839
FITS MODEL
PART #
BETA
RR/RS 4-strokes 05-14, RR250/00 13-14
SS-46
HONDA
Most 50-80cc QA, MR, CH, CR models
SS-43
XR/XL/CRF50-100, most off-road and motocross 2- and 4-stroke: CR80-500cc (late model) and all small-bore 4-stroke 80-100cc XL
SS-1XX
CRF230F, SL175, SL350, some early CR125M/CR250M models
SS-10
Most XL/XR250, XL/XR350, XL/XR500, XL/XR600, XL/XR650, NX650 and TL250 models
SS-11
XR185, XR200, XR200R, XL125, XL185S and XL200 (see SS-10 for larger application)
SS-19
XL/XR200/250/400/650s
SS-9
CRF150R 07-09, CRF250R 04-09, CRF450R 02-08, CRF250X 04-08
SS-63
CRF250R 10-14, CRF450R 09-14, CRF450X, CR250R 78-80
3802-0016
Early 2-cycle magneto pullers (see SS-7 for larger diameter)
SS-6
Most MT250 and early 2-cycle magneto pullers (see SS-6 for smaller diameter)
SS-7
HUSABERG
400/501/600 models
SS-12
FE250/390/450/650, FX450, FS570
SS-46
HUSQVARNA
All models with ignition point systems 60-70
SS-2
Early mid-70s-80s 2-cycle models with CDI ignitions
SS-3
WX Series 2-stroke enduro models
SS-11
Late-model 2-stroke models with CDI ignitions
SS-12
610 models
SS-29
Most 250/450/510 TE/TC/SM/SMR 4-strokes
SS-46
TXC250/TE250 10-13 (EFI)
3802-0045
350E/610E 4-strokes 90-98
SS-45
KAWASAKI
Most 50cc mini models
SS-43
KX85/100; KV75, MC190, G4TR90, G4TR100, F6 125, F7 175 Enduros, KD80, KM100, KE100, KE125, KE175, KDX80, KDX200, KDX220, KDX250, KX60, KX80, KX125,
KX250 and KX500 models
SS-1XX
KLX110 03-07, KLX450R
3802-0016
Early-model KX125/250/420
SS-10
KLR250 85-95, KLR600A 84-86, KLR650A 87-95, KLR650B Tengai 90-91 (see SS-9 for smaller application)
SS-11
KLR250/600/650, KL650 Tengai, KLX250/300
SS-9
KX250F 06-10, KX450F 04-08
SS-63
KX250F 11-14, KX450F 09-14
3802-0016
KTM
SX/SR Mini Racers, removes clutch bodies, flywheels and primary gears
3802-0033
Mini Racer and 50cc Senior
SS-50
Late-model 2-stroke internal-rotor MOTOPLAT liquid-cooled engines
SS-3
All large-flywheel external-rotor MOTOPLAT engines: 125, 250, 300, 360 and 495cc
SS-12
250/400/450/525/620 EXC/MXC/SMC/SX/XC 4-stroke 88-11, 250/300 XC/XCW 2-stroke 08-11
SS-46
620/625/640/960/690 LC4 electric-start models
3802-0005
MOTOPLAT with 33 mm x 1,5 right-hand, internal, male
SS-4XX
SUZUKI
Most 50cc mini models
SS-43
RM60, RM80, RM100, RM125, RM250, RM370, RM400, RM465, RM500 76-87; PE175, PE250, DR200, DR250, DR370, DR400; early model SP250, SP370 and SP400
SS-13
RM80/85, RM100 03, RM125, RM250 and RMX250 88-09, most off-road and motocross models
SS-1XX
TM125, TM250 and TM400 and mid-70s TS250, DR200SE 04-09 (see SS-29 for larger application)
SS-8
DR250/350 dual/off-road models (see SS-29 for 76,2 mm (3”) depth)
SS-5
RM-Z250 04-09, RM-Z450 04-07
SS-63
RM-Z250 10-14, RM-Z450 08-14, DR-Z110
3802-0016
Most DR250, DR350 and DR600 dual-sport models
SS-29
Used for removal of starter alternator rotor from crankshaft on DR500, SP300, DR650
SS-39
TM
250 EFI 4-strokes 11-14
3802-0045
YAMAHA
Most 60s-90s 2-stroke and 4-stroke models w/ CDI ignitions; AT125, CT175, DT250, RT360, SC500, IT200, YZ250, YZ400, YZ490, TT/XT500, YZ250F, YZ400F,
YZ426F, 03-05 YZ450F
SS-1XX
Most YZ125 2-stroke w/ liquid-cooled engine
SS-6
Most 70s YZ125, YZ250, YZ360
SS-7
For 4-cycle XT series (see SS-1XX and SS-8 for smaller applications)
SS-29
WR250F 03-09
3802-0006
WR450F 04-09
3802-0005
WR250F 01-02, most WR400F/WR426F
SS-54
YZ450F 06-09
SS-63
For all applications taking a 24 mm x 1,0 right-hand, external, female
SS-30
DESCRIPTION/SIZE AND TOOL TYPE
PART #
33 mm x 1,5 (76,2 mm depth (3”)); right‑hand, female
3802‑0005
30 mm x 1,0; right‑hand, female
3802‑0006
28 mm x 1,0; right‑hand, female
3802‑0016
7‑hole flywheel puller disc w/ 6 mm bolts
3802‑0033
26 mm x 1,5; right‑hand, female
3802‑0045
27 mm x 1,0; left‑hand, male
SS‑1XX
33 mm x 1,5; right‑hand, male
SS‑2
27 mm x 1,25; right‑hand, male
SS‑3
30 mm x 1,5; right‑hand, male
SS‑4XX
35 mm x 1,5; right‑hand, female (25,4 mm depth (1”))
SS‑5
DESCRIPTION/SIZE AND TOOL TYPE
PART #
18 mm x 1,5; right‑hand, male
SS‑6
20 mm x 1,5; right‑hand, male
SS‑7
30 mm x 1,5; right‑hand, female
SS‑8
20 mm x 1,5; right‑hand, male
SS‑9
16 mm x 1,5; right‑hand, male
SS‑10
22 mm x 1,5; right‑hand, male
SS‑11
26 mm x 1,5; right‑hand, male
SS‑12
8‑hole disc w/ 6 mm puller bolts
SS‑13
14 mm x 1,5; right‑hand, male
SS‑19
35 mm x 1,5; right‑hand, female (76,2 mm depth (3”))
SS‑29
DESCRIPTION/SIZE AND TOOL TYPE
PART #
24 mm x 1,0; right‑hand, female
SS‑30
42 mm x 1,5; right‑hand, female
SS‑39
24 mm x 1,0; right‑hand, male
SS‑43
28 mm x 1,5; right‑hand, male
SS‑45
26 mm x 1,0; right‑hand, female
SS‑46
19 mm x 1,0; right‑hand, male
SS‑50
3‑hole disc w/ 6 mm puller bolts
SS‑54
24 mm x 1,5; right‑hand, female
SS‑63
FLYWHEEL PULLERS, ROTOR PULLERS AND SPECIAL TOOLS
•Measurements are from male threads (outside edge)
•Consult the descriptions first to find a tool or puller
•Made in the U.S.A.
NOTE: Internal threads in the engine part take a male-threaded tool or puller; external threads on the engine part
take a female-threaded tool or puller.
NOTE: Lubricate heavily before use.
PULLER DIMENSIONS
FLYWHEEL/ROTOR PULLERS
SS‑54
3802‑0006
SS‑30
SS‑39
SS‑5
SS‑29
SS‑13
SS‑3
SS‑45
SS‑46
SS‑43
SS‑4XX
3802‑0005
3802‑0045
SS‑50
SS‑8
SS‑63
SS‑1XX
SS‑12
SS‑2
SS‑7
SS‑6
SS‑9
SS‑11
SS‑10
SS‑19
