All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
ELECTRICAL & GAUGES
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
543
VAPOR/
STRIKER
INDICATOR
LIGHT
DASHBOARD
•Includes installation hardware; installs easily to triple clamp
of most motorcycles
•Fits Vapor and Striker Trail Tech computers
•Includes eight indicator lights for customization: low
beam, high beam, turn arrow left, turn arrow right, turn
arrow left and right (hazard), oil, N, R
VAPOR/STRIKER HANDLEBAR
MOUNTING HARDWARE
•Replaces handlebar mounting hardware
found in each Vapor/Striker computer kit
•Fits 22 mm to 28,6 mm handlebars (
7
/
8
” to 1
1
/
8
”)
FITS MODEL
PART #
HONDA
CR250R, CRF250R/450R 04-14
2212-0221
CRF250X/450X 04-14
2212-0222
XR650R 00-13
2212-0223
HUSABERG
TE 125/250/300 11-14
2212-0217
FE/FX 390/450/570 09-14
2212-0217
501e 00-08
2212-0217
FS 570 12
2212-0217
HUSQVARNA
CR/TC 125/250/449/450 09-13
2212-0217
WR 125/250/300 09-13 (2-stroke)
2212-0217
TE 250/310/400/449/511 09-13 (4-stroke)
2212-0217
TXC 250/449/511 08-13 (4-stroke)
2212-0217
FITS MODEL
PART #
HUSQVARNA (CONT)
TXC 450/TE 610 08
2212-0217
TE 400-610 05-09 (4-stroke)
2212-0224
KAWASAKI
KX125/250/250F 04-14
2212-0219
KLX400 00-11 (radiator screw sensor)
2212-0403
KX450F 04-14
2212-0219
KLX450 08-09
2212-0219
KTM
SX/MXC/EXC/XC/XC-W 04-07
(radiator screw temp sensor)
2212-0216
SX/MXC/EXC/XC/XC-W 00-14
(radiator hose temp sensor)
2212-0217
FITS MODEL
PART #
SUZUKI
RM125/250, RM-Z250/450 00-07 (all)
2212-0219
RM-Z250/450 08-14
2212-0403
DR-Z400 00-13 (radiator screw sensor)
2212-0403
YAMAHA
YZ/WR125/250/250F/400F/426F/450F 95-04
2212-0218
YZ/WR125/250/250F/450F 05-14
2212-0219
TTR225/TTR230/TTR250 00-12
(front disc brake only)
2212-0402
WR250R/X 08-13
2212-0224
GENERIC INVERTED FORKS
All years
2212-0224
GENERIC CONVENTIONAL FORKS (AIR-COOLED)
All years
2212-0402
VAPOR SPEEDOMETER/TACHOMETER COMPUTER
•Speed, temp, distance, tach and clock
•Speedometer functions: current, average, maximum; selectable MPH/KM/H
•Temperature functions: ambient temp, engine temp with LED alerts, dual programmable temp lights,
exact model fit temp sensors; selectable F/C scale
•Distance functions: adjustable distance, permanent odometer; selectable mile/kilometer
•Tachometer functions: real-time rpm bar graph, numeric rpm readout, dual programmable shift
lights; up to 20.000 rpm
•Clock functions: hour meter, stop watch, ride time; selectable 12/24 hour display
•Includes universal power connector for all machines and accepts AC and DC power
•Waterproof design with high-intensity LCD white backlight display
DESCRIPTION
PART #
Vector remote switch
2106-0065
Vapor/Striker indicator light dashboard
2201-0064
Vapor/Striker triple clamp mounting bracket
2201-0065
Vapor/Striker flat surface mount protector
2201-0066
DESCRIPTION
PART #
Vapor/Striker direct bolt protector
2201-0067
Vapor/Striker lower mount protector
2201-0068
Vapor/Striker handlebar mounting hardware
2201-0069
VAPOR/STRIKER ACCESSORIES
VAPOR/STRIKER
LOWER MOUNT
PROTECTOR
•Fits motorcycles and
ATVs with anti-vibe
steering stems: 100-103
mm bolt spacing
VAPOR/STRIKER
DIRECT BOLT
PROTECTOR
•Bolts directly to the top of
the triple clamp using stock
or provided hardware
•Fits OEM mounts for XR650R
VAPOR/STRIKER FLAT
SURFACE MOUNT
PROTECTOR
•Bracket mounts computer to
front of triple clamp of most
off-road motorcycles
•Adaptable for mounting to any
flat surface
VAPOR/STRIKER TRIPLE CLAMP
MOUNTING BRACKET
•Protect your Trail Tech computer and place
it in an optimum viewing position
•Mounts computer to front of triple clamp
of most off-road motorcycles
•Adaptable for custom applications
STRIKER REMOTE SWITCH
•Enables rally mode and lap timer mode for
the Trail Tech Striker computer
•In rally mode, enduro style distance
adjustments are as simple as pressing a
button on the remote switch
•In lap timer mode, compare lap times on
the fly or review recorded information
after the race
2212‑0216
2201‑0068
2201‑0069
2201‑0067
2201‑0066
2106‑0065
2201‑0064
2201‑0065
