532
PART #
2212-0182
MOTOMINDER HOUR METER
•Automatically records and displays your engine’s accumulated run time, so oil changes,
piston, rings, valves, spark plugs, etc. can be serviced at the correct maintenance schedule
•Correct schedule saves costly engine damage from service neglect, but Motominder can
also save money from servicing too frequently
•Powered by the vehicle’s electrical system by simply cable tying its power line along the
spark plug lead or direct connecting to the kill switch wire
•Smallest engine hour meter available (approximately 25 mm x 38 mm (1” x 1,5”)); doesn’t
require additional mounting brackets and can be easily mounted by the peel-and-stick
method to the frame or other convenient area
•Records the installation date, and displays this briefly whenever the engine is started; on
start-up it displays hours of runtime for 1 minute, flashes the runtime every 10 seconds
while the engine is running and also displays runtime at power down
for 2 minutes, so riders have plenty of time to get
their helmets off before checking the display
PART #
2212-0404
GET C1 HOUR METER
•Works off the engine vibrations – no wires needed
•Calculates total and partial hour count (total hour count up
to 999 hours)
•Resettable partial hour count
•Big, clear, easy-to-read display
•Integrated zip-tie slot design in case
•Waterproof, resistant housing
•Measures 68 mm L x 34 mm W x 16 mm D
iMETER™ WIRELESS
HOUR METER
•The most advanced, accurate, reliable hour meter
made and the quickest and easiest to install
•There are no connections required
•Automatically starts and stops from the running of your engine by sensing
the resonance of the motor
•No wiring required; no power, ground or pick-up wire required – just peel
and stick
•Includes resettable trip as well as total hours accumulated modes
•Includes double-sided tape and mounting screws
•Waterproof; shock-resistant
•Built-in battery has 5-7 year lifespan
•Comes with log book to track the service life – oil changes, valve
adjustments, spark plugs, settings, etc.
•Records and displays to 9.999,9 hours
•Hourglass symbol automatically appears when engine is running and
flashes on/off to indicate counting time
•Push button to display data when engine is not running
•Resolution 0,1 hour
•Works on any motorcycle, ATV/UTV or PWC automatically; 2- or 4-stroke
•Made with solid-state electronics, modern LCD; iMETER has superb
environmental durability and enhanced functionality, making it the best
choice of all possibilities without sacrifice to performance, operation
or budget
•Made with ROHS compliant components
•CE Certified; IP-68 Rating
•Designed, assembled and
packaged in the U.S.A.
PART #
2212-0425
DESCRIPTION
PART #
Resettable hour meter
2212‑0399
Steering stem mount for hour meter
2212‑0292
RESETTABLE HOUR METER/TACHOMETER
WITH LOG BOOK
•Resettable timer and service modes that flash service messages at 5, 10
and 20 hours of operation
•Real time reading of Tach up to 20k rpm; records max rpm
•Also keeps track of total time accumulated
•Keeps track of important maintenance times for your bike including oil
changes, valve adjustments, spark plugs, etc.
•Includes log book to write down oil changes, valve service, chassis
lubrication, clutch service and suspension setting notes
•Usable with any gas engine
•Records and displays up to 9.999,9 hours
•Just peel and stick or attach with enclosed hardware
•Connects to spark plug wire; no batteries are needed
•Hours automatically roll over
•Safely and completely encased in 100% epoxy
•Mount for hour meter available separately
•CE Certified; IP-68 Rating; made with ROHS-compliant components
2212‑0292
2212‑0399
