620
FITS MODEL
DESCRIPTION
PART #
KTM (CONT)
250 SX-F 11-12
Cylinder kit (80 mm big bore) 277cc
0931-0468
Forged piston kit A (79,96 mm)
0910-2536
Forged piston kit B (79,97 mm)
0910-2765
Gasket kit
0934-2898
Repl. ring set
0912-0378
250 SX-F 13-14
Cylinder kit (82 mm standard bore) 280cc
0931-0525
Forged Piston Kit A (81,95 mm)
0910-3414
Forged Piston Kit B (81,96 mm)
0910-3415
250 XC-F 09-12,
Cylinder kit (80 mm big bore) 277cc
0931-0468
XCF-W 07-13
Forged piston kit A (79,96 mm)
0910-2536
Forged piston kit B (79,97 mm)
0910-2765
Gasket kit
0934-2898
Repl. ring set
0912-0378
350 EXC-F 12-13
Cylinder kit (90 mm big bore) 365cc
0931-0472
Repl. forged piston (89,96 mm)
0910-2764
Gasket kit
0934-2897
Repl. ring set
0912-0429
350 EXC-F 12-13
Cylinder kit (88 mm standard bore)
0903-0943
Forged piston kit A (87,95 mm)
0910-2766
Forged piston kit B (87,96 mm)
0910-2767
Gasket kit
0934-2899
Repl. ring set
0912-0430
350 Freeride/EXC-F Cylinder kit (90 mm big bore)
0931-0472
Six Days 13
Repl. forged piston (89,96 mm)
0910-2764
Gasket kit
0934-2897
Repl. ring set
0912-0429
350 Freeride/EXC-F Cylinder kit (88 mm standard bore)
0903-0943
Six Days 13
Forged piston kit A (87,95 mm)
0910-2766
Forged piston kit B (87,96 mm)
0910-2767
Gasket kit
0934-2899
Repl. ring set
0912-0430
350 SX-F 11-14
Cylinder kit (90 mm big bore) 365cc
0931-0467
Repl. forged piston (89,96 mm big bore)
0910-2764
Gasket kit
0934-2897
Repl. ring set
0912-0429
350 SX-F 11-14
Cylinder kit (88 mm standard bore) 350cc
0931-0469
Forged piston kit A (87,95 mm)
0910-2766
Forged piston kit B (87,96 mm)
0910-2767
Gasket kit
0934-2899
Repl. ring set
0912-0430
350 XC-F 11-13
Cylinder kit (90 mm big bore) 365cc
0931-0467
Repl. forged piston (89,96 mm)
0910-2764
Gasket kit
0934-2897
Repl. ring set
0912-0429
350 XC-F 11-13
Cylinder kit (88 mm standard bore) 350cc
0931-0469
Forged piston kit A (87,95 mm)
0910-2766
Forged piston kit B (87,96 mm)
0910-2767
Gasket kit
0934-2899
Repl. ring set
0912-0430
350 XCF-W 12
Cylinder kit (90 mm big bore)
0931-0472
Repl. forged piston
0910-2764
Gasket kit
0934-2897
Repl. ring set
0912-0429
350 XCF-W 12
Cylinder kit (88 mm standard bore)
0903-0943
Forged piston kit A (87,95 mm)
0910-2766
Forged piston kit B (87,96 mm)
0910-2767
Gasket kit
0934-2899
Repl. ring set
0912-0430
SUZUKI
RM-Z250 04-06
Cylinder kit (83 mm big bore) 290cc
0931-0026
Forged Rev dome piston kit A (82,95 mm piston)
0910-0310
Forged Rev dome piston kit B (82,95 mm piston)
0910-0725
Gasket kit (83 mm)
0934-0359
Repl. ring set
0912-0159
RM-Z250 07-09
Cylinder kit (83mm big bore) 290cc
0931-0112
Forged piston kit A (82,95 mm)
0910-0883
Forged piston kit B (82,96 mm)
0910-0884
Gasket kit
0934-1537
Repl. ring set
0912-0159
RM-Z250 10-14
Cylinder kit (83 mm big bore) 290cc
0931-0330
Forged piston kit A (82,95 mm)
0910-0883
Forged piston kit B (82,96 mm)
0910-0884
Repl. ring set
0912-0159
DR-Z400 00-12
Cylinder kit (94 mm big bore) 435cc
0931-0016
1
Forged Rev dome piston kit A (93,94 mm)
0910-0647
Gasket kit
0934-0194
Repl. ring set
0912-0103
RM-Z450 05-06
Cylinder kit (100 mm big bore) 490cc
0931-0114
Forged piston kit A (99,95 mm piston)
0910-0885
Gasket kit
0934-1538
Repl. ring set
0912-0101
FITS MODEL
DESCRIPTION
PART #
SUZUKI (CONT)
RM-Z450 08-12
Cylinder kit (96 mm stock bore) 450cc
0931-0250
Forged piston kit A (95,96 mm piston)
0910-1334
Forged piston kit B (95,97 mm piston)
0910-1335
Gasket kit
0934-1844
Repl. ring set
0912-0354
RM-Z450 08-12
Cylinder kit (100 mm kit big bore) 490cc
0931-0251
Forged piston kit A (99,95 mm piston)
0910-1336
Gasket kit
0934-1845
Repl. ring set
0912-0374
YAMAHA
YZ85 02-14
Cylinder kit (53 mm big bore; stock stroke) 105cc
0931-0473
Cylinder kit (53 mm big bore; stock stroke) 112cc
0931-0474
Forged piston kit A (52,95 mm piston)
0910-2780
Forged piston kit B (52,96 mm piston)
0910-2781
Gasket kit
0934-2912
Repl. ring set
0912-0434
YZ125 97-04
Cylinder kit (54 mm standard bore) 125cc
400485100003
2
Repl. cast piston kit
0910-0669
Gasket kit
400485160003
Repl. ring set
0912-0160
YZ125 97-04
Cylinder kit (58 mm big bore) 144cc
0931-0258
4
Gasket kit
0934-3117
Repl. cast piston kit
0910-0648
Repl. ring set
0912-0104
YZ125 Race 01-04
Race cylinder kit (54 mm standard bore) 125cc
400485100008
3
Gasket kit
400485160003
YZ125 05-14
Cylinder kit (54 mm standard bore; high compression)
0931-0095
Repl. cast piston kit
0910-0669
Gasket kit
0934-1055
Repl. ring set
0912-0160
YZ125 05-14
Cylinder kit (58 mm big bore) 144cc
0931-0146
4
Repl. cast piston kit
0910-0648
Gasket kit
0934-1578
Repl. ring set
0912-0104
WR250R/X 08-14
Cylinder kit
0931-0479
Forged piston kit A (82.95 mm)
0910-1338
Forged piston kit B (82.96 mm)
0910-1339
Gasket kit
0934-1846
YZ250LC 03-14
Cylinder kit (72 mm big bore) 294cc
0931-0440
Forged piston kit A (71,95 mm)
0910-2666
Forged piston kit B (71,96 mm)
0910-2667
Gasket kit
0934-2584
Repl. ring set
0912-0428
YZ250LC 03-14
Cylinder kit (72 mm big bore) 294cc
0931-0470
Forged piston kit A (71,95 mm)
0910-2666
Forged piston kit B (71,96 mm)
0910-2667
Gasket kit
0934-2584
Repl. ring set
0912-0428
YZ250F 08-13
Cylinder kit (83 mm big bore) 290cc
0931-0248
Forged piston kit A (82,95 mm)
0910-1330
Forged piston kit B (82,96 mm)
0910-1331
Gasket kit
0934-0357
Repl. ring set
0912-0159
YZ250F 01-07/
Cylinder kit (83 mm big bore) 290cc
0931-0024
WR250F 01-12
Forged Rev dome piston kit A (82,95 mm)
0910-0308
Forged Rev dome piston kit B (82,96 mm)
0910-0727
Gasket kit
0934-0357
Repl. ring set
0912-0159
YZ450F 03-05/
Cylinder kit (98 mm big bore) 478cc
0931-0020
WR450F 03-06
Forged Rev dome piston kit A (97,94 mm)
0910-0304
Gasket kit
0934-0355
Repl. ring set
0912-0105
WR450F 07-11
Cylinder kit (98 mm big bore) 478cc
0931-0098
Forged Rev dome piston kit A (97,94 mm)
0910-0304
Gasket kit
0934-1057
Repl. ring set
0912-0105
YZ450F 06-09
Cylinder kit (98 mm big bore) 478cc
0931-0098
Forged Rev dome piston kit A (97,94 mm)
0910-0304
Gasket kit
0934-1057
Repl. ring set
0912-0105
YZ450F 10-13
Cylinder kit (102 mm big bore) 500cc
0931-0429
Repl. forged piston
0910-2539
Gasket kit
0934-2555
Repl. ring set
0912-0379
1
This Athena cylinder kit assembled with OE CDI and exhaust gets much more torque (Nxm) than OE
bike; in order to strongly increase horsepower to the wheel, it is necessary to use, at least, a racing
exhaust system.
2
YZ125 97-98 models require the use of a 99 or newer exhaust pipe and silencer.
3
For 97-98 models you must use a 99 exhaust and an 01 cylinder head; for 99-00 models you must
use an 01 cylinder head.
4
May require case boring.
CYLINDER KITS (CONT)
