851
DESCRIPTION
PART #
Inner Damper Rod Holding Tool
SS‑25
INNER DAMPER ROD
HOLDING TOOL
•Provides a positive means of holding
the inner damper rod while removing
the bolt from the bottom of the fork leg
•Square 9,5 mm (
3
/
8
”) drive
•Fits most Kawasaki KDX, KX, KZ and Z
series models
FORK TUBE TOOL
•For use when assembling and disassembling
the fork tube from the axle lugs
DESCRIPTION
PART #
Professional Fork Oil Level Tool
TFOL02
PROFESSIONAL FORK OIL LEVEL TOOL
•Same easy-to-use qualities as Race Tech’s standard fork oil level tool in
a durable, professional package
•CAD-designed, it’s made of CNC-machined aluminum for maximum
strength and minimal weight
•Components are anodized for protection and an attractive finish
•Collapsible stainless steel tube has etched measurement increments for
easy, accurate fork oil level readings
DESCRIPTION
PART #
Fork Oil Level Gauge
MP08‑121
FORK OIL LEVEL GAUGE
•For checking and adjusting the oil level on all conventional and
inverted forks
•Adjustable ring will measure oil levels from 0-300 mm in 5 mm increments
•Syringe has a capacity of 60 ml
DESCRIPTION
PART #
Fork Tube Tool
3805‑0045
FORK OIL LEVEL KIT
•A rugged, accurate measuring scale to adjust
fork oil height
•Built-in memory device to eliminate guesswork
DESCRIPTION
PART #
Fork Alignment Tool
3801‑0115
FORKTRU FORK
ALIGNMENT TOOL
•Quick and easy-to-use tool for
aligning front forks to ensure they are parallel from top to bottom
•Knurled adjustment screws for easy setup
•Proper alignment reduces stiction, enhancing fork performance
•Reduces seal and bushing wear
•Will work on 27 mm-62 mm fork legs and tubes
•Works on forks that are distanced 140 mm to 220 mm (5,5”-8,6”) on center
•Patent pending
DESCRIPTION
PART #
Fork fluid filler
3805‑0114
FORK FLUID
FILLER
•Ultimate tool for servicing
fork oil on conventional forks
that have a drain screw
•Huge time saver by not
having to remove fairing,
handlebars and other parts
•No need to remove fork caps
•Must be used with
Mityvac vacuum pump
(PART #3850-0104) or similar;
available separately
•Not for use with cartridge or inverted forks
•Made in the U.S.A.
DESCRIPTION
PART #
Fork Oil Level Adjustment Kit
FOL‑2
FORK OIL LEVEL
ADJUSTMENT KIT
•A fork oil level measurer and
adjuster in one
•Simply set stop to recommended
height, lower into fork and reverse
pump to suck oil out until level
is reached
DESCRIPTION
PART #
Compression Bolt Removal Tool
3801‑0111
COMPRESSION BOLT
REMOVAL TOOL
FOR KTM
•Fits 2007-later KTM with WP 4860 MXMA CC forks
•For removing and installing the compression
valve assembly from the fork cap
•17 mm hex head
•Made from billet 6061 T-6 aluminum
•Anodized finish with laser engraving
CAUTION
: Fork cap assembly under pressure! Always wear safety glasses and refer to
the fork manufacturers for correct assembly and disassembly procedures.
DESCRIPTION
PART #
Fork Leg Holder Tool
3805‑0032
FORK LEG
HOLDER TOOL
•Holds fork legs and tubes for easy
hands-free servicing or rebuilding
•Mounts in vise to hold fork firmly
during repair without causing damage to fork assembly
•Will not scratch finish
•50,8 cm (2”) maximum diameter
•Made in the U.S.A.
DESCRIPTION
PART #
Fork Oil Level Kit
FOL‑1
