All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
FUEL/AIR SYSTEMS
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
774
DYNOJET QUICK
SHIFTER (DQS)
SENSORS USB/V
•Races are won or lost in fractions of a second
•Dynojet’s Quick Shifter (DQS) kit allows full-throttle, clutchless upshifts in racing and
performance riding applications
•The shift rod pressure/tension sensor kit is a universal sensor that mounts to the
shift rod in either a push or pull configuration
•Requires modification of gear-linkage tie-rod
•The linear travel sensor kit works with bikes that have no shift rod,
or on those the shift rod sensor will not fit
•Mount one end to the shift lever and the other to a fixed point on the chassis
•Push- or pull-types available with universal mounting kit
•Plugs directly into the Power Commander expansion port with no re-wiring required
•Power Commander Control Center software lets you set engine dead-time during upshifts and minimum rpm
for system operation
•PART #s 1601-0327 and 1601-0328 are “linear” sensors for PCIII USB
•PART #s 1601-0329 and 1601-0330 are “linear” sensors for PCV
NOTE: To order either of the above sensors, you must find the correct direction of movement during an upshift (push or pull). For the shift rod/pressure/tension sensor,
press on the shift lever in the direction of an upshift to see if the rod is pushing or pulling on the clevis on the shift shaft. For the linear travel sensor, also move
the shifter for an upshift. If movement is down, a pull sensor is needed. If movement is up, a push sensor is required.
IMPORTANT NOTE:
SEE PAGE 729 FOR IMPORTANT INFORMATION REGARDING CERTAIN WARRANTY AND EMISSION CONTROL REGULATORY
COMPLIANCE INFORMATION.
PART #
1601-0331
UNIVERSAL
QUICK SHIFTER
IGNITION MODULE
•Allows any vehicle with 4-cylinders
or less (M/C, ATV, Mini sprint, etc.) to use
Quick Shifter functionality without
a Power Commander
•Control unit can toggle between “road” and “race”
settings, depending on usage
•Compatible with PC III USB style quick shifter sensors
•Includes all necessary wires and connectors
PART #
1020-0988
EXHAUST SERVO
REMOVAL MODULE
FOR YAMAHA WR250R/X 08-09
•Eliminates the need for a heavy, bulky,
exhaust servo motor and cable assembly
when installing full exhaust systems on
late Yamaha models
•Keeps the FI light from coming on unless
there is a “real” problem with the
bike’s systems
•Decreases the weight of the bike and adds space for
additional components
DESCRIPTION
PART #
MX sensor (push type)
1601‑0319
MX Kit
1601‑0320
Quickset adjuster for MX kit
1601‑0321
Shift rod linear sensor (pull type)
1601‑0327
Shift rod linear sensor (pull type) for Power Commander V
1601‑0329
DESCRIPTION
PART #
Shift rod linear sensor (push type, includes mounting kit)
1601‑0328
Shift rod linear sensor (push type,
includes mounting kit) for Power Commander V
1601‑0330
Handlebar‑mounted shift button (used only when tension
or linear sensor cannot be used)
2106‑0175
FITS MODEL
PART #
BMW
G650 Xchallenge 07-11
1861-0848
G650 Xmoto 07-11
1861-0848
G650 Xcountry 07-11
1861-0848
R1200GS (72 kw) 03-08
1861-0848
FITS MODEL
PART #
BMW (CONT)
R1200GS (77 kw) 07-
1861-0848
R1200GS Adventure 08-
1861-0848
R1200R 06-10
1861-0848
R1200RT 04-09
1861-0848
FITS MODEL
PART #
BMW (CONT)
R1200S 05-07
1861-0848
R1200ST 04-08
1861-0848
HUSQVARNA
TE450 07-13
1861-0850
FITS MODEL
PART #
HUSQVARNA (CONT)
SM450R 07-13
1861-0850
SM510R 07-13
1861-0850
SM610 07-13
1861-0850
LAMBDA SENSORS
•NGK is the leading supplier of
lambda sensors
in the motorcycle industry
•These sensors provide perfect fuel
mixture and guarantee optimal
working conditions for the catalytic converter
1861‑0850
1861‑0848
1601-0328
1601-0327
2106-0175
