862
DESCRIPTION
PART #
Ignition System Tester
MP08‑122
IGNITION SYSTEM TESTER
•Test the integrity and strength of your ignition system
•Spark gap is adjustable from 0 to 10 mm
•The larger the gap your ignition will jump, the stronger your system is
•Will test the ignition on most motorcycles, watercraft, ATVs
and snowmobiles
DESCRIPTION
PART #
Ignition Timing Tester
LM4100
IGNITION
TIMING TESTER
•Eliminate the guesswork when timing
a point-type ignition
•A switch allows for either a light or
a tone at the precise time of
point closure
•Can also be used as a continuity tester
IGNITIONMATE DUO
•Lightning-fast ignition diagnostic tool that displays and compares the ignition
parameters of two cylinders or ignition systems simultaneously – on the same
engine or on two like engines
•The power sport industry’s top tool for trouble-shooting problems on all ignition
systems (transistor, CDI, magneto, points)
•Precise and sensitive in measurement, yet robust and weather resistant
•Designed to find the failed part or bad connection on the vehicle – the tool pays
for itself by virtue of the time saved in tracing the problem on the vehicle before
disassembly/swapping out of parts
•Ignition signals are fast, high-voltage pulses of energy that can damage even a
good digital multi-meter, whereas the IgnitionMate has been specially designed
to measure and dynamically display both primary and secondary ignition signals
on bright LED bar graph displays
•Allows direct comparisons of secondary coil voltage, secondary spark current,
primary coil voltage/current, ignition peak voltage pulses, in-cylinder spark
stability and intensity, or primary circuit voltages
•Dual low-tension leads and high-tension leads
•The instrument is powered by an internal rechargeable 1,5Ah NiMH battery;
recharge the battery with any 12VDC source, such as a vehicle battery
or 12VDC adapter
•Battery switches off after two minutes of no activity, to conserve power
•Includes carrying case and necessary cable accessories
10 MM x 14 MM
SPARK PLUG
THREAD CHASER
•Restores and cleans threads of dirt, carbon build-up
and metal particles
•Range of sizes service 10 mm or 14 mm spark plugs
•Rubber O-ring holds chaser firmly in socket
•Use with
5
/
8
” hex deep well socket
5
/
8
” SPARK
PLUG SOCKET/
EXTENSION
•For use with
5
/
8
” spark plugs
•Special thinwall design fits in tight spaces
•Perfect for use on water-cooled 4-strokes with
5
/
8
” spark plugs
•Unique two-step extension – swivel or fixed
•
3
/
8
” drive swivel extension can be turned with a Phillips screwdriver,
3
/
8
” ratchet or driver,
or 14 mm wrench or socket
•Spark plug socket can be turned with
3
/
8
” driver, 19 mm wrench, or 19 mm socket
•Spark plug socket can be used with a screwdriver to hold the front 19 mm hex axles
on late-model 4-stroke motorcycles
•Fits KTM 4-strokes, DR-Z400, CRF450R, YZ/WR400/426F,
YZ250F, KLX300, DVX400 and many other motorcycles
and ATVs with
5
/
8
” spark plugs
DESCRIPTION
PART #
Spark Plug Socket
MP08‑0175
18 MM SPARK
PLUG SOCKET
•Originally designed for
the Honda XR400R as a trail tool but fits many models
with 18 mm plugs
•The thinwall socket is designed to fit into the plug
cavity and allow the user to choose between the
Motion Pro spark plug ratchet wrench, a
3
/
8
” ratchet
or
13
/
16
” wrench as well as a Tool Kit bar or Phillips
screwdriver through an 8,5 mm hole for removal
and installation
•Other applications include Honda XR250R 84-03,
XR350R 83-85, XR400R 96-04, XR500R 81-84, XR600R
85-00, XR650L 93-07, CRF150F 03-09 and CRF230F 03-09;
KTM 400SXC 2000, 620LC4 96-97, 620SX 97-98 and 640
LC4 99; and Yamaha XT225 92-99 and TT600 85
DESCRIPTION
PART #
For air‑cooled engines
M204
DESCRIPTION
PART #
For water‑cooled 2‑stroke engines
M205
PLUG WRENCHES
•Plug wrench for water-cooled 2-strokes has
a 12-point, broached socket for tight situations
•Handle can be custom-bent to better fit your application
•Fits standard 20,6 mm (
13
/
16
”) plug size
•Made in the U.S.A.
DESCRIPTION
PART #
Spark Plug Socket
3801‑0210
14 MM SPARK PLUG SOCKET
•Thin-wall design allows for use in small plug cavities
•Can be driven with
1
/
4
” drive ratchet, 13 mm or 14 mm
wrench, socket or T-handle
•Rubber plug retainer
•Designed for use on late-model KTM
4-strokes, 2010-2014 Honda CRF250R
and 2009-2014 CRF450R
DESCRIPTION
PART #
IgnitionMate Duo
3807‑0219
DESCRIPTION
PART #
Repl. backprobe set
3807‑0079
M204
M205
DESCRIPTION
PART #
Spark Plug Socket/Extension
MP080239
3807-0219
DESCRIPTION
PART #
Spark plug thread chaser
3807‑0222
