837
DESCRIPTION
PART #
3‑in‑1 Trueing Stand
35‑9573
3-IN-1 TRUING STAND
•Check your cranks and fork tubes
for run-out; true spoke wheels;
balance spoke and cast wheels
•28 cm (11”) between points
•Handles rims up to 21”
•Dial indicator not included;
available separately
•Indicator arm assembly included
(for PART #35-8428)
DESCRIPTION
PART #
Metric Engine Stand
0950‑0004
MC25 METRIC
ENGINE STAND
•Makes pan removals,
transmission repairs,
starter clutch replacement
and much more a snap
•Adjusts easily in width
and height to fit a wide
range of enginetypes,
including in-line four and
six cylinders
•Engine can be rotated a full 360°
in stand to make repairs easy
DESCRIPTION
PART #
Crankshaft Assembly Fixture 3801‑0152
SINGLE CYLINDER
CRANKSHAFT
ASSEMBLY FIXTURE
•Assemble single cylinder
crankshafts including Honda tin
can cranks
•Set includes assembly fixture plus
17 mm, 20 mm, 22 mm, 25 mm,
28 mm, 30 mm and 32 mm axle
bushing adapters
DESCRIPTION
PART #
Magnetic Base
3850‑0014
MAGNETIC BASE FOR DIAL INDICATORS
•For use with dial indicator gauge
•Features an easy-to-use
on-off knob
•Flexible indicator mounting
arm locks into place to make any job easy
DESCRIPTION
PART #
Dial Indicator Gauge
3850‑0013
DIAL INDICATOR GAUGE
WITH MAGNETIC BASE
•Reads 1,0” in increments of 0,001”
•Gauge can be locked for a zero setting
•Includes magnetic base stand that has an
adjustable dial indicator mounting arm for a wide
range of applications
DESCRIPTION
PART #
Dial Indicator Gauge
35‑8428
DIAL
INDICATOR
GAUGE
FOR 3-IN-1
TRUING STAND
•Dial indicator gauge
features 57,2 mm
(2
1
/
4
”) face with 1”
sweep in 0,001” increments
•Use with 3-in-1 Truing Stand
PART #35-9573
DESCRIPTION
PART #
Blind Bearing Removal Set
3812‑0003
BLIND BEARING REMOVAL SET
•Set includes 30, 25, 20, 17, 15, 12, 10 and 8 mm collets
•0,9 kg (2 lb) hammer
•Crossbar-type shaft allows easy collet removal
•Necessary tool for most transmission rebuilds
•Can be used for wheel bearing removal
•Fitted storage box included
DESCRIPTION
PART #
Stud Installation Tools
3812‑0011
STUD INSTALLATION TOOLS
•Will install cylinder studs on most engines
•Hex head is
3
/
4
” or 19 mm
•Sold in a set with three metric sizes: 6 mm x
1,00, 8 mm x 1,00 and 10 mm x 1,00
•Made in the U.S.A.
