842
VALVE GUIDE BALL HONES
•Durable enough to size C630 bronze and cast iron valve
guide materials
•Available from 4 mm up to
3
/
8
” widths
•Sold each
•Made in the U.S.A.
SIZE
PART #
4 mm
3801‑0217
4,5 mm
3801‑0218
5 mm
3801‑0219
5,5 mm
3801‑0220
SIZE
PART #
7 mm
3801‑0221
5
/
16
”
3801‑0222
3
/
8
”
3801‑0223
VALVE
ADJUSTMENT
KIT
•Universal six-piece tappet
adjusting set includes 8
mm, 9 mm and 10 mm wrenches
with square tip and straight slot
adjusters; fits most 4-stroke
motorcycles and ATVs
•Made in the U.S.A.
DESCRIPTION
PART #
Valve Adjustment Kit
3812‑0020
TAPPET
ADJUSTER SET
•Heat-treated and chrome-plated for durability
•Set includes three wrenches: 8, 9 and 10 mm and three adjusters: screw
type and 3 and 4 mm square-type
•Interchange adjusters and wrenches for nine different combinations
•Fits most motorcycles and ATVs with screw-type tappet adjusters
DESCRIPTION
PART #
Tappet Adjuster Set
P523
BLADE FEELER GAUGES
•For ignition and general purpose measuring
•Blades measure
76,2 mm L x 12,7 mm W (3” x
1
/
2
”)
•Made of tempered 1095 spring steel
•The sizes, both decimal and metric
equivalent, are permanently etched on
each blade
•PART #3801-0247 contains 32 76,2 mm x 12,7 mm (3” x
1
/
2
”) blades with
thicknesses: 0,0015; 0,002; 0,0025; 0,003; 0,004; 0,005; 0,006; 0,007; 0,008; 0,009;
0,010; 0,011; 0,012; 0,013; 0,014; 0,015; 0,016; 0,017; 0,018; 0,019; 0,020; 0,021;
0,022; 0,023; 0,024; 0,025; 0,026; 0,028; 0,030; 0,032; 0,035; and 0,010 brass
blade for transistorized engines
•PART #3801-0248 contains 26 76,2 mm x 12,7 mm (3” x
1
/
2
”) blades with
thicknesses: 0,0015; 0,002; 0,0025; 0,003; 0,004; 0,005; 0,006; 0,007; 0,008; 0,009;
0,010; 0,011; 0,012; 0,013; 0,014; 0,015; 0,016, 0,017; 0,018; 0,019; 0,020; 0,021;
0,022; 0,023; 0,024; 0,025
•Made in the U.S.A.
DESCRIPTION
PART #
32‑Blade feeler gauge with 0,010 brass blade
3801‑0247
26‑Blade feeler gauge
3801‑0248
3801-0248
P555
TAPPET FEELER
GAUGES
•Allow accurate
tappet adjustments
•Angled blade for easy access
to tappets
•Make valve adjustments quick and easy
•Packed six per display card; sold each
•Assortment includes two of each size; sold each
•Made in the U.S.A.
SIZE
PART #
0,05mm-0,08mm (0,002”-0,003”)
P552
0,10mm-0,13mm (0,004”-0,005”)
P553
SIZE
PART #
0,15mm-0,20mm (0,006”-0,008”)
P554
Assortment
P555
MULTIMETER VOLT
PROBE KIT
•Assortment of color-coded, sharp probes
for precise, back probing and non-
damaging diagnostics when working
with sealed connectors and wiring harnesses
•Standard 4mm banana plug connections work with most multimeter leads
•180°, 45°, 90° probes for hard-to-reach terminals as well as standard
alligator clips
•All probes are fully insulated with 30 volt protection
•Made in the U.S.A.
DESCRIPTION
PART #
26‑blade offset feeler gauge
3801‑0249
26-BLADE
OFFSET FEELER
GAUGE
•Contains 26 10 cm x 13 mm (4” L x
1
/
2
” W) blades with thicknesses: 0,005;
0,006; 0,007; 0,008; 0,009; 0,010; 0,011; 0,012; 0,013; 0,014; 0,015; 0,016;
0,017; 0,018; 0,019; 0,020; 0,021; 0,022; 0,023; 0,024; 0,025; 0,026; 0,027;
0,028; 0,029; 0,030
•Made of tempered 1095 spring steel
•Equipped with knurled lock-nut, which releases the blades instantly
for rapid selection of size desired and when tightened locks the
individual blade into the working position, retaining the blades not in use
firmly to handle
•10 cm (4”) long blades have 25 mm (1”) 45° offset for checking
valve clearances
•The sizes, both inch and metric equivalent, are permanently etched on
each blade
•Made in the U.S.A.
DESCRIPTION
PART #
Feeler Gauge/Spark Plug Gap Tool
3807‑0013
FEELER GAUGE/SPARK
PLUG GAP TOOL
FOR KTM 250/450/525
4-STROKES 02-06
•For checking intake and exhaust valve clearance
(0,12mm/0,005”)
•For checking the spark plug gap (0,60 mm/0,024”)
•Angled and tapered blade for easy access
•Makes valve and spark plug gap adjustments quick and easy
•Sold to dealer in pack of six on a display card; sold to
consumer as each
DESCRIPTION
PART#
Multimeter probe kit
3807‑0224
