All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
SUSPENSION
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
504
PRO BLEEDER FORK
KIT
5
/
16
”-32 UNEF
•Designed to release built-up air
pressure in the forks of late-model MX bikes
•Push-button operation allows air pressure to be relieved
without tools
•Kit is designed for the professional who wants the cleanest
possible setup
•Requires drilling, tapping and end-milling of the fork caps
•Kit includes two Pro Bleeder valves,
5
/
16
”-32 tap,
9
/
32
” drill bit,
washers and instructions (low-profile installed height of
3
/
8
”
or 10 mm)
•Requires
7
/
16
” end mill (not included)
PART #
MP11-0028
DESCRIPTION
COLOR PART #
M4 x 0,7; for KTM SX/SX‑F/XC/XCF/XCW 07‑later models with
WP 4860 MXMA CC closed cartridge fork caps and all 99‑later
WP 43/WP 48 fork caps w/ external preload adjusters (these fork caps
require 4‑pin spanner PART #MP08‑0290 to remove fork cap)
Black 0404‑0144
M4 x 0,7; for all 99‑later WP 43/WP 48 fork caps w/o external preload
adjusters (these fork caps do not require 4‑pin spanner to remove fork cap) Orange 0404‑0145
M5 x 0,8; for use w/ most Showa inverted forks w/ a M5 x 0,8 air bleed
screw in the fork cap
Gold
0404‑0279
M5 x 0,8; for use w/ most Kayaba inverted forks w/ a M5 x 0,8 air bleed
screw in the fork cap
Silver
0404‑0280
MICRO BLEEDERS
•New ultra-compact, low-profile
design is only 11 mm high installed
•Stainless steel body is stronger and will not corrode
•Easy to install – simply replace the OE bleeder screw with the Micro Bleeder
•Reduces harshness caused by air buildup
•Allows bleeding of pressure without tools
•One of the easiest bolt-on upgrades you can make to your forks
•Kits include two bleeder valves
DESCRIPTION
SIZE
PART #
WP/Marzocchi/Ohlins/Paioli, orange
4 mm x 0,7
0404‑0134
WP/Marzocchi/Ohlins/Paioli, black
4 mm x 0,7
0404‑0141
Showa/Kayaba, black
5 mm x 0,8
0404‑0135
Showa/Kayaba, blue
5 mm x 0,8
0404‑0136
Showa/Kayaba, red
5 mm x 0,8
0404‑0137
Showa/Kayaba, green
5 mm x 0,8
0404‑0140
MOTOCROSS
FORK AIR BLEEDERS
•Allows riders to easily bleed air from forks
•Rider only has to push a button to release the air in the forks
•High-quality anodized finishes
PART #
0450-0011
FORK REBOUND HOLDER
FOR RM250 02-03 KYB FORKS
•Replace the stock units when threads become
damaged after disassembly
•Nylon locking nuts included
•Sold each
COLOR
PART #
SHOWA/KAYABA UPSIDE DOWN FORKS
(EXCEPT HONDA CRF450R 13-14,
KAWASAKI KX450F 13-14)
Blue
3805-0018
Red
3805-0030
Stealth
3805-0031
WP UPSIDE DOWN FORKS/KTM
65/85 SX (all)
0404-0032
COLOR
PART #
WP UPSIDE DOWN FORKS/KTM (CONT)
WP upside down all models
up to 13 (except SX/SX-F 08-14,
XC/XC-F 09-14)
0404-0032
XC-F 09-14
0404-0059
SX/SX-F/XC 08-14
0404-0059
KAWASAKI
Green – all models up to 13 (except
CRF450R 13-14, KX450F 13-14)
0404-0044
PRESSURE RELIEF VALVE KITS
•Release built-up fork air pressure with the push of a button
•Valves allow forks to work at peak performance without the use of any tools
•O-ring under cap creates a positive seal to keep dirt, mud, and water out
•Replaces OEM fork bleeder screws on Showa, Kayaba, and WP
•Installation tool included
•Made in the U.S.A.
0404‑0145
0404‑0144
0404‑0279
0404‑0280
0404‑0135
0404‑0134
0404‑0136
0404‑0140
0404‑0137
3805‑0018
3805‑0030
0404‑0032
0404‑0044
3805‑0031
