WIRE GAUGE SPARK
PLUG GAPPING TOOL
•Wire-gauge-type gapping tool for precise
measurement of electrode gap
•Six standard sizes – 0,025”; 0,030”; 0,034”; 0,035”; 0,040”; 0,045”
•Six metric sizes – 0,64 mm; 0,76 mm; 0,86 mm; 0,89 mm; 1,02 mm
and 1,14 mm
•Two electrode-adjusting tools
•Compact design
DESCRIPTION
PART #
4” reach (ea.)
3801-0183
DESCRIPTION
PART #
4” reach (5-pk.)
3801-0184
5
/
8
” SPARK PLUG
SOCKET WRENCHES
•Most popular size,
5
/
8
” spark plug
socket wrenches fit most
powersport applications
•Perfect for applications that require a thin-wall socket to fit into the head
where typical forged mechanics sockets will
not fit
•4” reach for spark plugs that may be situated rather deep into the head
•Sockets include a rubber grommet to hold the plug in place, and meet
ANSI tolerances
•Uses
11
/
16
” wrench to loosen or tighten the spark plug socket
•Available each or in dealer 5-pack
DESCRIPTION
PART #
Ratchet Spark Plug Wrench
P08-147
RATCHET SPARK PLUG WRENCH
•Designed to fit in limited space on many water-cooled 2-stroke engines
•Ratchet mechanism works one way, turn over to reverse
•Fits standard 20,6 mm (
13
/
16
”) plugs
DESCRIPTION
PART #
Heavy-Duty Spark Plug Wrench
849
HEAVY-DUTY SPARK PLUG WRENCH
•Chrome-finished steel combination wrench fits 14 mm or 18 mm spark
plugs thread with 21 and 26 mm hex head
DESCRIPTION
PART #
Wire Gauge Spark Plug Gapping Tool 3807-0048
LARGE CHROME
RAMP GAUGE
•Spark plug tool adjusts spark plug
gap in graduated ramp sequence
•Sizes: SAE 0,020–0,100”;
Metric 0,60 mm–2,40 mm
E-Z GRIP SPARK PLUG RAMP GAUGE
•Full range coverage for all spark plug gapping requirements from 0,060
mm to 2,00 mm (0,020 to 0,080”)
•Applications include those with distributor-less ignition systems
•Includes a recess specifically designed to adjust electrodes
•Universal spark plug gauge that is precise and easy to use
DESCRIPTION
PART #
Wire Crimper
3807‑0076
DESCRIPTION
PART #
Connectors/terminals kit
2120‑0349
WIRE CRIMPER AND
CONNECTORS
•High-quality crimper used by professionals
•Wire connector/terminal kit contains an assortment of male and female
connectors, matching terminals and wire sleeving often used
on imported motorcycles
DESCRIPTION
PART #
T-handle bit driver
3812-0049
T-HANDLE BIT
DRIVER WITH NO.
1, 2, 3 JIS
CROSS-HEAD
BITS
•High quality Motion Pro standard bit driver T-handle
•Features three
1
/
4
” drive heads, one at end of shaft and two at each end of
handle with magnets to hold drivers firmly in place
•Includes high grade S2 tool steel JIS cross-head bits no. 1, no. 2, and no. 3,
but also accepts all common driver bits
•Use of traditional Phillips driver on JIS cross head screws will
damage screw head
•Narrow drive head profile fits into tight spaces
•Chrome vanadium handle and shaft
•Durable chrome finish on shaft and handle
•Shaft is 8.5” long
DESCRIPTION
PART #
7-Way Crimper Tool
3807-0012
7-WAY CRIMPER TOOL
FOR SPARK PLUG WIRES
•Black anodized finish with insulated hand grips for protection
•Crimp slot on end of tool secures most ignition terminals including
W-type, right-angle and High Tower terminals
•Crimps 7 mm to 8,5 mm ignition wire
•Works with 10 to 22-gauge solderless terminals
3801-0183
DESCRIPTION
PART #
Ramp gauge
3807-0221
DESCRIPTION
PART #
E-Z grip spark plug ramp gauge
3807-0220
3807-0076
2120-0349
