FITS MODEL PART #
HONDA
CRF50/XR50/Z50 79-13 0920-0045
CRF70/80/100 04-13 0920-0045
CR80 80-02 0920-0045
XR80 79-00 0920-0045
XR100 81-84 0920-0045
CR125 74-03 0920-0040
CR250 92-08 0920-0040
XR250 79-04 0920-0045
XR350 83-85 0920-0045
XR400 96-04 0920-0045
CRF450 09-12 0920-0065
CR480 82-83 0920-0045
CR500 84-01 0920-0040
XR500 81-84 0920-0045
XR600 89-00 0920-0045
XR650L 93-04 0920-0045
XR650R 00-04 0920-0045
HUSQVARNA
TE/TC/TXC 250-510 04-10 (transmission) 0920-00534
TE/TC/TXC 250-510 04-10 (crankcase) 0920-00545
KAWASAKI
KX65 00-14 0920-0048
KX80/85/100 79-14 0920-0048
KX125/250 74-04 0920-0048
KLX250 04 0920-0048
KX250F 03-14 0920-0048
KLX300 94-03 0920-0048
KLX300R 04-08 0920-0048
KX450F 06-14 0920-0049
FITS MODEL PART #
KAWASAKI (CONT)
KX500 (all) 0920-0048
KTM
All 2-stroke/4-stroke models 99-14 0920-00461
All RFS 4-Strokes 97-07 (center case plug) 0920-00472
SUZUKI
RM80-250 2-stroke 99-07 0920-0041
RMZ250 04-06 0920-0048
RMZ250 07-09 0920-0041
DRZ400 99-07 0920-0041
RMZ450 08-14 0920-00443
YAMAHA
YZ125 98-04 0920-0040
YZ125 05-14 0920-0039
YZ250 98-14 0920-0040
YZ/WR250F 01-09 0920-0039
WR250F 10-14 0920-0040
YZ250/450F 03-on (internal and external oil tanks) 0920-00443
YZ250F 10-14 0920-0039
YZ/WR400F 98-02 0920-0045
YZ/WR450F 03-11 0920-0039
WR450F 12-14 0920-00443
YZ450F 10-13 0920-00443
YZ450F 14 0920-0039
1 Anodized orange.
2 Color is silver and is non-magnetic; replaces Allen bolt with 12 mm hex head; accepts
stock screen filter.
3 Color is silver.
4 Engine case oil drain bolt.
5 Side engine oil screen bolt.
PART # DIMENSIONS (MM)
0920‑0039 14 mm x 1,5 x 19 mm
0920‑0040 12 mm x 1,5 x 17 mm
0920‑0041 12 mm x 1,25 x 17 mm
0920‑0044 8 mm x 1,25 x 12 mm
PART # DIMENSIONS (MM)
0920‑0045 12 mm x 1,5 x 22 mm
0920‑0046 12 mm x 1,5 x 20
0920‑0047 16 mm x 1,5 x 12 mm
0920‑0048 10 mm x 1,5 x 17 mm
PART # DIMENSIONS (MM)
0920‑0049 10 mm x 1,5 x 22 mm
0920‑0053 16 mm x 1,5 x 19 mm
0920‑0054 14 mm x 1,5 x 13 mm
0920‑0065 8 mm x 1,25 x 20 mm (including magnet)
MAGNETIC DRAIN PLUGS – BY ZIPTY
•Made from 7075 lightweight aluminum
•Prolong engine life by pulling metal filings out of the oil
•Ultra-powerful magnets
•Come with either O-ring or washer sealing surface
•Compare with original OEM plug before installing
•Anodized red, unless noted
•PART #0920-0047 is non-magnetic
•Made in the U.S.A.
DRAIN PLUG DIMENSIONS
FITS MODEL PART # THREAD SPECS LENGTH OF THREAD
HONDA
XR/Z/​50R 79‑03 M0103 M12x1,5 0,500”
CR80R/​85R 80‑04 M0103 M12x1,5 0,500”
CR125R/​250R 74‑04 M0103 M12x1,5 0,500”
XR80 79‑00 M0103 M12x1,5 0,500”
XR100 81‑84 M0103 M12x1,5 0,500”
XR250 79‑04 M0103 M12x1,5 0,500”
XR350 83‑85 M0103 M12x1,5 0,500”
XR400 96‑04 M0103 M12x1,5 0,500”
CR480R 82‑83 M0103 M12x1,5 0,500”
CR500R 84‑01 M0103 M12x1,5 0,500”
XR500 81‑84 M0103 M12x1,5 0,500”
XR600 89‑00 M0103 M12x1,5 0,500”
XR650L 93‑04 M0103 M12x1,5 0,500”
XR650R 00‑04 M0103 M12x1,5 0,500”
KAWASAKI
KX65 00‑04 M0105 M10x1,5 0,500”
KX80/85/​100 79‑04 M0105 M10x1,5 0,500”
KLX125/L 04 M0105 M10x1,5 0,500”
KX125/​250/​500 74‑04 M0105 M10x1,5 0,500”
KDX175 80‑82 M0105 M10x1,5 0,500”
KDX200/​220 83‑04 M0105 M10x1,5 0,500”
KX250F 04‑05 M0105 M10x1,5 0,500”
KLX300R 04 M0105 M10x1,5 0,500”
FITS MODEL PART # THREAD SPECS LENGTH OF THREAD
KAWASAKI (CONT)
KLX400 03 M0105 M10x1,5 0,500”
SUZUKI
RM80/85 93‑02 M0101 M12x1,25 0,560”
DR‑Z110 04 M0105 M10x1,5 0,500”
DR‑Z125/L 04 M0105 M10x1,5 0,500”
RM125/​250 92‑94 M0101 M12x1,25 0,560”
DR250 90‑92 M0102 M14x1,25 0,420”
DR‑Z250 04 M0105 M10x1,5 0,500”
RM‑Z250 04 M0105 M10x1,5 0,500”
RMX250 92‑98 M0101 M12x1,25 0,560”
DR350/​650 93‑94 M0102 M14x1,25 0,420”
DR‑Z400 04 M0105 M10x1,5 0,500”
YAMAHA
YZ80 82‑01 M0103 M12x1,5 0,500”
YZ100 76‑83 M0103 M12x1,5 0,500”
YZ125/​250 84‑05 M0103 M12x1,5 0,500”
WR200/​250/​500 91‑97 M0103 M12x1,5 0,500”
YZ/​WR250F/​450F 03‑05 0920‑0005 M10x1,25 0,600”
YZ400 76‑79 M0103 M12x1,5 0,500”
YZ400F/​426F 98‑02 M0103 M12x1,5 0,500”
YZ465 80‑81 M0103 M12x1,5 0,500”
YZ490 82‑85 M0103 M12x1,5 0,500”
MAGNETIC DRAIN PLUGS
•Prolong engine life and save on costly repairs with an oil plug that picks up metal filings
•Must use washer provided
•Compare with original OEM plug before installing
•Made in the U.S.A.
