530
MINI 3 AIR/FUEL
RATIO METER
•Allows riders to monitor and adjust
air/fuel mixture for more power and
peak performance
•Specially designed to help tune carbureted
or fuel-injected 4-stroke engines
•Easy installation to 12V systems by
connecting the sensor to the exhaust system
•Includes gauge unit, sensor, bung and cap
•Dimensions: 30,5 mm (1,2”) L x
60,5 mm (2,4”) W x 12,3 mm (0,5”) D
PART #
1050-0276
MINI 3
AMP AND
VOLT
METER
•Developed with the best components and the
latest technology
•Displays vehicle voltage and amps used
•Voltage warning indicator when the volt is below DC
11,5V or above 15,5V
•Especially useful when there are many
electrical accessories
•Compact and lightweight design
•Gauge comes complete with electric current sensor
•Dimensions: 60,5 mm (2,4”) W x 30,5 mm (1,2”) L x
12,3 mm (0,5”) D
PART #
2212-0488
MINI 3 OIL PRESSURE GAUGE
•Helps avoid major mechanical problems by
allowing the rider to keep a watchful eye on the
vehicle’s oil pressure
•By watching the pressure gauge, riders can be
sure their vehicle is being properly lubricated
•Features an oil pressure warning that flashes
when oil pressure drops
•Lightweight, compact design makes this gauge a
perfect complement to the actual gauge cluster
•Gauge comes complete with needed sensor
•Dimensions: 60,5 mm W x 30,5 mm L x 12,3 mm D
(2,4” x 1,2” x 0,5”)
PART #
2212-0489
MINI 3 AMBIENT TEMP/
CLOCK/VOLT METER
•Helps monitor the basics for planning a ride
•Check battery voltage with
low-voltage indicator
•Large display clock is easily read while riding
•Ambient temperature gives a good reference
on how to dress properly for a ride
•Dimensions: 60,5 mm (2,4”) W x
30,5 mm (1,2”) L x 12,3mm (0,5”) D
PART #
2212-0486
PART #
2211-0109
MINI TACHOMETER
AND HOUR METER
•Compact, easy-to-read LCD display
•Tachometer function displays within 0-15000 rpm
range (100 rpm resolution)
•Hour meter function displays total hours (1 hour
resolution) and two resettable hour meters (0,1
hour resolution)
•Records max rpm
•Battery life time is 1.000 hours
•Measure 34 mm H x 61 mm W x 15 mm D (1,33” x
2,42” x 0,61”)
PART #
2212-0248
MINI
ENGINE
HOUR
METER
•Easy-to-read digital display
•Display shows total hours (1 hour resolution)
and two resettable hour meters
(0,1 hour resolution)
•Starts to record one second after ignition and
sleeps 30 seconds after input stops
•Internal battery holds memory for 180 days
without a charge
•Measures 61 mm W x 34 mm H x 15 mm D
(2,42” x 1,32” x 0,61”)
PART #
2212-0251
MINI THERMOMETER
•Compact thermometer with easy-to-read,
backlit display
•Changeable internal battery
•Records top temperature
•Measures 61 mm W x 34 mm H x 15 mm D
(2,42” x 1,32” x 0,61”)
•Includes water temperature sensor
DESCRIPTION PART #
M10 x P1,0 2212‑0284
M12 x P1,5 2212‑0285
M14 x P1,25 2212‑0286
DESCRIPTION PART #
M14 x P1,5 2212‑0287
M16 x P1,5 2212‑0288
OIL TEMPERATURE SENSORS
•Available in a multitude of sizes for
any application
DESCRIPTION
PART #
10 mm
2212‑0309
14 mm
2212‑0310
10 mm w/ waterproof JST connector
2212‑0376
14 mm w/ waterproof JST connector
2212‑0377
CYLINDER HEAD
TEMPERATURE SENSORS
•0-250°C range (32-482°F)
•For 10 mm or 14 mm cylinder head studs
•Also available with waterproof JST connector
2212-0309
2212‑0376
DESCRIPTION PART #
14 mm
2212‑0276
16 mm
2212‑0277
18 mm
2212‑0278
DESCRIPTION PART #
22 mm
2212‑0279
26 mm
2212‑0280
WATER TEMPERATURE
SENSOR ADAPTERS
•Mount included water temperature sensors inline
•Clamps included
DESCRIPTION
PART #
5
/
16
‑18 x
7
/
8
” L
2210‑0133
M5 x P0,8 x 12 mm L
2210‑0134
M6 x P1,1 x 12,6 mm L
2210‑0135
M6 x P1,1 x 19,7 mm L
2210‑0136
M6 x P1,0 x 24 mm L
2210‑0137
M8 x P1,25 x 22,5 mm L
2210‑0138
M8 x P1,25 x 27,5 mm L
2210‑0139
SPEED SENSOR
MAGNET BOLTS
•Simple and reliable alternative to
gluing sensor magnet to a bolt or rotor
PART #
2212-0247
WATER
TEMPERATURE
GAUGE WITH
WARNING
•Easy-to-read
digital display
•Range of 0-120° C or 32-248° F
•Features a visual overheat warning
•48 mm (1,9”) dia.; 53 mm (2,1”) dia. w/ bezel
•Includes gauge bracket and water temperature
sensor (requires water temperature sensor adapter;
sold separately)
2212‑0284
2212‑0276
2210‑0133
