544
EQUINOX LED 35 MM LIGHT KITS
•LED light kits built rugged for off-road use
•Feature 800 lumens output in a tight, well-designed form
•Focused, forward lighting allows extreme visibility in night-time conditions
•Button-selectable high, medium and low output
•Hardened glass lenses, vibration isolation and machined aluminum
bodies for long life
•Specs: 12W/6W/3W power draw; 6h/12h/24h run time (with 6600mAh battery);
800 lumens; measure 46 mm x 81 mm (1,8” x 3,2”); weight 167 g
(5,9 oz.); 6300K beam color; 12V DC polarity
•Optional three-piece mounting kit (PART #2201-0128, sold separately) contains
three mounts: for handlebar, flat surface and helmet (handlebar mount fits 22 mm - 29 mm bars (
7
/
8
” - 1
1
/
8
”))
•12W, 15° spot
•Black color
DESCRIPTION
PART #
Two‑light kit w/ two handlebar and two surface mounts
2040‑0792
One‑light kit w/ handlebar and surface mount
2040‑0793
DESCRIPTION
PART #
One‑light kit w/ post mount
2040‑0794
Opt. three‑piece mounting kit
2201‑0128
ELECTRICAL SYSTEMS
•Increase the amount of power available for lighting
•Wattages listed indicate power available for lighting at 3.000 rpm
DESCRIPTION
PART #
SWITCHES
Water‑resistant on/off light switch, black (fits 10 mm (
3
/
8
” hole))
2106‑0066
Three‑position (Hi/Lo/Off) bar‑mount light/kill switch
2106‑0138
WIRING HARNESSES
Wire harness for Trail Tech SC4, MR16 and LED lights
(includes push button switch)
2106‑0140
Wire harness for Trail Tech SC4, MR16 and LED lights
(includes handlebar‑mounted button switch)
2106‑0141
ELECTRICAL ACCESSORIES/
REPLACEMENT PARTS
2060‑0182
2106‑0066
2112‑0613
DESCRIPTION
PART #
REGULATORS AND RECTIFIERS
AC regulator, universal voltage
2112‑0613
LED BULB
19 LED replacement bulb; draws 1W; replaces any 1157 socket; bright red 2060‑0182
2201‑0128
2040‑0793
FITS MODEL
DESCRIPTION
PART #
HONDA
CRF150R/RB 07-09
70W DC system; includes stator, reg/rec, battery, battery bag, flywheel
2112-0626
70W AC system; includes stator, regulator, flywheel
2112-0627
CRF250R 04-09
40W DC system; includes stator, reg/rec, 3.5 amp hour batter and wiring harness
2112-0347
70W DC system; includes stator, reg/rec, battery, battery bag, flywheel
2112-0621
70W AC system; includes stator, regulator, flywheel
2112-0622
CRF250R 10-14
70W DC system; includes stator
2112-0625
70W DC system; includes stator, reg/rec, battery, battery bag
2112-0985
CRF250X 04-09
40W DC system; includes stator, reg/rec
2112-0623
70W DC system; includes stator, reg/rec, flywheel
2112-0624
CRF450R 02-04
40W DC system; includes stator, reg/rec, 3.5 amp hour batter and wiring harness
2112-0346
70W DC system; includes stator, reg/rec, battery, battery bag, flywheel
2112-0619
70W AC system; includes stator, regulator, flywheel
2112-0620
CRF450R 05-08
40W DC system; includes stator, reg/rec, 3.5 amp hour batter and wiring harness
2112-0347
70W DC system; includes stator, reg/rec, battery, battery bag, flywheel
2112-0621
70W AC system; includes stator, regulator, flywheel
2112-0622
CRF450X 05-09
100W DC system; includes stator, reg/rec
2112-0629
120W DC system; includes stator, reg/rec, flywheel
2112-0630
CRF450R 09
90W DC system; includes stator, flywheel
2112-0628
CRF450R 10-12
70W DC system; includes stator
2112-0625
90W DC system; includes stator, reg/rec, battery, battery bag, flywheel
2112-0986
KTM
200/250 EXC/MXC/XC/XC-W 02-07
120W AC system; includes stator, regulator, flywheel backing plate
2112-0618
1
,
2
250 XCF/XCF-W 06-10 (with 4K3B ignition)
100W DC system; include stator, reg/rec and connectors (battery required; not included)
2112-0344
250/300 2-strokes 08-10 (with 2K-3 ignition, no backing plate)
100W DC system; include stator, reg/rec and connectors (battery required; not included)
2112-0345
250/350 XC-F/SX-F 11-14
70W DC system; includes stator
2112-0983
250/380 SX 02-10
120W AC system; includes stator, regulator, flywheel backing plate
2112-0618
1
300/380 EXC/MXC/XC/XC-W 00-07, 200 XC/XC-W 08-12
100W DC system; includes stator with backing plate, reg/rec
2112-0984
1
400/450/525/530 XC-W/EXC/MXC/XCF-W/EXC-R 02-10 (with 4K3B ignition)
100W DC system; include stator, reg/rec and connectors (battery required; not included)
2112-0344
4
400/450/520/525/560 SX/SXS/SMR 02-07
120W DC system; includes stator, reg/rec, flywheel
2112-0614
1
,
3
120W AC system; includes stator, regulator, flywheel, side case
2112-0615
1
450/505 SXF 07-10
90W DC system; includes stator, flywheel
2112-0616
450/505 XC-F 08-09
90W DC system; includes stator, flywheel
2112-0616
450 SMR 08
90W DC system; includes stator, flywheel
2112-0616
450/525/530 EXC-Racing, EXC-R/EXC Champions Edition 07-10
100W DC system; includes stator, reg/rec
2112-0617
YAMAHA
WR250F 03-05, WR450F 03-04
100W DC system; includes stator, reg/rec
2112-0632
WR250F 06-09, WR450F 05-09
100W DC system; includes stator, reg/rec
2112-0631
1
Requires wire harness PART #2120-0376 and NiMH battery PART #2113-0099 for DC systems.
2
250 SX 00-06 requires wire harness PART #2120-0376, NiMH battery PART #2113-0099 and side case for stator upgrade.
3
Side case battery or capacitor required but not included.
4
Not for 450/530 EXC-R 07-09.
