All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
ENGINE
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
619
1
This Athena cylinder kit assembled with OE CDI and exhaust gets much more torque (Nxm) than OE bike; in order to strongly
increase horsepower to the wheel, it is necessary to use, at least, a racing exhaust system.
FITS MODEL
DESCRIPTION
PART #
HONDA
CRE50 Derapage
Cylinder kit with head (70cc) (big bore)
0931-0219
Competition/RR 07-11 Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
CRE50 Six/Baja/
Cylinder kit with head (70cc) (big bore)
0931-0219
Derapage RR 01-11 Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
CRE50 Baja RR 07-11 Cylinder kit with head (70cc) (big bore)
0931-0219
Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
CRF150R 07-10
Cylinder kit (69 mm big bore) 163,5cc
0931-0307
Repl. forged piston
0910-2002
Gasket kit
0934-1968
Repl. ring set
0912-0331
CRF250R 04-09,
Cylinder kit (82 mm big bore) 280cc
0931-0094
CRF250X 04-13
Forged piston kit A (81,95 mm piston)
0910-0646
Forged piston kit B (81,96 mm piston)
0910-0722
Gasket kit
0934-1054
Repl. rings
0912-0281
CRF250R 10-14
Cylinder kit (82 mm big bore) 284cc
0931-0428
Forged piston kit A (81,95 mm piston)
0910-2537
Forged piston kit B (81,96 mm piston)
0910-2538
Gasket kit
0934-2554
Repl. ring set
0912-0281
CRF450R 02-08
Cylinder kit (100 mm big bore) 490cc
0931-0014
1
Forged piston kit A (99,95 mm; 11,6:1 compression)
0910-0255
Forged piston kit B (99,96 mm; 11,6:1 compression)
0910-0723
Gasket kit
0934-0192
Repl. ring set
0912-0101
CRF450R 09-13
Cylinder kit (100 mm big bore) 490cc
0931-0327
Repl. forged piston (100 mm)
0910-2530
Gasket kit
0934-2546
Repl. ring set
0912-0374
CRF450X 05-14
Cylinder kit (100 mm big bore) 490cc
0931-0103
Forged piston kit A (99,95 mm)
0910-0255
Forged piston kit B (99,96 mm)
0910-0723
Gasket kit
0934-1529
Repl. ring set
0912-0101
HM
CRE 50 Derapage/
Cylinder kit with head (70cc) (big bore)
0931-0219
Baja 01-06
Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
CRE 50 Six 01-11
Cylinder kit with head (70cc) (big bore)
0931-0219
Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
CRE 50 Baja RR 07-11 Cylinder kit with head (70cc) (big bore)
0931-0219
Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
CRE 50 Derapage
Cylinder kit with head (70cc) (big bore)
0931-0219
RR 07-11
Racing cylinder kit with head (70cc) - 47,6 mm piston (big bore)0931-0236
Cylinder kit with head (50cc) - 40 mm piston (standard bore)
0931-0237
HUSQVARNA
SMR 250 03-05
Cylinder kit (300cc) (83 mm big bore)
0931-0241
SMR 250 06-07
Cylinder kit (300cc) (83 mm big bore)
0931-0240
TC 250 03-05
Cylinder kit (300cc) (83 mm big bore)
0931-0241
TC 250 06-07
Cylinder kit (300cc) (83 mm big bore)
0931-0240
TE 250 03-05
Cylinder kit (300cc) (83 mm big bore)
0931-0241
TE 250 06-07
Cylinder kit (300cc) (83 mm big bore)
0931-0240
TXC 250 03-05
Cylinder kit (300cc) (83 mm big bore)
0931-0241
TXC 250 06-07
Cylinder kit (300cc) (83 mm big bore)
0931-0240
FITS MODEL
DESCRIPTION
PART #
KAWASAKI
KX65 02-14
Cylinder kit (50 mm big bore) 80cc
0931-0107
Repl. Cast piston A (49,95 mm)
0910-0873
Repl. Cast piston A (49,96 mm)
0910-0874
Gasket kit
0934-1533
Repl. ring set
0912-0375
KX125 03-07
Cylinder kit (54 mm standard bore) 125cc
0931-0012
Cast-lite flat-top piston (53,94 mm piston)
0910-0253
Gasket kit
0934-0190
Repl. ring set
0912-0160
KX125 03-07
Cylinder kit (58 mm big bore) 144cc
0931-0109
Cast piston kit A (57,94 mm)
0910-0877
Cast piston kit B (57,95 mm)
0910-0878
Gasket kit
0934-2135
Repl. ring set
0912-0104
KX250F 04-08
Cylinder kit (83 mm) 290cc
0931-0026
Forged Rev dome piston kit A (82,95 mm piston)
0910-0310
Forged Rev dome piston kit B (82,96 mm piston)
0910-0725
Gasket kit
0934-0359
Repl. ring set
0912-0159
KX250F 09-10
Cylinder kit (83 mm big bore) 290cc
0931-0308
Forged piston kit A (82,95 mm)
0910-0883
Forged piston kit B (82,96 mm)
0910-0884
Gasket kit
0934-2136
Repl. ring set
0912-0159
KX250F 11-12
Cylinder kit (83 mm big bore) 290cc
0931-0471
Forged piston kit A (82,95 mm)
0910-0883
Forged piston kit B (82,96 mm)
0910-0884
Gasket kit
0934-2136
Repl. ring set
0912-0159
KX250F 13-14
Cylinder kit (83 mm big bore) 300cc
0931-0524
KLX400 03-06
Cylinder kit (94 mm big bore) 435cc
0931-0016
1
Forged Rev dome piston kit A (93,94 mm)
0910-0647
Gasket kit
0934-0194
Repl. ring set
0912-0103
KX450F 06-08/
Cylinder kit (100 mm big bore) 490cc
0931-0111
KLX450 08-13
Forged piston kit A (99,95 mm piston)
0910-0881
Forged piston kit B (99,96 mm piston)
0910-0882
Gasket kit
0934-1536
Repl. ring set
0912-0101
KX450F 09-14
Cylinder kit (100 mm big bore) 493cc
0931-0328
Repl. forged piston (100 mm)
0910-2535
Gasket kit
0934-2552
Repl. ring set
0912-0374
KTM
65 SX 01-08
Cylinder kit (50 mm big bore) 80cc
0931-0245
Cast piston kit A (49,95 mm piston)
0910-1328
Cast piston kit B (49,96 mm piston)
0910-1329
Gasket kit
0934-1841
Repl. ring set
0912-0282
250 EXC-F/
Cylinder kit (80 mm big bore) 277cc
0931-0468
Six Days 12-13
Forged piston kit A (79,96 mm)
0910-2536
Forged piston kit B (79,97 mm)
0910-2765
Gasket kit
0934-2898
Repl. ring set
0912-0378
250 SX 14
Repl. ring set
0912-0471
250 SX-F 06-10
Cylinder kit (80 mm big bore)
0931-0427
Repl. forged piston
0910-2536
Gasket kit
0934-2553
Repl. ring set
0912-0378
CYLINDER
KITS
•Athena cylinder kits are bolt-on
performance replacement
kits specifically designed for
each application
•Kits include an aluminum
cylinder with nickel-carbide
coating designed with
wider water jackets
•Forged piston with
molybdenum coating
•Special gasket kit included
CYLINDER KITS continued on next page.
2-stroke cylinder kit
4-stroke cylinder kit
