All part numbers in
BOLD MAGENTA
are new this year.
2014 PARTS EUROPE OFFROAD
HANDLEBARS & CONTROLS
EXHAUST
TIRES
TUBES &
WHEELS
TIRE
ACCESSORIES
ACCESSORIES
HANDLEBARS
& CONTROLS
FOOT
CONTROLS
BODY
GRAPHICS
& SEATS
SPROCKETS
CHAINS
BRAKES
SUSPENSION
ELECTRICAL
& GAUGES
ENGINE
FUEL/AIR
SYSTEMS
CHEMICALS
& LUBRICANTS
HARDWARE
& TOOLS
TRANSPORT
& TRAILER
RIDER
ACCESSORIES
MERCHANDISING
INDEX
131
M0446254
DESCRIPTION
PART #
A ‑ WIDTH
B ‑ HEIGHT
C ‑ RISE
D ‑ BASE
F ‑ CONTROL LENGTH
Honda/Kawasaki OE bend (901)
0601‑2533
802
99
65
200
54
McGrath bend (902)
0601‑2534
805
83
40
205
55
Champ bend (907)
0601‑2535
805
93
50
205
55
Country Boy bend (914)
0601‑2536
803
92
56
210
57
Shorty bend (929)
0601‑2537
802
80
49
205
60
CR Hi bend (930)
0601‑2538
795
95
70
205
62
PODIUM HANDLEBARS
•Building off of the CFT platform in 2013, ODI constructed the Podium bar from a high-tensile strength alloy for more durability
•Although you give up some comfort in the flex of the material, it is more than made up for with the added strength
•Constructed of 2014 alloy for strength
•Feature the CFT crossbar
•Includes bar pad
•32 mm (1,25”) outside diameter clamp area
DESCRIPTION
PART #
A ‑ WIDTH (MM)
B ‑ HEIGHT (MM)
C ‑ RISE (MM)
D ‑ BASE (MM)
F ‑ CONTROL LENGTH (MM)
Honda/Kawasaki OE bend (701)
0601‑2529
802
99
65
200
54
Henry/Reed (766)
0601‑2530
803
92
56
210
57
Supermini (784)
0601‑2532
740
118
83
95
42
22 mm (
7
/
8
”) HANDLEBARS
•The perfect replacement for OEM handlebars on most minis and 2-strokes
•Constructed of 7075 alloy for high strength
•Clamped crossbar for additional support
•22 mm (
7
/
8
”) diameter
•Available in multiple bends
•Include bar pad
X-LINE SERIES HANDLEBARS
•The bulged alloy handlebars from Magura
•Light, stable, reduced rider fatigue!
•Ball-burnished finish for increased durability
•TÜV approved
FITS MODEL
PART #
Kawasaki with split clamp
M0720474
Honda, Yamaha, Suzuki with one‑piece clamp/fork bridge; hole distance 32‑36 mm M0720488
1, 2
1
Adds 18 mm to rise.
2
For use on rigid handlebar mounts only.
X-LINE BULGE BAR
•Extremely light, stable, butted alloy handlebar reduces rider fatigue
•Easily installed bar mounts provide an alternative to replacing expensive
top triple clamp
•Bulge diameter 28,6 mm (1
1
/
8
”); suitable for standard-size grips and controls
•Constructed of 7075 T-6 aluminum
•Light titanium in color
•TÜV approved
X-LINE BULGE BAR PADS
•Designed to be used with Magura X-line Bulge Bars
•Available in black
PART #
0601-1928
X-LINE BULGE BAR MOUNTS
Application Guide
Application Guide
BULGE BAR
DESCRIPTION
HEIGHT
PULLBACK
PART #
SX
120 mm
63 mm
M0446254
M0720474
0601‑2533
0601‑2529
DESCRIPTION
COLOR
A (MM)
B (MM)
C (MM)
F1 (MM)
H (MM)
0 (MM)
PART #
MX Extreme Motocross
Silver
808
135
195
105
80
22
0612‑0239
M0720488
