All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
ELECTRICAL & GAUGES
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
539
FITS MODEL
PART #
HONDA
CRF50F/XR50R 00‑13
2101‑0085
CRF70F/XR70R 97‑13
2101‑0085
CRF80F/100F, XR80R/100R 94‑13 2101‑0085
CRF150F 03‑05/CRF230F 03‑14 2101‑0084
CRF150F 06‑14
2101‑0167
FITS MODEL
PART #
KAWASAKI
KLX110 02‑09
2101‑0120
SUZUKI
DR‑Z110 03‑05
2101‑0120
REV BOX
•Replacement CDI units with hotter advance curve
•Eliminates rev-limiter on Honda models and raises rev limiter by 1000 on
Kawasaki and Suzuki and for optimum performance
PART #
DRL-300CDI
STANDARD REV
LIMITER
•Designed to work with small engine CDI ignitions with a grounding-type
kill switch
•Works with most dirt bikes and snowmobiles, but is not compatible with
Arctic Cat models, which use a different method for killing spark
•As shipped, limiter is set up for single-cylinder applications; can be
adjusted for up to 8-cylinder engines
•Continuously adjustable from 6.000 to 12.000 rpm
•Smooth, precise limiting action
•Complete directions for installation are included
FITS MODEL
PART #
HONDA
CRF250R 07
2102‑0140
CRF450R 07
2101‑0155
SUZUKI
DR‑Z400 00‑09
2102‑0147
1
FITS MODEL
PART #
SUZUKI (CONT)
DR‑Z400 00‑09
2102‑0148
DR‑Z400SM 06‑09
2101‑0222
YAMAHA
YZ250F 06‑08
2101‑0160
FITS MODEL
PART #
YAMAHA (CONT)
YZ450F 06‑08
2101‑0157
WR450F 03‑06
2101‑0196
WR450F 07‑09
2101‑0195
1
Non‑programmable.
DYNA FS
PROGRAMMABLE
IGNITION SYSTEMS
•Plug-in replacement module with four
programmable advance curves that
provide improved torque and 800% more
spark energy for easier starts
•Four programmable timing curves
•3D advance curves on TPS-equipped bikes
•One programmable rev limit per ignition curve
•Improved throttle response
•Easy to mount
•Programming kit sold separately
PART #
2101-0056
DYNA FS IGNITION SYSTEM
FOR HONDA XR50R 00-03/XR80R 85-03
•Plug-in replacement module provides improved torque
and 800% more spark energy for easier starts
•Improved throttle response
•Easy to mount
DYNA FS
PROGRAMMING
KIT
•Quick, user-friendly and everything you need to
reprogram the Dyna FS programmable ignition
•Easy-to-understand interface, simple saving,
recalling and printing of curves
•Includes software to reprogram all available Dyna FS Programmable
Ignition models and the programming cable
•Not recommended for inexperienced tuners
PART #
DFSPK-1
CURVEMAKER
PROGRAMMING
KIT/HARNESS
•Contains CurveMaker software,
harness to connect the Dyna
2000 to the computer’s serial
port and a 9V battery
•Software comes pre-loaded
with standard Dyna 2000 4-cylinder default curves
•Software allows the advance/retard curves and rev-limit to be
reprogrammed to specification
DESCRIPTION
PART #
Dirt bike with serial port
2101‑0154
DESCRIPTION
PART #
Offroad with USB connection 2101‑0205
FITS MODEL
PART #
HONDA
CRF450R 09
2102‑0168
FITS MODEL
PART #
KAWASAKI
KLX450R 08
2102‑0143
COIL KIT
•High-output minicoil includes
all necessary mounting
hardware, wiring adapters and
spark plug wires
PART #
2101-0323
IGNITION BOOSTER
MODULE
•Boost ignition power in
points-equipped motorcycle
•Improves performance by transferring
inconsistent electrical surges into precisely
controlled bursts of energy to the coil for more thorough
and efficient combustion
•No more burned points; current reduced to 0,1 amp
•Unaffected by dirt, moisture, oil or vibration
•Ultra fast spark voltage rise time; 50% faster than points
•Extends spark plug life
2101-0154
2102-0143
2101-0160
2102-0140
2101‑0120
2101‑0084
