All part numbers in BOLD MAGENTA
are new this year. 2014 PARTS EUROPE OFFROAD
ENGINE
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
571
FITS MODEL BORE SIZE
PISTON KIT
PART #
REPLACEMENT
WRIST PIN
PART #
REPLACEMENT
CIRCLIPS
PART #
REPLACEMENT
RING SET
PART #
HONDA
CR125R 05-07 54 mm std bore 0910-1722 0913-0082 0913-0086 0912-0293
KAWASAKI
KX125 04-07 54 mm std bore 0910-1724 0913-0082 0913-0086 0912-0293
KX250 05-07 66,4 mm std bore 0910-1725 0913-0083 0913-0074 0912-0294
SUZUKI
RM125 04-06 54 mm std bore 0910-1726 0913-0082 0913-0086 0912-0293
RM250 05-08 66,4 mm std bore 0910-1727 0913-0083 0913-0074 0912-0294
YAMAHA
YZ125 05-13 54 mm std bore 0910-1720 0913-0082 0913-0086 0912-0293
YZ250 02-13 66,4 mm std bore 0910-1721 0913-0083 0913-0074 0912-0294
HIGH PERFORMANCE 2-STROKE
PISTON KITS BY CP PISTONS
•Forged from 4032-T6 aluminum for ultimate strength, durability, and performance
•Engineered for maximum weight reduction that enables a faster and more consistent
throttle response
•Newly designed and tested skirt profiles provide extra durability and noise
reduction while delivering maximum power
•Along with the latest skirt profiles, newly designed rings put less
tension on the cylinder wall without compromising ring seal
•Skirt coating acts as a buffer to ensure better wear characteristics
•Each kit comes complete with a piston, wrist pin, pin bearings, circlips,
rings, and a top-end gasket kit
•Replacement rings, wrist pins, and circlips are available
•Replacement gaskets available from Moose Racing on pages 634-638
•Made in the U.S.A.
0910-1725
2-STROKE PISTONS
FITS MODEL BORE SIZE
PISTON KIT
PART #
REPLACEMENT
WRIST PIN
PART #
REPLACEMENT
CIRCLIPS
PART #
REPLACEMENT
RING SET
PART #
KAWASAKI (CONT)
KX250F 14,0:1 04-08 Race Piston 77 mm std bore 0910-16501, 2 0913-00933 0913-0071 0912-0241
KX250F 13,5:1 09 77 mm std bore 0910-1276 0913-0062 0913-0071 0912-0241
KX250F 14,2:1 09 Race Piston 77 mm std bore 0910-24461, 2 0913-00933 0913-0071 0912-0241
KX250F 13,5:1 10-14 Race Piston 77 mm std bore 0910-20072 0913-00933 0913-0071 0912-0241
KLX400F 12,5:1 03-05 90 mm std bore 0910-2005 0913-0091 0913-0076 0912-0333
KX450F 13:1 04-08 96 mm std bore 0910-1102 0913-0063 0913-0072 0912-0243
KX450F 13,0:1 09-12 96 mm std bore 0910-1125 0913-0063 0913-0072 0912-0243
KX450F 13,5:1 09-12 Race Piston 96 mm std bore 0910-24471, 2 0913-00953 0913-0072 0912-0243
KTM
250SXF 13,5:1 06-10 76 mm std bore 0910-1107 0913-0062 0913-0071 0912-0245
250SXF 14,0:1 11-12 Race Piston 76 mm std bore 0910-24491, 2 0913-00933 0913-0071 0912-0245
450SX-F 13,0:1 07-10 97 mm std bore 0910-2010 0913-0063 0913-0072 0912-0334
450SX-F 13,5:1 07-10 97 mm std bore 0910-2011 0913-0063 0913-0072 0912-0334
450XC 12,0:1 08 89 mm std bore 0910-2014 0913-0067 0913-0076 0912-0252
450XC-G 12,5:1 05-07 95 mm std bore 0910-2008 0913-0067 0913-0076 0912-0253
450XC-G 13,5:1 05-07 95 mm std bore 0910-2009 0913-0067 0913-0076 0912-0253
505XC 13,0:1 07-10 Race Piston 100 mm std bore 0910-20132 0913-00963 0913-0076 0912-0336
525EXC/MXC 13,0:1 03-07 95 mm std bore 0910-1119 0913-0067 0913-0076 0912-0244
525EXC/MXC 12,0:1 03-07 95 mm std bore 0910-2012 0913-0067 0913-0076 0912-0253
SUZUKI
RMZ250 13,5:1 07-09 77 mm std bore 0910-1098 0913-0062 0913-0071 0912-0241
RMZ250-14,2:1 07-09 Race Piston 77 mm std bore 0910-24431, 2 0913-00933 0913-0071 0912-0241
RMZ250 13,5:1 10-14 77 mm std bore 0910-2004 0913-0062 0913-0071 0912-0241
DRZ400 12,5:1 00-09 90 mm std bore 0910-2005 0913-0091 0913-0076 0912-0333
RMZ450 13,0:1 05-07 95,5 mm std bore 0910-1099 0913-0063 0913-0072 0912-0242
RMZ450 13:1 08-14 96 mm std bore 0910-1100 0913-0063 0913-0072 0912-0242
YAMAHA
YZ250F/WR250F 13,5:1 01-04 77 mm std bore 0910-1103 0913-0062 0913-0071 0912-0241
YZ250F/WR250F 13,5:1 05-13 77 mm std bore 0910-1104 0913-0062 0913-0071 0912-0241
YZ250F/WR250F 14,0:1 05-13 Race Piston 77 mm std bore 0910-16511, 2 0913-00933 0913-0071 0912-0241
YZ250F 14,5:1 05-13 Race Piston 77 mm std bore 0910-16521, 2 0913-00933 0913-0071 0912-0241
YZ450F/WR450F 13,0:1 03-05 95 mm std bore 0910-1105 0913-0065 0913-0074 0912-0244
YZ450F/WR450F 13,5:1 06-09 95 mm std bore 0910-1106 0913-0065 0913-0074 0912-0244
YZ450F 13,0:1 10-14 Race Piston 97 mm std bore 0910-17182 0913-00943 0913-0074 0912-0334
YZ450F 13,75:1 10-14 Race Piston 97 mm std bore 0910-24411, 2 0913-00943 0913-0074 0912-0334
1 Use race fuel only.
2 Piston comes standard with skirt coating.
3 DLC wrist pins.
HIGH PERFORMANCE 4-STROKE PISTON KITS
BY CP PISTONS (CONT)
