860
RK CHAIN BREAKER/
PRESS-FIT
AND RIVET TOOL
•A necessity for O-ring chains with
rivet-type connecting links
•Easily press-fits tight-tolerance O-ring
side-plates to the correct depth for clip
link installation
•Press-fits all 50- and 60-series sealed chain
•Cuts all 40- and 50-series chain with the SKH9 tool-steel cutting pin
•Includes three flare pins and two adapters
PBR CHAIN BREAKER
•PBR = press, break, rivet
•Innovative design will press, break and
rivet 520, 525 and 530 chains with one
convenient tool
•Versatile design will remove chain pins, press master-link plates and
rivet hollow nose and soft nose (quad stake) master link pins on
O-ring and non O-ring type chains
•Easy-to-use design allows you to change tool functions by simply moving the position of the anvil block
•Indexing letters on movable anvil and body ensures correct tool configuration; simply line up the letter on the
anvil to the letter on the body to get the configuration you need
•All components conveniently store on tool when not in use
•All steel construction with heat-treated components for strength and durability
•May be supported in a vise or held with included handle
•Great for the professional technician or DIY mechanic
•Compact and light enough to carry in a tool bag for trailside repairs
•Patent pending
DESCRIPTION
PART #
Chain breaker
P501
Repl. pin
P502
CHAIN BREAKER
•For #420 to #530 chain
•Will push link pin completely
through link/side plate
•Handle folds away for
easy storage
•Replaceable pin is heat-treated
for strength and wear resistance
•Will not work on EK 330 MVO/MVX Chain
DESCRIPTION
PART #
Chain Breaker, Press and Riveting Tool
3806‑0014
CHAIN BREAKER, PRESS
AND RIVETING TOOL
•Complete chain tool for most 520, 525 and
530 standard and O-ring chains
•Break, press, and rivet your chain with
one compact tool
•Will rivet hollow-nose master links
(will not rivet solid soft-nose pins)
•Will push pin completely through link/side plate
•Hardened body, riveting tip and breaker pin for strength and durability
•Removable handle for compact storage
•Perfect for your trail/road tool pack if you have a chain with a rivet master link
DESCRIPTION
PART #
Press‑fit tool
UCT4060
DESCRIPTION
PART #
Flare pin
FP50
DESCRIPTION
PART #
Riveting tool
P558
Pin, 2 mm
P559
Pin, 3 mm
P560
DESCRIPTION
PART #
Pin, 4 mm
P561
Repl. wedge tip
P562
Repl. press plates
P567
CHAIN RIVETING
TOOL
•Versatile enough to be
used on cam chains or
drive chains
•Will break chains from
#35 to #530
•For chain #520 and up, it is
recommended to grind the rivet head
•Each kit includes three pin sizes to fit most
chains (2 mm, 3 mm, 4 mm)
•Investment-cast, hardened body and redesigned body bolt
•Recommended for light- to medium-duty use
•For riveting hollow nose master links
•Kit includes press plates PART #P567
DESCRIPTION
PART #
Press tool, complete
P566
Press pads only
P567
Breaking and riveting conversion kit
3806‑0011
CHAIN PRESS TOOL KIT
•For use on #520 and #530 chain standard and O-ring types
•Complete chain press tool includes press pads; does not rivet chain
•PART #3806-0011 (sold separately) turns chain press tool PART #P566
into a chain breaker and riveting tool for 520, 525, and 530 chains only
P501
HEAVY-DUTY CHAIN BREAKER
•Made for use on all 420 to 630 size chains
•Compression screw forces the pin out of chain for removal of
extra links
•Sold each
3806‑0011
P566
P567
UCT4060
DESCRIPTION
PART #
Chain Breaker
3806‑0016
P502
FP50
P558
DESCRIPTION
PART #
Heavy‑duty chain breaker
DS‑192276
