IRIDIUM SPARK PLUGS
BETTER METALS MEAN BETTER SPARK PLUG DESIGNS
•Six times harder than platinum, iridium doesn’t melt in temperatures up to 2204°C (4.000°F)
•Because the iridium electrodes of these plugs can be shrunk to only 0,4 mm, voltage requirements decrease while firing performance improves
•360° laser welding of electrode provides a seal that resists wear even in the worst conditions
•Ground electrode features a tapered cut and U-groove that form a large volume area for the flame’s center
•Use NGK reference chart to order and stock these plugs
U-GROOVE SPARK PLUGS
PLUG #
THREAD
REACH
W24ESR‑U
14 mm
3
/
4
”
W27ESR‑U
14 mm
3
/
4
”
X22EPR‑U9
12 mm
3
/
4
”
X24EPR‑U9
12 mm
3
/
4
”
X24ESR‑U
12 mm
3
/
4
”
PLUG #
THREAD
REACH
U22FS‑U
10 mm
1
/
2
”
W16FS‑U
14 mm
1
/
2
”
W20EP‑U
14 mm
3
/
4
”
W20ES‑U
14 mm
3
/
4
”
W22EP‑U
14 mm
3
/
4
”
W22ES‑U
14 mm
3
/
4
”
PLUG #
THREAD
REACH
W24ES‑U
14 mm
3
/
4
”
W24FS‑U
14 mm
1
/
2
”
W27ES‑U
14 mm
3
/
4
”
X22ES‑U
12 mm
3
/
4
”
X24ES‑U
12 mm
3
/
4
”
X27ES‑U
12 mm
3
/
4
”
E3 SPARK PLUGS
•Unique electrode shape maximizes the power created by the spark plug – Diamond Fire technology
•Electrode is a combination of performance and technology that results in an improved flame kernel shape
•This flame front ignites the bulk air/fuel mixture faster, moves heat into the combustion chamber faster
and creates a more localized pressure front for faster pressure rise during the cylinder power stroke
•The result is more complete combustion and an improvement in engine performance
•A truly premium performance plug
•Sold each
COPPER PLUS™ SPARK PLUGS
STANDARD AND RESISTOR TYPES
•Copper Plus spark plug has a copper core center electrode that allows for accurate control of heat range, optimizing
performance, and longevity of the spark plug
•Patented SAC-9 semi-conductor resistor for maximum EMI and RFI suppression
•Patented Ultraseal™ coated shell for rust prevention
IRIDIUM PLUG NGK REFERENCE #
IK16
BKR5E, ZFR5F
IW16
B6L, BR5ES, BPR5ES, BP5ES‑11, BPR5ES‑11, BPR5EVX‑11
IW20
BP6ES, BPR6ES, BPR6ES‑11, BPR6EVX‑11, BP6EV
IU22
C7E, CR7E
IUF22
C7HSA, CR7HSA, C7HVX
IW22
BP7ES, BPR7ES, BPR7ES‑11, BP7EVX
IWF22
B7HS, BR7HS, BP7HS, BPR7HS, B7HVX, BP7EVX
IX22
D7EA, DR7EA, DR7ES, D7EVX
IX22B
DP7EA‑9, DPR7EA‑9, DPR7EVX‑9, PJR7A
IU24
C8E, CR8E, CR8EVX
IU24A
CR8EK
IW24
B8ES, BR8ES, BR8ES‑11, B8EG, BR8EG, BR8EGV, B8EV, BR8EVX
IRIDIUM PLUG NGK REFERENCE #
IWF24
B8HS, BR8HS, B8HV, B8HVX
IX24
D8EA, DR8EA, DR8ES, DR8ESL, D8EVX
IX24B
DP8EA‑9, DPR8EA‑9, DP8EVX‑9, DPR8EVX‑9
IU27
C9E, CR9E, CR9EVX
IU27A
CR9EK
IUH27
CR9EH‑9, CR9EHVX‑9
IW27
B9ES, BR9ES, B9EG, BR9EG, B9EGV, B9EV, BR9EV, B9EVX, BR9EVX, BR9ECS
IX27
D9EA, DR9EA, JR9B
IX27B
DP9EA‑9, DPR9EA‑9, DP9EVX‑9, DPR9EVX‑9
IU31A
CR10EK
IW31
B10EG, B10EGV, B10ES, B10EV, B10EVX, BPR10EVX, BR10ECS, BR10EG,
BR10ES, BR10EV, BR10EYA
PART # E3 PART # CHAMPION REFERENCE NGK REFERENCE #
AUTOLITE REFERENCE
2103‑0125 E3,31
N2C, N3C, N4C, N4YC,
N6YC, N7YC, RN2C, RN3C,
RNYC, RN4YC, RN6YC,
RN7YC, RN57YC
B7EB, B7EB‑11, B7ES, B7ES‑11, B7EV, B7EVX, BP7ES, BP7ES‑11, BR7EB‑11, BR7EIX, BR7ES, BR7ES‑11,
BR7EVX, BUR7EB‑11, B8EG, B8ES, B8EV, BP8ES, BR8EA, BR8EIX, BR8ES, BR8EV, B9EG, B9ES, B9EV,
BPR9EIX, BPR9ECS, BPR9ES, BPR9EVX, BPR10ECS, BR9ECS, BR9EIX, BR9ES, BR9EV, BR9EYA,
BUR7EB‑11, R4339‑8, R45671‑9, R5671‑7, R5671A‑7, R5671‑8, R5671‑9, R6918B‑7
403, 4054, 4055, 4062,
4063, AR3933,
XS4063, XS4062,
XS61, XST4055
2103‑0083 E3,34
N9YC, N11YC, N12YC,
RN9YC, RN11YC, RN12YC
B4E, B4ES, B5EB‑11, B5ES, B5ES‑11, B5EV, BP4E, BP4ES, BPREA‑L, BP5ES, BP5ES‑11, BP5EV, BP5EY,
BP6EKA, BP6ES, BP6ES‑11, BP6ET, BP6EV, BP6EY, BP7ES, BP7ES‑11, BP7EV, BPR2ES, BPR4ES,
BPR4ES‑11, BPR5EA‑L, BPR5EIX, BPR5EP, BPR5ES‑11, BPR5EV, BPR5EY, BPR6E, PBR6EIS, BPR6ES,
BPR6ES‑11, BPR6EY, BPR7EIS, BPR7ES, BPR7ES‑11, BR4ES, BR5ES, BR5ES‑11, BUR4EB‑11, BUR5EB‑11,
BUR6EA, BUR7EA‑11, GR4, GR45, GR5, GR55
63, 64, 65, 66, 405, 646,
4263, 4265, AP63,
AP64, AP66, AP646,
APP64, APP646, XP63,
XP64, XP646
2103‑0084 E3,36
RA6HC, RA8HC
D6EA, D7EA, DCPR6E, DCPR7E, DCPR7EIX, DP6EA‑9, DP7EA‑9, DP7EV‑9, DP8EA, DP8EA‑9, DP8EV, DP8EV‑9,
DP8EVX‑9, DPR8EVX‑9, DPR6EA‑9, DPR6EB‑9, DPR7EA‑9, DPR7EIX‑9, DPR7EV‑9, DPR7EVX‑9, DPR8EA‑9,
DPR8EIX‑9, DPR8EV‑9, DPR8Z, DPR9Z, DR7EA, DR7EIX, DR8EIX, DR8ES
4163, 4164,
XS4163, XS4164
2103‑0085 E3,38
G57C, G59C
C7E, C8E, C8EH‑9, C8EVX, C8EVX‑9, C9E, C9EVX, CR7E, CR7EB, CR7EH‑9, CR7EIX, CR7EK, CR8E, CR8EB,
CR8EH, CR8EH‑9, CR8EHVX‑9, CR8HIX‑9, CR8EIX, CR8EK, CR8EKB, CR8EKPA, CR8EVX, CR9E, CR9EB,
CR9EH, CR9EIA‑9, CR9EH‑9, CR9EHIX‑9, CR9EHX‑9, CR9EHVX‑9, CR9EIX, CR9EK, CR9EKA, CR9EVX,
CR9HIX‑9, IMR8C‑9H, IMR9A‑9H, IMR9C‑9H, IMR9D‑9H, PMR6B, PMR7A, PMR8A
4302, 4303,
XS4302, XS4303
PART #
THREAD REACH PER BOX
J-12-YC
14 mm
3
/
8
”
10
L-82-C
14 mm
7
/
16
”
10
N-2-C
14 mm
3
/
4
”
10
N-3-C
14 mm
3
/
4
”
10
N-4-C
14 mm
3
/
4
”
10
PART #
THREAD REACH PER BOX
N-12-YC
14 mm
3
/
4
”
8
RA6HC
12 mm
3
/
4
”
10
RA8HC
12 mm
3
/
4
”
10
RH8C
14 mm
7
/
16
”
8
RL-82-YC
14 mm
1
/
2
”
10
PART #
THREAD REACH PER BOX
RN-2-C
14 mm
3
/
4
”
10
RN-3-C
14 mm
3
/
4
”
10
RN-4-YC
14 mm
3
/
4
”
10
RN-12-YC
14 mm
3
/
4
”
4
RN-13-LYC
14 mm
3
/
4
”
6
HOT U STANDARD PLUGS
HOT U RESISTOR PLUGS
