OPTIMATE TEST
BATTERY TESTER FOR ALL
LEAD-ACID AND LITHIUM BATTERIES
•Microprocessor circuit draws very low power
from the battery and displays status
•State of charge result in volts and percent
•Tests all 12V lead-acid and LiFePO4 / LFP
lithium batteries
OPTIMATE™4 DUAL PROGRAM
•OptiMate4, the ultimate all-in-one tool for 12V battery care at home, now with dual program that
diagnoses, recovers, charges, tests and optimally maintains your battery automatically
•Charge the battery directly or select the program to charge via the 12V port on your CAN-bus
equipped bike
•With automatic keyless activation, OptiMate4 Dual Program will charge and maintain your battery
automatically until it is disconnected
•Includes low voltage pulse recovery for even more effective recovery of badly neglected,
sulphated batteries; a user-friendly battery test at connection; a slick weatherproof enclosure
with built-in mounting lugs and improved energy efficiency
•Extending battery life by up to 400%, OptiMate4 Dual Program will keep your battery safe and
ready-to-go for months on end
•Includes two detachable, interchangeable battery connectors: a connector with eyelets for
permanent connection and battery clips for bench charging
•Available in most countries with 220-240V supply
•Meets all relevant EN & IEC norms and CE directives
•EU plug
OPTIMATE
PRO-S
AMPMATIC
BATTERY
INITIALIZING
SHOP CHARGER,
DESULFATOR AND
MAINTAINER
•A shop charger that
initializes all sealed and
filler cap batteries in
one hour or less and also desulfates and recovers neglected batteries
•For all 12V batteries
•Simply decide between a NEW or USED battery selection
•Select NEW and battery receives the correct initialization charge
•The USED program allows optional selection between two sizes of
battery (2 or 4 Amp) and the rest is automatically done for you
•The high-voltage and pulsing recovery mode is able to save a
neglected, sulfated 12V lead-acid battery unable to accept charge
from a standard charger
•Battery power is optimized during bulk, absorption and cell-balancing
charge modes by the microprocessor-controlled ampmatic™
program, a unique feature that automatically ensures the battery
receives optimal current every second, and then tests to verify
charge retention
•Automatic safety features include quick identification of a severely
shorted battery, 12-hour maximum program for used batteries and
electronic reverse polarity protection
•Includes fused, weather-protected eyelet connectors, clip connectors
and 2,5 m extension cable
•CE conformity
•EU plug
PART #
3807-0125
PART #
3807-0227
OPTIMATE™
LITHIUM
•OptiMate™ Lithium, the first
OptiMate to protect your
LiFePO4 battery in a way no
other charger has
•Will protect your investment
and keep your Lithium
Iron Phosphate (LiFePO4 /
LFP) battery performing as
advertised, for a very long time
•With 5 Amps of charge current
available, OptiMate Lithium’s
unique multi-step Ampmatic™
program recharges and balances
cells within the battery quickly
and efficiently
•OptiMate Lithium’s maintenance
program delivers current to the
vehicle circuitry, protecting and keeping the battery at 100% charge
•Tests and displays battery condition before charging
•Voltage retention test is conducted for 30 minutes during which no charge
current is delivered, and provides results indicating the battery’s general state
of health
•The 12-hour MAINTENANCE CHARGE CYCLE consists of 30-minute float charge
periods at a voltage of 13,6V followed by and alternating with 30 minute “rest”
(no charge current) periods
•During the float charge period current is delivered only if the battery has lost
charge due to connected vehicle circuitry; a refresh cycle may be performed if
the charge level has dropped significantly
•Charge progress is tracked against the ideal LiFePO4 charge curve; internal
damage will be detected and unnecessary charging of a battery that cannot be
recovered is prevented
•Includes permanent ringlet connector with weatherproof cap and a set of
battery clips
•CE conformity
•EU plug
PART #
3807-0153
PART #
3807-0226
OPTIMATE 3
DESULFATING/
MAINTAINING CHARGER
•Smaller, lighter and more powerful than
its predecessor
•Diagnoses, recovers, charges, checks and
maintains batteries safely for months
•Advanced, fully automatic battery charger and
maintainer for all 12V lead-acid batteries from 2,5
to 50A hours capacity
•Recommended for sealed and conventional
batteries for motorcycles and similar vehicles,
including dry-charged MF, sealed wet
maintenance-free types, AGM and sealed deep-
cycle gel batteries
•Features vent-free enclosure, SAE weatherproof
connectors and includes wall mounts
•Unique diagnostic function automatically
identifies deeply discharged (sulphated)
batteries and applies a controlled high voltage
with small fixed current for a limited period to recover them
•Includes two detachable, interchangeable battery connectors: a connector with eyelets for
permanent connection and battery clips for bench charging
•Comes with global input (100-240V)
•Meets all relevant EN and IEC norms and CE directives
•CE conformity
•EU plug
PART #
3807-0253
