IMPORTANT NOTE:
SEE PAGE 729 FOR IMPORTANT INFORMATION REGARDING CERTAIN WARRANTY AND EMISSION CONTROL REGULATORY
COMPLIANCE INFORMATION.
PART #
85-2437
FUEL/AIR RATIO MONITOR
•The ultimate tool for precise jetting and carb tuning
•Indicates lean, rich and correct mixtures on a bar scale
•Oxygen sensor installation requires welding a fitting to the
headpipe collector
•Monitor can be temporarily mounted for performance testing (requires 9-12V power source)
•Works with 2- or 4-stroke gas engines including those with nitrous oxide setup
•Not recommended for use with nitromethane fuel
•Surface-mount monitor features 10 easy-to-read LEDs
PART #
1050-0229
WIDEBAND AIR/FUEL RATIO METER
•Highly visible, backlit digital display
•Allows more precise tuning
•Programmable warning alerts rider of too lean or too rich ratio
•Displays ratio between 10,0-24,0
•Includes Bosch O
2
sensor, sensor bung, sensor bung cap and gauge bracket
•Measures 99 mm W x 43 mm H x 23 mm D (3,9” x 1,7” x 0,9”)
•Recommended for use with 4-stroke
engines; for 2-stroke applications,
use O
2
adapter PART #1861-0524
PART #
1050-0230
MINI AIR/FUEL
RATIO METER
FOR 4-STROKE
ENGINES
•Compact air-fuel ratio meter
with backlit digital display
•Internal battery allows meter to be moved from bike to bike without
disconnecting power wires; battery life is about 2.000 hours
•Unit can also be hardwired to power source (backlight only functions with
hardwired power)
•Displays range between 12,1-16,8
•Includes O
2
sensor
•Measures 61 mm W x 34 mm H x
15 mm D (2,42” x 1,33” x 0,61”)
NARROW BAND AIR/
FUEL RATIO METER
FOR 4-STROKE ENGINES
•Highly visible, backlit digital display
with a chrome bezel
•Allows precise tuning of the engine
•Measures 55 mm (2,15”) dia.; 61 mm
(2,4”) dia. w/ bezel
•Includes O
2
sensor and gauge bracket
PART #
1050-0231
PART #
1861-0525
WELD-ON EGT BUSHING
•Allows installation of exhaust gas
temperature meter
•Sold each
PART #
1861-0521
WIDE-BAND
BOSCH O
2
SENSOR
•For use with air/fuel ratio meters
PART #
2212-0283
NARROW BAND
O
2
SENSOR
•For use with KOSO’s narrow band
air/fuel ratio meter
(PART #1050-0231) and other
like gauges
PART #
1861-0524
O
2
SENSOR BUNG
ADAPTER
FOR 2-STROKE ENGINES
•For use with wideband air/fuel
ratio meters
DESCRIPTION
PART #
O
2
sensor bung, plug and washer set
1861‑0728
Weld‑in O
2
sensor bung
1861‑0523
O
2
sensor bung plug
1861‑0522
Aluminum washer for O
2
sensor plug
1860‑0545
O
2
SENSOR BUNG, PLUG AND WASHER
•Available as a set or individually
•Weld-in O
2
sensor bung allows installation of O
2
sensors in any exhaust
system; 18 mm x 1,5p
•O
2
sensor bung plug works with any O
2
sensor bung; 18 mm x 1,5p
•Aluminum bung plug washer fits any 18 mm O
2
sensor bung plug
1861‑0523
1861‑0522
1860‑0545
