VOLTS
WATTS OR
CANDLEPOWER
BLISTER PACK
QUANTITY PART #
GE1889 L
1889 BA9s
14V 2C
2
1889‑BP
‑
M 7443 W3x16q 13,5V ‑
2
2060‑0163
‑
N 9005 P20d 12,8V 65W
1
2060‑0164
3
6235J
O
P15‑d‑3 12V 35/35W 1
6235J‑BP
6245J
O
P15d‑3 12V 45/45W 1
6245J‑BP
6260J
O
P15d‑3 12V 60/60W 1
6260J‑BP
A‑7025 O
P15d‑3 12V 35/35W 1
A7025‑BP
6235B P
BA20d 12V 35/35W 1
6235B‑BP
6245B P
BA20d 12V 45/45W 1
6245B‑BP
6260B P
BA20d 12V 60/60W 1
6260B‑BP
6235Y Q
P15d30 12V 35/35W 1
6235Y‑BP
6245Y Q
P15d30 12V 45/45W 1
6245Y‑BP
6260S R
P36t
12V 60/60W 1
6260S‑BP
6260SA S
P43t38 12V 60/60W 1
6260SA‑BP
6245BA T
P45t41 12V 45/45W 1
6245BA‑BP
6260BA T
P45t41 12V 60/60W 1
6260BA‑BP
H1155‑BP U
PGJ19‑2 12V 55W
1
2060‑0245
3
‑
V
BAY15D 12,8V 32/3C
1
2060‑0255
2
A‑3625 W
PX15d 6V 25/25W 2
A3625‑BP
A‑3603 W
PX15d 12V 25/25W 2
A3603‑BP
A‑3598H W
PX15d 6V 15/15W 2
A3598H‑BP
HM202 X
12,8 36,5/55
1
2060‑0349
‑
Y
1157 BAY15D 12V 50/15W 1
H1157‑BP
3
1
Also substitutes for GE1035.
2
Amber.
3
Halogen.
MOTORCYCLE BULBS
•All bulbs are packaged in blister packs and sold per pack; number of bulbs per package is listed in chart
U
V
X
T
R
W Y
PART #
1157R
H7100
H7100SW
2060‑0070
2060‑0071
K
D
L
J
M
N
I
G
P
O
Q
H
F
C
B
E
A
S
DS‑280009
