BLADDER CAP SNAP RING
REMOVAL TOOL
•Used to tap the bladder cap down to remove the
snap ring
•Eliminates damage to the Schrader valve
DESCRIPTION
PART #
Bladder Cap Snap Ring Removal Tool
3805‑0009
DESCRIPTION
PART #
Folding Sag Scale
3806‑0007
FOLDING SAG SCALE
•6061 T-6 aluminum construction
•Rigid folding design fits in most tool boxes
•Direct reading scale (no subtracting required)
•Adjustable zero set point with extended range
•Will work on both mini and full-size motorcycles
•Inch and metric scale combination
•Installs in rear axle
•Can be used to check front or rear sag
•Extended length 72 cm (28
1
/
4
”)
•Folded length 40 cm (15
3
/
4
”)
DESCRIPTION
PART #
Shock Nitrogen Charging Tool
3805‑0046
SHOCK NITROGEN
CHARGING TOOL
FOR KTM WP SHOCKS
•Works on all WP shocks that have a reservoir
•Less expensive and easier to use than the
factory recharging tool
•Clamps on to the reservoir
DESCRIPTION
PART #
Shock Bearing Driver Set
TSBD‑SET
SHOCK BEARING
DRIVER SET
•For easy installation of shock shaft bushings into seal heads
•Comes with 12,5 mm, 14 mm, 16 mm and 18 mm bushing drivers
•Works with all OEM shocks with 12,5 mm, 14 mm, 16 mm and 18 mm shafts
•Perfect for use with Race Tech shock shaft bushings
DESCRIPTION
PART #
Nitrogen Gauge Pro
3805‑0020
DESCRIPTION
PART #
Nitrogen hose
3805‑0021
NITROGEN GAUGE AND HOSE
•High quality at low cost
•Nitrogen Gauge Pro is a 0-300 psi gauge that does not require a wrench
and reaches hard-to-get valve stems
•Nitrogen hose is a special 800 psi hose with finger-tight
1
/
4
” flare nut
quick couplings
NOTE: Race Tech nitrogen hose and gauge are meant to work together but can be
adapted with standard
1
/
4
” fittings.
DESCRIPTION
PART #
Nitrogen Needle for Shocks
TSNN01
NITROGEN NEEDLE
FOR SHOCKS
•Adapts shocks with self-sealing
rubber valves for use with Race Tech
nitrogen gauge PART #3805-0020
DESCRIPTION
PART #
Gauge and filler
P572
DESCRIPTION
PART #
Nitrogen needle set
3805‑0012
NITROGEN SHOCK GAUGE,
FILLER AND NEEDLE
•300-psi capacity
•Regulator and transfer hose required to get nitrogen
from tank to nitrogen Shock Gauge and Filler
•Bleeder valve and T-handle plunger pin chuck
•Swivel chuck has a 30,5 cm (12”) flexible hose
•Instructions, carrying box and Schrader valve extension included (required
on some Showa shocks)
•Nitrogen needle is used to fill shocks with self-sealing rubber valves (some
Yamaha, Fox and Öhlins)
•Instructions included
•Made in the U.S.A.
WARNING: For use by trained professional mechanics only! Improper use could result
in great bodily injury or death.
DESCRIPTION
PART #
Shock spanner wrench
DS‑192282
SHOCK SPANNER WRENCH
•Heavy-duty steel shock wrench for easy rear
shock spring pre-load adjustment
•Zinc plated
•Sold each
DESCRIPTION
PART #
Stainless Steel Shock Spanner
3805‑0038
STAINLESS STEEL SHOCK SPANNER
•Allows adjustment of shock preload
•Compatible with majority of shock makes
•Constructed of stainless steel; very strong and won’t corrode
•Small enough to fit into a tool kit
3805‑0020
3805‑0021
P572
3805‑0012
