506
COLOR
PART #
FORK SKINS
Black
0406‑0001
Blue
0406‑0002
Red
0406‑0003
COLOR
PART #
STANDARD FORKS SEAL SKINS
Black
0406‑0022
Blue
0406‑0023
Red
0406‑0024
COLOR
PART #
INVERTED FORKS SEAL SKINS
Black
0406‑0018
Blue
0406‑0019
Red
0406‑0020
DIRT SKINS
FORK AND SEAL SKINS
•Protect expensive suspension components
from rocks, mud, sand and all other types
of roost
•Made of flexible 2 mm neoprene and held on
by industrial-grade hook-and-loop material
•Easy to install
•Fork skins are sold in sets of four
•Seal skins 25,4 mm (1”) longer than the
original version; sold in pairs
•For 125cc or larger
DESCRIPTION
PART #
(A) For Pee‑Wee (Y‑Zinger and PW‑50)
0406‑0031
(B) For Marzoochi/KTM 45 mm and Magnum 45 mm
0406‑0032
DESCRIPTION
PART #
For Marzoochi/KTM 50 mm and Magnum 50 mm
0406‑0033
(C) For Honda XR650R; Suzuki DR‑Z400/Dual Sport, RM125/250 and
50 mm White Power Forks
0406‑0034
BLACK POLY-VINYL FORK BOOTS
•Extend the life of fork seals and shaft by protecting them from mud, dirt,
rocks and other flying debris
•Longest lasting fork boots on the market
•Made from a premier Poly-Vinyl material that is much less affected by the elements than
rubber boots
•Easy to install, and come with re-useable cable ties that allow quick removal for cleaning and maintenance
•PART #0406-0034 is a Big Bike Long Travel version for models listed; extended length 42 cm (16,5”), collapsed length 76 mm (3”), upper boot inside diameter
44,5 mm (1,75”), lower boot inside diameter 66,2 mm (2
39
/
64
”)
B
A
C
BLACK
BLUE
RED
ROYAL BLUE
YELLOW
D58‑1
D58‑2
D58‑6
D58‑7
D58‑8
D69‑1
D69‑2
D69‑6
D69‑7
D69‑8
D83‑1
‑
D83‑6
D83‑7
‑
D234‑1
‑
‑
‑
‑
FORK BOOT
SERIES #
AVAILABLE
TRAVEL
COLLAPSED
HEIGHT
FITS UPPER TUBE
DIMENSIONS
FITS LOWER
FORK DIMENSION
(A) D58‑
279 mm (11”)
50,8 mm (2”)
30‑40 mm
50,8‑63,5 mm (2‑2
1
/
2
”)
(B) D69‑
330 mm (13”)
69,9 mm (2
3
/
4
”) 40‑48 mm
50,8‑63,5 mm (2‑2
1
/
2
”)
(C) D83‑
279 mm (11”)
25,4 mm (1”)
30‑40 mm
50,8‑63,5 mm (2‑2
1
/
2
”)
(D) D234‑
279 mm (11”)
12,7 mm (
1
/
2
”)
30‑40 mm
50,8‑63,5 mm (2‑2
1
/
2
”)
FORK BOOTS
•Protection from dirt, rocks and other contaminants
•Boots utilize the latest advances in material technology to adapt to fork and styling demands
FORK BOOT SPECIFICATIONS
FORK BOOT PART NUMBERS
DESCRIPTION
PART #
For BBR SP5, 27 x 39 x 10,5 mm
0407‑0081
For BBR E6, 30 x 40,5 x 10,5 mm
0407‑0180
DUST AND OIL SEALS
•OEM quality heavy-duty dust and oil seals for BBR
front forks
•Includes one oil seal and one dust seal
FITS MODEL
PART #
KAWASAKI
KLX110 02‑12 (all except KLX110L)
0414‑0193
FITS MODEL
PART #
SUZUKI
DR‑Z110 03‑05
0414‑0193
DAMPING ROD SETS
•A perfect match for the BBR Super Pro Swingarm Kit
•Slows rebound and compression damping for a firmer ride
•Billet-machined from high-strength steel
•Increases ride height and travel by 38 mm (1,5”)
•BBR Fork Springs recommended for larger and/or more aggressive riders
•Extended brake cable may be needed
Fork Skins
Seal Skins
A
B
B
B
C
D
