OPTIMATE PRO 4
BATTERY DIAGNOSTIC CHARGER, DESULFATOR AND MAINTAINER
•Four-bank automatic six-stage charger initializes new sealed and filler-cap batteries
in one hour, plus desulfates and recovers neglected batteries – simply decide between a
NEW or USED battery selection
•Incorporates diagnostic checks and an automatic special recovery mode for deep-
discharged (sulfated) batteries, making it suitable for all different types of powersports
vehicle batteries
•4 Amps constant current for each of the four battery banks/stations
•Three battery type selections: STD, Deep-Cycle and MF for fully sealed,
absorbed-acid batteries
•Automatic detection and recovery of deep-discharged or sulfated batteries
•Self-discharge test (following charging): voltage parameters set for the selected
battery type
•Can be used for long-term storage charging
•Temperature-corrected testing and charging ensures accurate results and no damage
to the battery
•CE conformity
•EU plug
PART #
3807-0155
OPTIMATE PRO 2
•Two independent charging systems
of 2 Amps each
•Able to desulfate, charge, maintain
and initialize new batteries using the
12-hour program
•Use on 2 x 12V lead-acid batteries
independently or connected
together in a 24V system
•Simply connect a battery and the rest
is automatic
•Includes the Ampmatic™ program that
automatically controls current and enables
cell equalization for initialization of new
batteries over 12 hours
•Tests and verifies charge retention by battery
•The high voltage and pulsing recovery mode is able to
save a neglected sulfated 12V lead-acid battery unable to
accept charge from a standard charger
•Automatic safety features include quick identification of a
severely shorted battery, 12-hour maximum program for USED
batteries and electronic reverse polarity protection
•Wall mount is included for easy and convenient wall placement, and the unit comes with
battery clips and permanent connectors for both banks, with cable reach of over 2,5 m
•Both banks use the 12-hour program
•CE conformity
•EU plug
PART #
3807-0116
ACCUMATE
6/12V
•Ideal for older
vehicles or deep
cycle applications
•For standard filler
cap and sealed AGM
and GEL starter
and deep-cycle
batteries from
4Ah to 75Ah
•4-step program
and 1,2 Amp charge current
•Simple to use – make a voltage selection (6 or 12V),
connect and 4-step program automatically completes
the charge
•Leave connected for long-term maintenance
•No risk of overcharging – AccuMate’s special
monitoring circuits vary and regulate the current
and voltage exactly according to the battery
manufacturer’s specifications
•Supplied with clips and fused battery fly-lead with
waterproof connector
•CE conformity
•EU plug
PART #
3807-0066
BATTERYMATE 150-9
LOAD TESTER/CHARGER
•This unique diagnostic load
tester and constant
current charger with
automatic desulfating
action saves valuable time
in professional service
workshops and prolongs
battery life
•Six load test settings from 15A to
150A, suitable for all starter batteries
from 2,5Ah to 45Ah
•Six charging Amps settings, from 1A to 9A
constant current, for correct and most time-
effective charging of batteries 2,5 Amp-hours and greater
•Also unique is the special MF program, essential for the correct and
vital first “commissioning” charge of motorcycle-type dry-charged
maintenance-free batteries
•The program terminates the important constant current “bulk charge” at
the correct voltage appropriate for any one of the various types of
MF batteries now available, according to their particular
impedance characteristics
•Incorrect commissioning charging of motorcycle AGM type MF batteries is
the single biggest cause of premature battery failure
•For all 12V lead-acid starter batteries of 2,5 Amp-hours capacity or greater,
as used in motorcycles, ATVs, snowmobiles, personal watercraft and
garden tractors
•Recommended by most motorcycle OEMs
•CE conformity
•EU plug
PART #
3807-0120
ACCUMATE COMPACT
•Charging circuit will engage and attempt to
recharge any 12V lead-acid battery retaining at
least 2V at the moment of connection; i.e., even a
very flat battery
•3 m long output cable, plus two detachable and
replaceable connection sets: one with metal
eyelets for permanent fixing to the battery posts
and easy and quick connection/disconnection to
batteries on the vehicle; the other with battery
clips for charging and maintenance of batteries
removed from the vehicle
•Recommended for all 12V lead-acid batteries from 2Ah to 32Ah, the
AccuMate Compact can also maintain larger batteries (they will just take
longer to charge)
•Comprehensive selection of connection accessory aids including a 2,5 m
output extension cable set, optional
•Full electronic protections against user error such as output short-circuit
and wrong battery connections
•Spark generation is suppressed even in short-circuit
•Furthermore, each charger comes with a selection of plastic plug props
that can be plugged into (and protrude from) holes in the lower edge of
the charger housing to relieve the stress on the socket due to the weight
of the charger when plugged into 2-pin Euro sockets
•Available in most countries with 220-240V supply
•Supplied with clips and fused battery connector
•Meets all relevant EN and IEC norms
and CE directives
•EU plug
PART #
3807-0067
