All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
HARDWARE & TOOLS
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
852
FITS MODEL
PART #
KTM
Late model KTM/Husaberg (WP USP 48 mm)
3805‑0108
FORK CAP
WRENCH TOOL
FOR WHITE
POWER FORKS
•High-quality aluminum fork
wrench for disassembling White Power forks
•Loosens fork caps without removing the handlebars
FITS MODEL
PART #
HONDA
CRF250R 04‑14
3805‑0105
CRF250X 06‑14
3805‑0105
CRF450R 04‑08
3805‑0105
CRF450X 05‑07
3805‑0105
KAWASAKI
KXF250 06‑14
3805‑0105
FITS MODEL
PART #
SUZUKI
RM125 06‑08
3805‑0105
RM250 07‑08
3805‑0105
RMZ250 07‑14
3805‑0105
RMZ450 05‑14
3805‑0105
FORK CAP
WRENCH TOOL
FOR SHOWA FORKS
•High-quality aluminum fork cap wrench for disassembling Showa forks
•Loosens fork caps without removing the handlebars
FITS MODEL
PART #
HONDA
CRF450R 09‑14
3805‑0104
KAWASAKI
KX450F 06‑14
3805‑0104
FITS MODEL
PART #
YAMAHA
YZ125/250 06‑14
3805‑0104
YZ250F/450F 06‑14
3805‑0104
FORK CAP
WRENCH TOOL
FOR KAYABA AND
KYB FORKS
•Constructed of aluminum
and stainless steel, this double
key makes disassembling your Kayaba or KYB forks a snap
•Loosens fork caps without loosening handlebars
DESCRIPTION
PART #
Fork Cap Wrench
MP08‑0236
FORK CAP
WRENCH
•For removing the fork caps on late-model Honda CR
models and Suzuki RM models
•Can be used for removal of a compression stack on late-model RMs
•One end is 46 mm, the other is 50 mm
FITS MODEL
PART #
HONDA
CRF250R/X 04-09/12, CRF450R 02-08, CRF450X 05-09.12 (Showa 46 mm
and 50 mm Twin-Chamber forks)
TFCW4650
KAWASAKI
KX250 05-07, KX250F 06-12 (Showa 46 mm and 50 mm Twin-Chamber forks)
TFCW4650
KTM
125/200/250/450/525 SX 02-06, 300 XC/XC-W 06, 450/525/560 SMR 05-06,
300 EXC 03-04 (WP 48 mm forks)
3805-0079
FITS MODEL
PART #
KTM (CONT)
125/144/150/250/450/505 SX/SX-F 07-10, 150 XC 10, 250/350/450 SX-F 11-12,
505 XC-F 08-09 (WP 50 mm dual-chamber forks)
3805-0048
SUZUKI
RM125 96-07, RM250 96-08, RM-Z250 07-12, RM-Z450 05-12 (Showa 46 mm
and 50 mm Twin-Chamber forks)
TFCW4650
1
1
Can also be used to adjust compression damping on RM125 96-03 and RM250 96-00.
FORK CAP WRENCHES
•PART #TFCW4650 has two six-point box ends
•PART #3805-0048 features a hex on one end and a pin
spanner on the other to allow access to the inner chamber
•Both are steel with an embossed Race Tech logo on handle
3805‑0048
3805‑0079
TFCW4650
FORK CAP TOOL
FORK KYB FORKS WITH
49 MM OCTAGONAL CAPS
•For removing the fork cap and compression cartridge on twin chamber
KYB forks found on late-model Honda, Husqvarna, Kawasaki and Yamaha
off-road motorcycles
•Outer ring fits 49 mm octagonal fork cap
•Inner body holds cartridge so it can be removed from fork cap
•Outer ring can be clamped in vise to hold fork cap securely while cartridge
is being removed
•Provides more secure grip on fork cap and cartridge and reduces risk of
damage during disassembly
•Easier and faster to use than any other tool now available
•Billet 6061 aluminum construction
with anodized blue finish
•
1
/
2
” square drive
DESCRIPTION
PART #
Fork cap tool
3805‑0106
FORK CAP WRENCHES
FOR DUAL-CHAMBER
FORKS ON HONDA,
KTM AND YAMAHA
•For removing the fork cap (cartridge) on
dual-chamber closed-cartridge forks
•12 mm slot for holding the damper rod when removing the rebound bolt;
this allows for the removal of the cartridge from the lower fork leg
•Made of billet 6061 T-6 and anodized Motion Pro blue
•Laser-engraved markings with Motion Pro logo
•Original Motion Pro design
DESCRIPTION
PART #
49 mm, 8‑point box wrench for dual‑chamber closed‑cartridge forks on
late‑model Honda and Yamaha
3805‑0059
50 mm, 6‑point box wrench for WP 4860 MXMA dual‑chamber closed‑cartridge
(WP USD 48 mm) forks on late‑model KTM
3805‑0060
3805‑0059
3805‑0060
DESCRIPTION
PART #
Cartridge Bleeding Tool Kit
3805‑0004
CARTRIDGE BLEEDING TOOL KIT
•Easily threads onto the damping rod to facilitate cartridge fork bleeding when
changing fork oil
•Baffled to eliminate the mess normally encountered when bleeding cartridges
•Kit includes adapters for 10 mm x 1,0 mm, 12 mm x 1,0 mm, 12 mm x 1,25 mm
and 14 mm x 1,0 mm
damping rods
•Zinc-coated
DESCRIPTION
PART #
Cartridge Fork Holding Tool
TFHP01
CARTRIDGE FORK HOLDING TOOL
FOR TWIN-CHAMBER FORKS
•Makes disassembly and assembly of twin-chamber
cartridge forks easier by holding
cartridge rod while bottom nut
is loosened or tightened
