All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
SUSPENSION
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
505
FITS MODEL
PART #
HONDA
CRF250R/450R 08‑10
0410‑0104
FITS MODEL
PART #
HONDA (CONT)
CRF250R/450R 11‑12
0410‑0138
STEERING DAMPING
GOLD VALVE KIT
FOR HONDA CRF250R/450R
•The standard mounting configurations on the
CRF250R and CRF450R result in inadequate
damping; this new Gold Valve kit solves
the problem
•Includes Gold Valve and instructions for three
settings: soft, standard and hard
FITS MODEL
HONDA
CR125/250 91-93/500R 91-94
FITS MODEL
SUZUKI
RM125-250 92-93
RMX250 92-95
PART #
FSRB12
REMOVABLE BOTTOM-OUT FORK
PISTON ASSEMBLY
FOR SHOWA FORKS
•Allows easy access to rebound valving, piston and internal
cartridge parts for tuning,
polishing and service
•For 12 mm forks
PART #
0450-0074
REPAIR JAM NUT
FOR SHOWA TWIN-CHAMBER FORKS
•Showa twin-chamber rebound rods sometimes
strip; now they can be repaired instead of
buying a new cartridge
•Repair nut has longer threads
•Just cut the thread longer and install the nut
•Repair is stronger than the original
FITS MODEL
PART #
HONDA
CR250R 97‑03
0450‑0049
CRF250R 08
0450‑0049
CRF450R 02‑03, 08
0450‑0049
KAWASAKI
KX250F 06‑10
0450‑0049
FITS MODEL
PART #
SUZUKI
RM125/250 04‑07
0450‑0049
RMZ250 07‑09
0450‑0049
RMZ450 07‑09
0450‑0049
LO-SPEED VALVES FOR SHOWA
•Perfect for heavier or more aggressive riders
•Hold the fork in place
•Reduce front end dive
•Sold in pairs
FITS MODEL
PART #
HONDA
CR250R 97-07
OLC47
CRF250R 04-09
OLC47
CRF250R 10-14
0450-0160
CRF450R 02-08
OLC47
CRF450R 09-10
0450-0160
CRF450R 11-12
0450-0229
FITS MODEL
PART #
KAWASAKI
KX250F 06-09
OLC47
KTM
125-505 SX 07-10
0450-0054
125-505 SX-F/
XC/XC-F 08-13
0450-0054
FITS MODEL
PART #
SUZUKI
RM125 01-02
OLC47
RM-Z250 07-12
OLC47
RM-Z450 07-12
OLC47
FORK OIL LOCK COLLAR SET
•Specially designed for aggressive and heavier riders
•Increase the progressive rate of the hydraulic oil lock
during the last 64 mm of stroke (2
1
/
2
”)
•Increase bottoming resistance, producing a more compliant valving curve
and better small-bump ride
•Mount to the bottom of the cartridge
DESCRIPTION
PART #
32 mm‑43 mm standard (for 85cc and smaller bikes)
0406‑0035
44 mm‑50 mm standard (for 125cc and larger bikes)
0406‑0036
EASY ON
FORK SKINS
•These Fork Skins are an easy-to-install product that eliminates
mud and dirt contamination
•Fork seals stay clean in all conditions, preventing oil and
air leaks
•Greatly increase the life of fork seals
•Available in two sizes to fit almost every off-road motorcycle
•Cable ties are included for extra security
•Two free grip donuts included
•Sold in pairs
DESCRIPTION
PART #
32 MM‑43 MM DIAMETER – FIT BIKES
85CC AND SMALLER
127 mm/5” L
0406‑0009
356 mm/14” L
0406‑0011
DESCRIPTION
PART #
44 MM‑50 MM DIAMETER – FIT BIKES
125CC AND LARGER
127 mm/5” L
0406‑0010
356 mm/14” L
0406‑0012
FORK SKINS
•Help protect vulnerable fork tubes
and seals from dust, dirt, and
corrosive elements
•Designed to fit closely over upper and
lower fork tubes
•Constructed of a double-lined 3 mm
thick neoprene
•Assembled using double-stitched seams
•Short skins include durable cable ties for extra security
•Available in two sizes for forks ranging from 32 mm to 50 mm
•Two free grip donuts included
•Sold in pairs
FITS MODEL
PART #
GAS GAS
All
0412‑0163
HONDA
All
0412‑0163
HUSABERG
All
0412‑0163
HUSQVARNA
All
0412‑0163
FITS MODEL
PART #
KAWASAKI
All
0412‑0163
KTM
All
0412‑0163
SUZUKI
All
0412‑0163
YAMAHA
All
0412‑0164
CARBON FIBER FORK GUARDS
•Carbon fiber with abrasion-resistant epoxy
•Snap over forks without mounting hardware
•Look good and save fork legs
•Sold in pairs
•Made in the U.S.A.
0412‑0163
0406‑0011
0406‑0009
0406‑0035
OLC47
0410‑0104
