621
FITS MODEL
DESCRIPTION
COMPRESSION
RATIO
BORE
(MM) PART #
HONDA
CRF150R 07‑09 Standard Bore kit
11,7:1
66
0931‑0269
Standard Bore High Compression kit ‑
66
0931‑0288
+2 mm Big Bore, 159cc kit
11,7:1
68
0931‑0172
CRF150R 07‑14 Standard Bore gasket kit
‑
‑
0934‑1930
Standard Bore Cylinder (only)
‑
66
0931‑0163
+2 mm Big Bore gasket kit
‑
‑
0934‑1697
CRF150R 12‑14 Standard Big Bore kit
11,7:1
66
0931‑0486
Standard Bore High Compression 12,2:1
66
0931‑0487
+2 mm Big Bore 159cc kit
11,7:1
66
0931‑0485
CRF250X 04‑14/
CRF250R 04‑09 Standard Bore Cylinder (only)
‑
78
0931‑0128
CRF250X 04‑14/ Standard Bore kit
12,9:1
78
0931‑0270
CRF250R 04‑07 Standard Bore High Compression kit 13,4
78
0931‑0289
Standard Bore gasket kit
‑
‑
0934‑1931
CRF250R 08‑09 Standard Bore kit
13,0:1
78
0931‑0271
Standard Bore High Compression kit ‑
78
0931‑0290
CRF250R 04‑09 Standard Bore gasket kit
‑
‑
0934‑1931
CRF250R 10‑14 Standard Bore Cylinder (only)
‑
76,8 0931‑0392
Standard Bore High Compression kit 14,1:1
76,8 0931‑0339
CRF250R 10‑13 Standard Bore kit
13,2:1
76,8 0931‑0338
+3,2 mm Big Bore, 270cc kit
13,2:1
80
0931‑0340
Standard Bore gasket kit
‑
‑
0934‑2146
+3,2 mm Big Bore gasket kit
‑
‑
0934‑2383
CRF250X 04‑14/ +3 mm Big Bore, 269cc kit
13,0:1
81
0931‑0118
1
CRF250R 04‑09 +3 mm Big Bore gasket kit
‑
‑
0934‑1521
CRF250X 04‑14/ +1 mm Big Bore, 256cc kit
13,0:1
79
0931‑0173
CRF250R 04‑09 +1 mm Big Bore gasket kit
‑
‑
0934‑1698
FITS MODEL
DESCRIPTION
COMPRESSION
RATIO
BORE
(MM) PART #
HONDA (CONT)
CRF450R 02‑08 Standard Bore Cylinder (only)
‑
96
0931‑0129
Standard Bore kit
12,1:1
96
0931‑0272
Standard Bore High Compression kit 12,5:1
96
0931‑0291
+4 mm Big Bore, 488cc kit
12,1:1
100 0931‑0119
Standard Bore gasket kit
‑
‑
0934‑1932
Big Bore gasket kit
‑
‑
0934‑1522
CRF450R 09‑12 Standard Bore kit
12,0:1
96
0931‑0273
Standard Bore High Compression kit 12,9:1
96
0931‑0292
+ 3 mm Big Bore, 478cc kit
12,0:1
99
0931‑0266
CRF450R 09‑14 Standard Bore Cylinder (only)
‑
96
0931‑0391
Standard Bore gasket kit
‑
‑
0934‑1933
Big Bore gasket kit
‑
‑
0934‑1927
CRF450R 13‑14 Standard Bore kit
12,5:1
96
0931‑0489
Standard Bore High Compression kit 13,2:1
96
0931‑0490
+ 3 mm Big Bore 478cc kit
12,0:1
99
0931‑0488
CRF450X 05‑14 Standard Bore Cylinder (only)
‑
0931‑0393
Standard Bore kit
12,1:1
96
0931‑0274
Standard Bore High Compression kit 12,5:1
96
0931‑0293
+3 mm Big Bore kit
12,1:1
99
0931‑0267
Standard Bore gasket kit
‑
‑
0934‑1934
+3 mm Big Bore gasket kit
‑
‑
0934‑1928
KAWASAKI
KX250F 04‑08
Standard Bore Cylinder (only)
‑
77
0931‑0130
Standard Bore gasket kit
‑
‑
0934‑1935
KX250F 04‑05
Standard Bore kit
12,6:1
77
0931‑0275
Standard Bore High Compression kit 13,3:1
77
0931‑0294
KX250F 06‑08
Standard Bore kit
13,5:1
77
0931‑0276
Standard Bore gasket kit
‑
‑
0934‑1935
CYLINDERS AND CYLINDER KITS
•Ready-to-install, direct bolt-on cylinders require no re-plating and look virtually identical to the OEM cylinders
•Three kit options to choose from: Standard Bore, Standard Bore Hi-Compression and Big Bore
•Cylinder kits include matched Vertex pistons to ensure longevity, performance and reduced engine noise
•Nickel Silicon Carbide plated for long life
•Kits come complete with gaskets, cylinder, piston, rings, pin and clips
•Big bore cylinders do not require machine work (unless noted)
•Replacement Vertex piston, rings, clips and pins also available; see pages 601-616
1
Requires case machining; instructions included.
CYLINDERS AND CYLINDER KITS continued on next page.
1
Requires case machining; instructions included.
