STEPLESS
®
EAR CLAMP KIT
FOR FUEL SYSTEM
•Convenient kit includes 70 pieces of hardware, a Motion Pro Side
Jaw Pincer tool, and a convenient fuel line clamp size chart
•Narrow 5 mm wide band provides concentrated seal compression
•360° Stepless
®
design with no gaps on inner surface
•Specially formed strip edges reduce the risk of damage to the part
being clamped
•Lightweight design
•Tampering is visible
•Kit includes 10 each of the clamps listed below in a convenient storage box
•Individual clamp sizes available separately in 10-pack for restocking
784
IMPORTANT NOTE:
SEE PAGE 729 FOR IMPORTANT INFORMATION REGARDING CERTAIN WARRANTY AND EMISSION CONTROL REGULATORY
COMPLIANCE INFORMATION.
FUEL LINE
BODY LENGTH
BETWEEN HOSES DIAMETER
PART #
6,4 mm i.d. (
1
/
4
”)
25,4 mm (1”)
33 mm (1,3”)
401C
6,4 mm i.d. (
1
/
4
”)
41,3 mm (1,625”)
22,2 mm (0,875”)
0707‑0003
6,4 mm i.d. (
1
/
4
”)
50,8 mm (2”)
22,4 mm (0,88”)
701C
6,4 mm i.d. (
1
/
4
”)
57,2 mm (2,25”)
30,2 mm (1,19”)
707C
FUEL LINE
BODY LENGTH
BETWEEN HOSES DIAMETER
PART #
6,4 mm i.d. (
1
/
4
”)
76,2 mm (3”)
30,2 mm (1,19”)
704C
4,8 mm i.d. (
3
/
16
”)
12,7 mm (0,5”)
28,6 mm (1,125”)
901C
7,9 mm i.d. (
5
/
16
”)
25,4 mm (1”)
38,1 mm (1,5”)
601C
6,4 mm or 7,9 i.d. (
1
/
4
” or
5
/
16
”)
90,4 mm (3,558”)
41,3 mm (1,625”)
0707‑0009
IN-LINE FUEL FILTERS
•Available in sizes to fit 6,4 mm; 4,8 mm, and 7,9 mm
fuel lines (
1
/
4
”,
3
/
16
” and
5
/
16
”)
•High-impact nylon housings
•Sonically welded for no-leak, no-break performance
•PART #s 707C and 0707-0003 operate 90° in-out
to save space in very close applications where a
normal straight in-line filter would not work
•Sold as a display card of 20; suggested retail is each
DESCRIPTION
PART #
Fuel system stepless clamp kit
2402‑0132
Stepless clamps; 7,8‑9,5 mm (fit Motion Pro Premium and clear vinyl 4,8 mm (
3
/
16
”) i.d. fuel line) (10‑pk.)
2401‑0557
Stepless clamps, 8,8‑10,5mm (fit Motion Pro Low Permeation yellow fuel line w/ 6,4 mm (
1
/
4
”) i.d.) (10‑pk.)
2401‑0819
Stepless clamps; 9,6‑11,13 mm (fit Motion Pro Premium and clear vinyl 4,8 mm (
3
/
16
”) i.d. fuel line) (10‑pk.)
2401‑0716
Stepless clamps; 10,3‑12,8 mm (fit Motion Pro Premium 6,4 mm (
1
/
4
”) i.d. fuel line) (10‑pk.)
2401‑0558
Stepless clamps; 10,8‑13,3 mm (fit Motion Pro clear vinyl 6,4 mm (
1
/
4
”) i.d. fuel line) (10‑pk.)
2401‑0559
Stepless clamps; 12,0‑14,5 mm (fit Motion Pro Premium and clear vinyl 7,9 mm (
5
/
16
”) i.d. fuel line) (10‑pk.)
2401‑0560
Stepless clamps; 13,2‑15,7 mm (10‑pk.)
2401‑0717
Stepless clamps; 14,8‑18,0 mm (fit Motion Pro Premium and clear vinyl 9,5 mm (
3
/
8
”) i.d. fuel line) (10‑pk.)
2401‑0561
Front jaw pincer tool (optional, not included w/ kit)
3801‑0034
Side jaw pincer tool
3801‑0182
DESCRIPTION
PART #
7,9 mm (
5
/
16
”) aluminum machined satin‑finish fuel filter
DS‑391663
Repl. brass 40 micron filter element
DS‑391666
IN-LINE FUEL FILTER
•High-flow custom fuel filter available in
a machined satin finish
•High-quality O-ring for a leak-proof seal
•Cleanable, reusable 40 micron filter element
•Works great with Pingel’s high-volume fuel valves
•Made in the U.S.A.
PART #
700A
CLEAR FILTER
•A greatly improved filter with
a larger fuel flow
•79,4 mm long (3
1
/
8
”) for 4,8 mm-
6,4 mm fuel line (
3
/
16
”-
1
/
4
”)
PART #
707
JUMBO-TYPE FILTER
•For use with 6,4 mm-7,9 mm fuel
lines (
1
/
4
”-
5
/
16
”)
•Overall length 102 mm (4”)
0707‑0003
0707‑0009
401C
601C
701C
704C
707C
901C
DS‑391666
DS‑391663
2402‑0132
2401‑0559
