All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
ELECTRICAL & GAUGES
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
528
PART #
2210-0119
XR-SR MULTI-
FUNCTION
ELECTRONIC
SPEEDOMETER
•Easy-to-read, blue back-lit digital
display with eight indicator lights
•Display shows speed (mph/km/h),
odometer, two trip meters, tach
(100 rpm resolution), fuel level
(10-bar display) and engine temperature
•Adjusts to any engine or tire size
•Keeps record of top speed, max rpm and max temperature
•Indicator lights for neutral, high beam, low beam, hazard lights, turn signals, oil
pressure and water temperature
•Gauge measures 72 mm H x 11,5 cm W x 32 mm D (2,85” x 4,57” x 1,25”)
•Includes gauge bracket, speed sensor with bracket, speed sensor magnet and water
temperature sensor (requires water temperature
sensor adapter; sold separately)
DL UNIVERSAL
ELECTRONIC
SPEEDOMETER
•Stainless steel body with
easy-to-read, blue back-lit
digital display
•Display shows speed (km/h or mph),
odometer, trip meter and fuel level (10-bar display)
•Face is completely black when off
•Adjusts to all tires sizes
•Gauge measures 55 mm (2,17”) dia. without bezel; 61 mm (2,4”)
with bezel
•Includes gauge bracket, speed sensor with bracket
and magnet
PART #
2210-0121
XR-SA MULTI-
FUNCTION ELECTRONIC
SPEEDOMETER
•Easy-to-read, blue back-lit digital display
•Display shows speed (0-230 km/h
(0-145 mph)), odometer and trip meter
•Adjusts to all tire sizes
•Indicator lights show high beam, turn
signals and oil pressure
•Gauge measures 83 mm H x 82 mm W x 29 mm D (3,27” x 3,24” x 1,14”)
•Includes gauge bracket, speed
sensor with bracket and magnet
DL UNIVERSAL
ELECTRONIC
TACHOMETER
•Stainless steel body
with easy-to-read
digital display with
blue backlight
•Digital display shows
tachometer with
0-18.000 rpm range
(100 rpm resolution) and
water temperature
•Adjusts to all engine types
•When off, face turns
completely black
•Works with single- or dual-fire ignitions
•55,1 mm dia. (2,17”); 61 mm (2,4”) dia. w/ bezel
•Includes gauge bracket and water temperature sensor
(requires water temperature sensor adapter; sold separately)
DESCRIPTION
PART #
White background
2211‑0077
DESCRIPTION
PART #
Black background
2211‑0090
GP-STYLE UNIVERSAL TACHOMETER
WITH TEMPERATURE GAUGE
•Easy-to-read white or black background with blue backlight
•Stepper motor keeps dial needle stable through the
heaviest vibrations
•Gauge dial shows tachometer with 0-9.000 rpm range; adjustable by
units of 100 rpm
•Blue back-lit digital display shows water temperature
•Gauge measures 55 mm (2,17”) dia. without bezel; 61 mm (2,4”) dia.
with bezel
•Includes gauge bracket and water temperature sensor (requires water
temperature sensor adapter; sold separately)
PART #
2210-0122
XR-S ELECTRONIC
SPEEDOMETER
•Easy-to-read, blue back-lit digital display
•Display shows speed (0-233 km/h
(0-145 mph)), odometer and trip meter
•Adjusts to all tire sizes
•Gauge measures 69 mm H x 76 mm W x 28 mm D (2,7” x 3” x 1,1”)
•Includes gauge bracket, speed
sensor with bracket and magnet
PART #
2211-0084
G2 REVOLUTION
TACHOMETER/DUAL
TEMP METER
•Highly visible, backlit digital
display shows rpm and
dual temperatures
•Large digital rpm readout and
REV bar-graph make it easy to
read rpm at high speeds; REV indicator is programmable to 10.000. 15.000 or 20.000 rpm
•Dual temp meters have programmable high-temp warning lights;
0-250°C range (32-482°F)
•Records max rpm and temp
•Also features volt meter, time, programmable shift light and optional air/fuel
ratio meter
•Includes water temperature sensor; oil temperature sensors and cylinder head
temperature sensors available separately
•Measures 86 mm W x 30 mm H x 19 mm
D (3,37” x 1,2” x 0,75”)
PART #
2210-0120
PART #
2211-0075
2211‑0077
2211‑0090
